kaptia Simply II 433 Unik 3 Button Remote Control
Introduction
The new Simply II models allow the copying and/or programming of most of the fixed or evolving code controls in our catalogue.
These controls have been designed in such a way that they are capable of reproducing the transmission characteristics of the original controls. Thanks to periodic updates, new compatibilities are introduced remotely on these devices, which avoids returns and allows stock to be reduced.
There are models for the 433 and 868 MHz band, both compatible with the Kaptia Klever system.
Product Description
Operation
To program the remote control, it must be connected to the micro USB cable of the Kaptia Klever duplicator. The app will guide you through all the necessary steps until programming is complete.
Indicator light
The device LED reports the following situations:
| The LED flashes regularly while the button is pressed | The code is transmitted normally |
| The LED flashes 2 times when you press a button | The remote (or button) is not programmed* |
| The LED flashes 3 times when you press a button | The battery is low. The battery must be replaced. |
*Note
Depending on the type of code loaded in the remote, this indication may be slightly different. If you have questions, contact Kaptia.
Battery replacement
This remote control works with 1 NON-RECHARGEABLE battery type CR2032.
To replace them, you must lever the notch on the right side with a coin or similar object until it opens.
Once opened, the used batteries must be removed from the battery holder and replaced with new ones of the same type, respecting the polarity.
Technical characteristics
| Compatible codes | Fixed and rolling codes (see compatibility list) |
| Operating frequencies | 433 / 868 MHz (depending on model) |
| Number of buttons: | 3 |
| Maximum number of codes | 1/3 (depending on code type) |
| Range | < 100 meters |
| Status LED color | White |
| Battery | 1 x 3V (type CR2032) |
| Supported system: | Katia Clever / Key (433 version only) |
| Updatable: | Yes |
Important: The programming connector should only be used to program the device. Using this connector for any other purpose may damage the device.
