សេចក្តីផ្តើម
The LAUNCH CRP129i V2.0 is an advanced automotive diagnostic scan tool designed for comprehensive vehicle system analysis. It provides diagnostic functions for Engine, Transmission, Anti-lock Braking System (ABS), and Supplemental Restraint System (SRS), along with various reset and maintenance services. This manual provides instructions for the proper setup, operation, and maintenance of your device.
តើមានអ្វីនៅក្នុងប្រអប់
- 1* LAUNCH CRP129I V2.0 OBD2 Scanner
- 1* OBDII Diagnostic Cable
- 1 * DC 5V Charging Cable
- 1 * សៀវភៅណែនាំអ្នកប្រើប្រាស់
- 1 * Storage Pack
រៀបចំ
- ការសាកថ្មដំបូង៖ Before first use, connect the device to the DC 5V Charging Cable and allow it to charge for approximately 8 hours. The device typically ships with no battery charge.
- បើកថាមពល៖ ចុចប៊ូតុងថាមពលឱ្យជាប់ ដើម្បីបើកឧបករណ៍។
- ការតភ្ជាប់ Wi-Fi៖ Follow the on-screen prompts to connect the device to a Wi-Fi network. This is necessary for software updates. Initial updates may take up to 45 minutes to download and install automatically.
- ការតភ្ជាប់រថយន្ត៖ Locate your vehicle's OBDII port, usually under the dashboard on the driver's side. Connect the OBDII Diagnostic Cable from the scanner to the vehicle's OBDII port. Ensure the vehicle's ignition is in the 'ON' position (engine can be off).
សេចក្តីណែនាំប្រតិបត្តិការ
The CRP129i V2.0 features a touchscreen interface and physical navigation buttons for ease of use.
1. 4-System Diagnosis (Engine, Transmission, ABS, SRS)
This tool allows for comprehensive diagnostics across four critical vehicle systems. When a warning light appears for any of these systems, the scanner can identify the root cause.
- ប្រព័ន្ធម៉ាស៊ីន៖ Retrieves fault codes (DTCs) and real-time sensor data related to engine performance, fuel supply, ignition, intake, and exhaust systems.
- ប្រព័ន្ធបញ្ជូន៖ Diagnoses issues related to engine power transmission to the wheels, including the transmission, clutch, and drive shafts. It can retrieve fault codes, check fluid levels, and inspect sensors.
- ប្រព័ន្ធ ABS៖ Identifies problems within the anti-lock braking system, which prevents wheel lockup during emergency braking. Reads ABS-related fault codes and checks wheel speed and pressure sensors.
- SRS System: Reads and clears DTCs for the Supplemental Restraint System, addressing issues with airbags, seat belt pretensioners, and the SRS ECU.
Image: LAUNCH CRP129i V2.0 displaying diagnostic options for Engine, Transmission, ABS, and SRS systems.
Image: Screen of LAUNCH CRP129i V2.0 showing system selection menu for Powertrain Control Module, Transmission Control Module, ABS, and Restraint Control Module.
២.៤. ២៨ មុខងារកំណត់ឡើងវិញ
The CRP129i V2.0 offers 12 essential reset and maintenance functions. Function availability may vary by vehicle model.
- កំណត់ប្រេងឡើងវិញ៖ កំណត់ប្រព័ន្ធជីវិតប្រេងឡើងវិញ បន្ទាប់ពីការផ្លាស់ប្តូរប្រេង។
- ការបង្កើតឡើងវិញ DPF៖ Manages Diesel Particulate Filter regeneration.
- កំណត់ TPMS ឡើងវិញ៖ Resets Tire Pressure Monitoring System sensors.
- ABS ហូរឈាម៖ Performs brake bleeding to restore ABS brake sensitivity.
- ការសរសេរកូដម៉ាស៊ីនចាក់៖ បញ្ចូលលេខម៉ាស៊ីនចាក់ថ្មីទៅកាន់ ECU ។
- Air/Fuel Reset: Adjusts air/fuel ratio parameters.
