1. សេចក្តីផ្តើម
The FCOB CCT Dual White RF Remote RC02RFB is designed for controlling CCT (Correlated Color Temperature) LED strips. This remote features 2.4GHz RF wireless transmission, allowing for 4-zone group control, brightness adjustment, and color temperature tuning. It is compatible with various FCOB CCT controllers, providing a convenient solution for managing your LED lighting.
2. មាតិកាកញ្ចប់
សូមផ្ទៀងផ្ទាត់ថាធាតុទាំងអស់មាននៅក្នុងកញ្ចប់របស់អ្នក៖
- 1x RC02RFB Remote Control
- 1x RF Remote Bracket
- 2x Screws for Bracket Installation
- 1x Double-sided Adhesive for Bracket Installation
- 1x RC02RF Remote Control Manual (this document)
Note: 3A batteries are required for the remote control and are not included in the package.
Image: The FCOB CCT Remote RC02RFB, shown alongside its wall-mount bracket and two screws for installation.
3. ផលិតផលលើសview
3.1 Remote Control Layout and Functions
Image: A detailed diagram illustrating each button and feature on the FCOB CCT Remote RC02RFB, including ON/OFF, color temperature slider, brightness controls, dynamic modes, and zone selection.
- មេ បើក/បិទ៖ Power on or off all linked devices.
- Color Temp Adjust Slider: Touch to dim brightness from 1% to 100% and adjust color temperature.
- អ្នកបើកយន្តហោះអិលamp: សូចនាករពន្លឺ។
- Cold-Warm White Switching: Press to cycle through cool white, nature white, and warm white.
- ពន្លឺ +/-៖ បង្កើនឬបន្ថយពន្លឺ។
- Dynamic Modes (M): Press to switch between various dynamic lighting modes.
- 100%/60%/30% Brightness: Shortcut buttons for specific brightness levels.
- ល្បឿន +/-៖ Adjust the speed of dynamic modes.
- Zone ON/(un)link Button (1-4): Turn on a specific zone or initiate linking/unlinking.
- Zone OFF/Night Light Mode: Turn off a specific zone or activate night light mode.
4. រៀបចំ
4.1 ការដំឡើងថ្ម
The RC02RFB remote control requires 3A batteries (not included). Open the battery compartment on the back of the remote and insert the batteries, ensuring correct polarity.
4.2 Linking Instructions
To link the remote control to an FCOB CCT controller:
- Disconnect the LED controller from its power supply for 10 seconds.
- Reconnect the LED controller to the power supply.
- Within 3 seconds of reconnecting power, short press the desired zone button (1, 2, 3, or 4) on the remote control 3 times.
- The LED strip connected to the controller will blink slowly 3 times, indicating successful linking.
Image: Visual guide for linking the remote control to an LED strip controller, detailing power cycling and button presses.
Important: If the LED strip does not blink slowly, linking has failed. Please repeat the above steps. A light that has already been linked cannot be linked again to the same zone.
4.3 Unlinking Instructions
To unlink the remote control from an FCOB CCT controller:
- Disconnect the LED controller from its power supply for 10 seconds.
- Reconnect the LED controller to the power supply.
- Within 3 seconds of reconnecting power, short press the previously connected zone button (1, 2, 3, or 4) on the remote control 5 times.
- The LED strip connected to the controller will blink quickly 10 times, indicating successful unlinking.
Image: Visual guide for unlinking the remote control from an LED strip controller, detailing power cycling and button presses.
Important: If the LED strip does not blink quickly, unlinking has failed. Please repeat the above steps. A light that hasn't been linked does not need to be unlinked.
5. Installation of Remote Bracket
The included remote bracket allows for convenient storage and access to your remote control. You can install it using either screws or double-sided adhesive.
5.1 Installation with Screws
- Choose a suitable location on a wall or surface.
- Mark the positions for the two screws using the bracket as a template.
- ខួងរន្ធអ្នកបើកបរបើចាំបាច់។
- Secure the bracket to the surface using the provided screws.
5.2 Installation with Double-Sided Adhesive
- Ensure the installation surface is smooth, clean, and dry.
- Peel off the protective backing from one side of the double-sided adhesive.
- Apply the adhesive firmly to the back of the remote bracket.
- Peel off the remaining protective backing and press the bracket firmly onto the desired surface.
Image: Illustrations demonstrating how to install the remote control bracket using either screws or double-sided adhesive.
6. សេចក្តីណែនាំប្រតិបត្តិការ
6.1 ការគ្រប់គ្រងថាមពល
ចុច ON button to turn on all linked LED strips. Press the បិទ button to turn off all linked LED strips.
6.2 ការលៃតម្រូវពន្លឺ
- Touch Slider: Gently touch and slide your finger along the color temperature adjust slider to dim the brightness from 1% to 100%.
- Brightness +/- Buttons: ចុច ពន្លឺ+ ដើម្បីបង្កើនពន្លឺនិង ពន្លឺ- ដើម្បីបន្ថយពន្លឺ។
- Preset Brightness Buttons: ប្រើ 100%, 60%, ឬ 30% buttons for quick brightness level selection.
6.3 ការលៃតម្រូវសីតុណ្ហភាពពណ៌
Use the touch slider to adjust the color temperature of your CCT LED strips. Slide towards the yellow side for warmer white light and towards the blue side for cooler white light. You can also press the ការផ្លាស់ប្តូរពណ៌សត្រជាក់ - ក្តៅ button to cycle through cool white, nature white, and warm white presets.
Image: A user adjusting the color temperature on the remote, demonstrating the transition from warm white to cool white light.
