Linortek Netbell®-KL-C
Network Extra Loud Bell Clock System
Owner’s Manual
The Key Features
- Easy to Install: The Netbell system is low voltage system that’s designed for DIY installation, no need to hire professional installer
- Web-based control: Access, schedule, and manage your break bells from any computer on the network
- Programmable up to 500 events: Create schedules for breaks and shift changes, automated reminders from standard browser
- High-output loud bell: Up to 102dBa@1m ensures your alerts are heard even in the noisiest environments
- Flexible scheduling: Weekday or calendar-based bell scheduling giving you the flexibility of bell control
- Easy to Expand: Each Netbell is an independent system, that you can easily add more units to the existing system as your business grows.
- Designed, developed and built in the USA
- Scan the QR code to learn more:
https://www.linortek.com/netbell-timed-alert-system/
Self-Contained, Easy-To-Use, Remote Access, Scheduling Bells from Web Browser, No Software Required to Install on Your Computer
Linortek Netbell® is a network-enabled, affordable, reliable, and easy-todeploy timed alert system. With the easy-to-use built-in web interface, you can access, control, and schedule bells, equipment, or any other timed events over the network from a web browser. No additional software or designated computer is required, eliminating the need for complex wiring and control systems. This cost-effective solution is ideal for schools, factories, warehouses, and other facilities to signal start and stop work, lunch breaks, shift changes, as well as using it as employee alarm system to satisfy the requirements of OSHA 29 CFR 1910.165 regulation.
The Netbell-KL-C is a self-contained, all-in-one extra loud bell system with 4” digital clock that can synchronize its time from the Netbell, the clock can be plugged to the Netbell-KL clock output directly, no configuration required.
This easy-to-use bell system was designed for busy school administrators, factory/warehouse managers to save valuable time in setting up a break time alarm system. It comes with a built-in 6-inch high output bell (102dB) that can cover up to 20,000 square feet area, and a completely wired web-based bell controller installed within a NEMArated box. All software and mounting hardware required for installation and operation are included; no wiring is required. There is one external bell output that allows you to add one more bell (not included) as your business expands. With the digital input, you can wire a push switch to ring the bell manually in an emergency.
Netbell® Technical Specifications
| General Information | ||||
| Model | Netbell-KL-C | Netbell-KL-M2-C | Netbell-KL-E1-C | Netbell-KL-E2M-C |
| Part# | 01-910-00066 | 01-910-00081 | 01-910-00087 | 01-910-00088 |
| Technical Specification | ||||
| Bell Scheduling Software | Built- In (All software located on built-in web server.) | |||
| Event Schedules | Up to 500 Web-Based Event Schedules (Add schedules from web browser) | |||
| Bell Ringing Duration | User Programmable for Each Schedule | |||
| Built-In Bell (6″, 102dBa@lm) | 1 | |||
| 4″ LED Digital Clock | 1 | |||
| External Bell Output (s) | 1 | 2 | 1 | 2 |
| External Bell (s) (6″, 102dBa@lm) | 0 | 0 | 1 | 2 |
| Coverage (SQ FT) | 20,000 | 20,000 | 40,000 | 60,000 |
| Manual Bell Control | Yes | |||
| Push Switch | Optional | |||
| Enclosure | ABS, IP66 /150mm x 150mm x 90mm | |||
| Accessories | Power Cable/RJ45 Cable/Mounting Brackets | |||
| Power Input | 24VAC (included) | |||
| Voltage Sensor | On Board | |||
| Temperature Sensor | On Board | |||
| Rechargeable Battery | On Board (For offline time & settings keeping backup up to 7 days) | |||
| Working Temperature | From 0 to +60 Celsius | |||
| Supported Protocols | HTTP/ SMTP/SNTP | |||
Linor Technology, Inc.
www.linortek.com
Address: Winston Salem, NC 27127
© Linortek, information subject to change without notice.
