ຄູ່ມືການໃຊ້ງານຊຸດເຄື່ອງເຊື່ອມໂມງ DIY 4 ຕົວເລກ IS RGB

1. ບົດແນະນຳ

This manual provides detailed instructions for assembling and operating your IS RGB 4-Digit DIY Clock Soldering Kit. This kit is designed as an educational project to develop soldering skills and understand basic electronics, resulting in a functional digital clock with various display features and colorful LED lights.

Image 1: The fully assembled IS RGB 4-Digit DIY Clock.

2. ຂໍ້ມູນຄວາມປອດໄພ

Please read and understand all safety warnings before beginning assembly. This kit involves soldering, which requires caution.

• ເຮັດວຽກຢູ່ໃນບ່ອນທີ່ມີລະບາຍອາກາດດີສະເໝີ ເພື່ອຫຼີກເວັ້ນການຫາຍໃຈເອົາຄວັນໄຟ.
• Wear appropriate eye protection (safety glasses) to protect against splashes or flying debris.
• Use a soldering iron with care; it operates at high temperatures and can cause burns.
• Ensure the soldering iron is placed in a safe holder when not in use.
• Keep flammable materials away from the soldering area.
• Wash hands thoroughly after handling solder, especially lead-based solder.
• Keep components and tools out of reach of children and pets.

3. ເນື້ອໃນຊຸດ

Verify that all components listed below are present in your kit before starting assembly. Refer to the image for visual confirmation.

Image 2: All components included in the soldering kit, laid out for inspection. This includes PCBs, resistors, capacitors, LEDs, buttons, and a USB cable.

ຊຸດຂອງທ່ານຄວນປະກອບດ້ວຍ:

• ກະດານວົງຈອນພິມ (PCBs)
• Resistors (various values)
• Capacitors (electrolytic and ceramic)
• RGB LEDs (frosted)
• 8x8 Dot Matrix Screens
• Push Buttons ('Set', 'Save', '+', '-')
• ລໍາໂພງ
• Integrated Circuits (ICs) and sockets
• ໄດໂອດ
• Transistors
• ສາຍໄຟ USB
• Mounting hardware (screws, standoffs)

4. Assembly Instructions (Soldering Project)

This section guides you through the assembly process. A basic understanding of soldering is recommended. Refer to the detailed printed instruction manual included in your kit for specific component placement and values.

ຮູບພາບ 3: ຕົວຢ່າງample of soldering practice, highlighting the educational aspect of the kit.

4.1 General Soldering Tips

• Heat both the component lead and the PCB pad simultaneously.
• Apply a small amount of solder to the heated joint.
• Remove the solder, then the iron, ensuring a shiny, cone-shaped joint.
• Avoid cold solder joints (dull, lumpy appearance) or solder bridges (solder connecting two unintended pads).

4.2 Assembly Steps (General Order)

It is generally recommended to solder components from lowest profile to highest profile. This makes the process easier and prevents damage to taller components.

1. Resistors and Diodes: Identify values and polarity (for diodes) and solder them into their designated positions.
2. ຕົວເກັບປະຈຸ: Pay attention to polarity for electrolytic capacitors.
3. Integrated Circuit (IC) Sockets: Solder the sockets first, then insert the ICs carefully after all soldering is complete to prevent heat damage.
4. ປຸ່ມກົດ: Solder the 'Set', 'Save', '+', and '-' buttons.
5. ໄຟ LED RGB: These require careful soldering due to their small size and multiple contacts. Ensure correct orientation.
6. 8x8 Dot Matrix Screens: Solder these display modules.
7. ລໍາໂພງ: Solder the speaker connections.
8. ພອດພະລັງງານ: Solder the USB power input port.
9. ສະພາສຸດທ້າຍ: Once all components are soldered, carefully assemble the PCBs and any casing using the provided screws and standoffs.

After assembly, double-check all solder joints for continuity and absence of shorts before applying power.

5. ຄໍາແນະນໍາການດໍາເນີນງານ

This section details how to use your assembled RGB 4-Digit DIY Clock.

5.1 ການເປີດເຄື່ອງ

Connect the provided USB cable to the power port on the clock and plug the other end into a 5V USB power adapter (not included) or a computer USB port. The clock will power on and display the current time or the last saved display mode.