6.4 របៀបថាមវន្ត
ចុច M button to cycle through various pre-programmed dynamic lighting modes. Use the ល្បឿន+ និង ល្បឿន - buttons to adjust the speed of the selected dynamic mode.
6.5 Zone Control and Grouping
The RC02RFB remote supports controlling up to 4 independent zones. Each zone can control one or multiple linked controllers.
- Zone ON: Press the corresponding zone button (1, 2, 3, or 4) to turn on the lights in that specific zone.
- Zone OFF/Night Light: Press the corresponding zone button (1, 2, 3, or 4) again to turn off the lights in that zone or activate night light mode if supported by the controller.
The remote features auto-transmitting and auto-sync functions. One controller can transmit signals to another controller within 30 meters (98 feet), extending the effective control distance. This allows for independent control of individual areas without device limits.
Image: A visual representation of the 4-zone wireless control capability, demonstrating how one remote can manage LED controllers across different areas of a home.
Image: An illustration detailing the auto-transmitting and auto-sync features, where one controller relays signals to others, extending the control range.
២.១. ភាពឆបគ្នា។
The RC02RFB remote control is designed to work with FCOB CCT controllers. Compatible controllers include, but are not limited to:
- C02RF Controller
- C02W Controller
- WB5 Controller
- LM051 Controller
- LM052 Controller
- LM053 Controller
It supports 5050SMD, 3528SMD, 5630SMD CCT FCOB COB CCT 3-wire (+ WW CW) LED strips. Please note that this remote requires a compatible controller to function.
Image: The FCOB CCT remote displayed with several compatible CCT controllers (C02W, C02RF, WB5, LM051, LM052, LM053) and an illuminated LED strip, illustrating system compatibility.
8. ការដោះស្រាយបញ្ហា
- ពីចម្ងាយមិនឆ្លើយតប៖ Ensure batteries are correctly installed and have sufficient charge. Replace batteries if necessary.
- Linking failure: If the LED strip does not blink as expected during linking, repeat the linking steps carefully. Ensure the remote is within close proximity to the controller during the linking process.
- ការត្រួតពិនិត្យបណ្តោះអាសន្ន៖ Check for obstructions between the remote and the controller. Ensure the remote is within the specified 98-foot (30-meter) control range.
- Incorrect color temperature/brightness: Verify that the remote is correctly linked to the desired zone. Adjust settings using the touch slider and dedicated buttons.
9. លក្ខណៈបច្ចេកទេស
| លក្ខណៈ | ការបញ្ជាក់ |
|---|---|
| ម៉ាក | FCOB |
| លេខម៉ូដែល | RC02RFB-Z |
| ទំងន់ធាតុ | 3.52 អោន |
| វិមាត្រកញ្ចប់ | 5.91 x 5.91 x 0.79 អ៊ីញ |
| Power Source (Controller) | AC/DC (Remote uses batteries) |
| ថ្មដែលត្រូវការ | Yes (3A batteries, not included) |
| លក្ខណៈពិសេស | ឥតខ្សែ |
| បច្ចេកវិទ្យាតភ្ជាប់ | Radio Frequency (2.4GHz) |
| ជួរត្រួតពិនិត្យ | រហូតដល់ 98 ហ្វីត (30 ម៉ែត្រ) |
| ឧបករណ៍ដែលត្រូវគ្នា។ | C02RF, C02W, LM051, LM052, LM053, WB5 Controllers |
9.1 Energy Efficiency Information
Image: The energy label for FCOB CCT products, indicating an energy efficiency class of F and an energy consumption of 42 kWh per 1000 hours.
សម្រាប់ព័ត៌មានលម្អិតបន្ថែម សូមចូលទៅកាន់មូលដ្ឋានទិន្នន័យ EPREL៖ https://eprel.ec.europa.eu/qr/1552759
10. ព័ត៌មានសុវត្ថិភាព និងការព្រមាន
10.1 General Attention
- សីតុណ្ហភាពផ្ទុក៖ -40 ℃ ទៅ + 80 ℃
- សីតុណ្ហភាពប្រតិបត្តិការ៖ -25 ℃ ទៅ + 60 ℃
- ផ្ទៃដំឡើង៖ Must be smooth, clean, and dry.
- LED Components: The part of LED components cannot be fixed on the surface of a sharp edge.
- បន្ទះ LED៖ The strip cannot be collided or crushed. The strip can be cut following the cutting lines only.
10.2 Packaging Warning
Image: A close-up of the product packaging, displaying caution regarding moisture and electrostatic sensitive devices, and a warning about the plastic bag being a suffocation hazard.
CAUTION! THIS BAG CONTAINS MOISTURE ELECTROSTATIC SENSITIVE DEVICES!
WARNING! To avoid the danger of suffocation, keep this plastic bag away from babies and children. Do not use this bag in cribs, beds, baby strollers, or playpens. This bag is not a toy.
11. ការធានា និងការគាំទ្រ
For technical support, warranty information, or other inquiries, please contact the manufacturer:
- ក្រុមហ៊ុនផលិត៖ SHENZEN CHAOGUOSE Technology Co., Limited
- អ៊ីមែលជំនួយ៖ support@fcob.com
- Webគេហទំព័រ៖ www.fcob.com
- អាស័យដ្ឋាន៖ 201, 2F, C-C2, Chuangfu Tech Park, Beihuan Rd, Shiyan St, Baoan District, Shenzhen, Guangdong, China
- តំណាង EC៖ Like Sun GmbH, Planckstr. 59, 45147 Essen
