OPT7 Aura 2 PCS 10ft Extension Wires User Manual

1. ផលិតផលលើសview

The OPT7 Aura 2 PCS 10ft Extension Wires are designed to extend the reach of your existing OPT7 Aura 4-pin flat RGB LED lighting kits. These wires facilitate the installation of LED light strips in locations further from the main control box, such as the rear of motorcycles, golf carts, ATVs, UTVs, snowmobiles, boats, or for interior car lighting applications.

Each package contains two 10-foot extension wires, featuring a 4-pin flat RGB connector for seamless integration with compatible OPT7 Aura products.

Image 1.1: Two 10ft OPT7 Aura Extension Wires. These wires provide additional length for installing LED lighting kits.

2. ការណែនាំអំពីការដំឡើង

These extension wires are designed for a simple plug-and-play installation. Ensure your main OPT7 Aura LED kit is powered off before making any connections.

1. កំណត់អត្តសញ្ញាណឧបករណ៍ភ្ជាប់៖ Locate the 4-pin flat RGB connector on your existing Aura control box wire and on the LED light strip you wish to extend.
2. Connect Extension Wire: Align the pins of the extension wire connector with the pins of the control box wire. Gently push them together until they snap securely into place.
3. Connect to LED Strip: Connect the other end of the extension wire to the 4-pin flat RGB connector on your LED light strip, ensuring a firm connection.
4. ខ្សែផ្លូវ៖ Utilize the flexible design of the Aura wires to route them discreetly and securely to your desired lighting location. Avoid pinching or sharply bending the wires.

Image 2.1: Connection diagram illustrating the plug-and-play nature of the extension wires with an Aura LED strip.

2.1 ភាពឆបគ្នា។

These extension wires are compatible with any OPT7 Aura 4-pin flat RGB LED kits. They are ទេ។ compatible with 5-pin RGBW round connectors, 4-pin RGB round connectors, or 3-pin RGBIC round connectors.

រូបភាព 2.2៖ ឧamples of OPT7 Aura LED kits compatible with the 4-pin flat RGB extension wires.

រូបភាព 2.3៖ ឧamples of OPT7 LED kits that are NOT compatible with the 4-pin flat RGB extension wires due to different connector types.

3. សេចក្តីណែនាំប្រតិបត្តិការ

These extension wires serve to extend the physical reach of your OPT7 Aura LED lighting system. They do not have independent operational controls. The operation of your lighting system (e.g., color changes, modes, brightness) will continue to be controlled by your main OPT7 Aura control box and its associated remote or app, as detailed in the instruction manual for your specific Aura LED kit.

4. ការថែទាំ

To ensure the longevity and proper function of your extension wires, follow these maintenance guidelines:

• ការត្រួតពិនិត្យជាប្រចាំ៖ Periodically check all connections to ensure they remain secure and free from corrosion or damage.
• ការសម្អាត៖ If necessary, gently wipe the wires with a dry, soft cloth. Avoid using harsh chemicals or abrasive materials.
• ការការពារបរិស្ថាន៖ These wires are មិនធន់នឹងទឹក។. Avoid exposing them to direct water spray, submersion, or extreme moisture. Ensure they are installed in a location protected from the elements where possible.
• ការ​កំណត់​ផ្លូវ​ខ្សែ​: Ensure wires are not pinched, cut, or exposed to excessive heat or sharp edges, which could damage the insulation and internal conductors.

5. ការដោះស្រាយបញ្ហា

If you experience issues after installing the extension wires, consider the following:

• No Light/Intermittent Light:
  • Verify all 4-pin flat RGB connectors are fully seated and secure.
  • Ensure the extension wires are compatible with your specific OPT7 Aura LED kit (4-pin flat RGB). Refer to Section 2.1.
  • Inspect the wires for any visible damage, cuts, or pinches.
  • Test the LED kit without the extension wires to confirm the main kit is functioning correctly.
• ពណ៌​មិន​ត្រឹមត្រូវ៖
  • Ensure the connectors are not partially inserted or misaligned, which can lead to incorrect color signals.

For issues related to the functionality of the LED lights themselves (e.g., app control, specific light modes), please refer to the instruction manual provided with your main OPT7 Aura LED lighting kit.

6. លក្ខណៈបច្ចេកទេស

7. ការធានា និងការគាំទ្រ

This product is covered by a complimentary 30-day warranty, effective from the order date. For any questions, concerns, or warranty claims, please contact OPT7's US-based customer service team. Refer to your purchase documentation or the OPT7 official webគេហទំព័រសម្រាប់ព័ត៌មានទំនាក់ទំនងជាក់លាក់។

8. វីដេអូផលិតផល

No official seller videos specifically detailing the installation or use of these extension wires were found in the provided product information.