- ការសម្របខ្លួនដោយបិទបើក៖ Relearns throttle body position.
- កំណត់ BMS ឡើងវិញ៖ Resets the Battery Management System.
- ការក្រិតតាមខ្នាត SAS៖ ក្រិតតាមខ្នាតឧបករណ៍ចាប់សញ្ញាមុំចង្កូត។
- កំណត់ EPB ឡើងវិញ៖ Resets the Electronic Parking Brake.
- AFS Headlamp កំណត់ឡើងវិញ៖ Resets the Adaptive Front-lighting System.
- AdBlue កំណត់ឡើងវិញ៖ Resets the urea system after maintenance.
Image: LAUNCH CRP129i V2.0 displaying 12 maintenance services.
3. Full OBD2 Functionality
The scanner supports all 10 OBD2 modes, ensuring comprehensive emissions-related diagnostics for vehicles post-1996, including OBDII, EOBD, and CAN standards.
4. Real-Time Live Data & Battery Monitoring
View real-time data streams in a 4-in-1 merged graph format, including parameters like oil temperature, speed, and tire pressure. Data can be recorded, replayed, and shared via email. The integrated battery monitoring function assesses battery health and voltage កម្រិត។
Image: LAUNCH CRP129i V2.0 displaying a real-time data stream graph.
Image: LAUNCH CRP129i V2.0 displaying a battery voltagអ៊ីក្រាហ្វ។
5. Auto VIN Scan & Diagnostic Reports
The device automatically identifies your vehicle's brand, model, and year via VIN scanning. After diagnosis, detailed reports can be viewed, shared, or printed for thorough analysis.
6. FCA AutoAuth Access
For 2017 and newer FCA (Chrysler, Jeep, Dodge, Fiat) vehicles with a Secure Gateway Module (SGW), the tool supports FCA AutoAuth for diagnostics and bidirectional features.
Image: The LAUNCH CRP129i V2.0 OBD2 Scanner Diagnostic Tool.
ថែទាំ
- ការអាប់ដេតកម្មវិធី៖ Regularly connect the device to Wi-Fi to download and install the latest software updates. This ensures optimal performance and compatibility with new vehicle models.
- ការសម្អាត៖ Use a soft, dry cloth to clean the device's screen and exterior. Avoid abrasive cleaners or solvents.
- ការផ្ទុក៖ Store the scanner in its provided storage pack in a cool, dry place away from direct sunlight and extreme temperatures when not in use.
ការដោះស្រាយបញ្ហា
- ឧបករណ៍មិនបើក៖ Ensure the device is fully charged or connected to the vehicle's OBDII port. Check the charging cable connection.
- គ្មានទំនាក់ទំនងជាមួយយានយន្ត៖ Verify the OBDII cable is securely connected to both the scanner and the vehicle's port. Ensure the vehicle's ignition is on. Check vehicle compatibility.
- បញ្ហានៃការធ្វើបច្ចុប្បន្នភាព៖ Ensure a stable Wi-Fi connection. If updates fail, try restarting the device and your Wi-Fi router.
- ការអានមិនត្រឹមត្រូវ៖ Ensure the vehicle's VIN is correctly identified. Consult the vehicle's service manual for expected parameter values.
លក្ខណៈបច្ចេកទេស
| លក្ខណៈ | ការបញ្ជាក់ |
|---|---|
| គំរូ | CRP129I V2.0 |
| ប្រព័ន្ធប្រតិបត្តិការ | ប្រព័ន្ធប្រតិបត្តិការ Android 8.1 |
| ទំងន់ធាតុ | 2.27 ផោន |
| វិមាត្រកញ្ចប់ | 9.85 x 7.17 x 3.07 អ៊ីញ |
| ថ្ម | 1 ថ្ម Lithium Ion ត្រូវការ |
ការធានា និងការគាំទ្រ
LAUNCH offers a 5-year warranty against manufacturer defects. For any issues or assistance, please contact LAUNCH customer support. For immediate concerns within the initial purchase period, refer to the retailer's return policy.