Image 4: The clock powered via USB, illustrating its power-off memory feature.

5.2 ຮູບແບບການສະແດງ

The clock supports multiple display modes. Press the "Save" button to cycle through the available displays:

• ເວລາ (ຮູບແບບ 24 ຊົ່ວໂມງ)
• ປີ
• Date (MMDD format)
• ມື້ຂອງອາທິດ
• ອຸນຫະພູມ (Celsius)

Image 5: The clock showcasing its five different display modes: time, year, date, day of the week, and temperature.

Watch the video below to see the display modes in action:

5.3 Setting Clock Functions

ກົດ "Set" button to enter the setting mode. Use the "+" ແລະ "-" buttons to adjust values. Press "Set" again to confirm and move to the next setting. Press "Save" to exit setting mode and save changes.

Image 6: The clock displaying its six function settings: setting time, year, date, week, alarm clock, and alarm sounds.

ການຕັ້ງຄ່າທີ່ມີຢູ່ລວມມີ:

• ກໍານົດເວລາ
• ກໍານົດປີ
• ກໍານົດວັນທີ
• ກໍານົດມື້ຂອງອາທິດ
• Set the alarm clock time
• Set the alarm sounds (3 melodious tunes available)

The video below demonstrates how to access and adjust these settings:

ໄຟ LED 5.4 ສີ

The clock features 24 frosted RGB LED lights that display dynamic color transitions. You can turn these lights on or off as desired.

Image 7: The clock's upper section illuminated with vibrant, changing LED colors.

To control the LED lights, use the dedicated buttons on the side of the clock. One button typically turns the lights on, and another turns them off. Refer to the markings on your PCB for exact button functions.

5.5 ຟັງຊັນປຸກ

The clock includes an alarm function with three selectable melodious tunes. Set the alarm time and choose your preferred tune in the setting mode (see Section 5.3).

Image 8: A visual representation of the alarm function, showing a hand reaching to press a button to silence the alarm.

When the alarm sounds, press any button on the clock to silence it.

5.6 Power-Off Memory Function

The clock retains its settings (time, date, alarm, etc.) even when power is disconnected. Upon reconnection, it will automatically restore the accurate local time and previous settings without requiring manual reset.

6. ບໍາລຸງຮັກສາ

• ທໍາຄວາມສະອາດ: Use a soft, dry cloth to clean the clock. Avoid abrasive cleaners or solvents.
• ການເກັບຮັກສາ: Store the clock in a dry environment, away from direct sunlight and extreme temperatures.
• ການທົດແທນອົງປະກອບ: If any components fail, they can be replaced by desoldering the faulty part and soldering a new one. This requires advanced soldering skills.

7. ການແກ້ໄຂບັນຫາ

8. ຂໍ້ມູນຈໍາເພາະ

Image 9: Dimensions of the assembled clock, showing a width of 3.74 inches, height of 3.74 inches, and depth of 0.83 inches.

• ຍີ່ຫໍ້: IS
• ໝາຍເລກຕົວແບບ: GY21504-1
• ປະເພດການສະແດງ: Digital (8x8 Dot Matrix)
• ໄຟ LED: 24 Frosted RGB Flashing Lights
• ຟັງຊັນ: Time (24-hour), Year, Date, Day of Week, Temperature, Alarm
• ແຫຼ່ງພະລັງງານ: DC 5V (ຜ່ານ USB)
• ໜ່ວຍຄວາມຈຳ: ການປິດການເຮັດວຽກຂອງຫນ່ວຍຄວາມຈໍາ
• ວັດສະດຸ: Plastic (frame), Electronic Components
• ຂະໜາດຜະລິດຕະພັນ: Approximately 3.74"W x 3.74"H x 0.83"D
• ນ້ໍາຫນັກລາຍການ: 7.8 ອອນ
• ການນໍາໃຊ້ພາຍໃນ / ນອກ: ພາຍໃນ

9. ການຊ່ວຍເຫຼືອລູກຄ້າ

For further assistance, technical support, or inquiries regarding your IS RGB 4-Digit DIY Clock Soldering Kit, please contact ICSTATION customer service. Refer to the contact information provided with your purchase or visit the official ICSTATION store on Amazon.

ICSTATION Store: Visit the IS Store on Amazon
