1. Introduzione
This manual provides essential information for the proper setup, operation, and maintenance of your Tera P150 Android 12 Barcode Scanner PDA. Please read this manual thoroughly before using the device to ensure optimal performance and longevity.
Image 1.1: The Tera P150 Android Barcode Scanner PDA, showcasinil suo design elegante e l'interfaccia utente.
2. Impostazione
2.1 Contenuto della confezione
Verificare che tutti gli articoli siano presenti nel pacco:
- Tera P150 Android Barcode Scanner PDA
- Custodia protettiva
- Pellicola protettiva per lo schermo
- Cinturino da polso
- Cavo USB
- Adattatore per caricabatterie
- Manuale utente (Guida rapida)
Image 2.1: All components included in the Tera P150 product package.
2.2 Installazione e ricarica della batteria
- Individuare il vano batteria sul retro del dispositivo.
- Insert the 5000 mAh removable battery, ensuring proper alignment of the contacts.
- Fissare il coperchio della batteria.
- Connect the USB cable to the device and the charger adapter, then plug into a power outlet.
- Per una carica completa sono necessarie circa 3 ore.
Image 2.2: The removable 5000 mAh battery, designed for extended use.
2.3 Accensione/Spegnimento
Press and hold the power button located on the side of the device until the screen illuminates (for power on) or a power-off menu appears (for power off).
3. Istruzioni per l'uso
Sistema operativo Android 12 3.1
The Tera P150 operates on Android 12, offering an intuitive user interface, enhanced performance, and improved privacy controls. Navigate using touch gestures similar to other Android devices.
Image 3.1: The Tera P150 displaying multiple applications, demonstrating seamless multitasking capabilities with Android 12.
3.2 Barcode Scanning with Zebra SE4710
The device integrates a Zebra SE4710 scanner engine for efficient barcode reading. To scan:
- Aprire l'applicazione di scansione sul dispositivo.
- Point the scanner window at the barcode.
- Premere il pulsante di scansione dedicato (se disponibile) o avviare la scansione tramite l'interfaccia sullo schermo.
- Ensure the red laser or illumination covers the entire barcode for accurate capture.
Image 3.2: A user operating the Tera P150 to scan barcodes in a warehouse environment, highlighting the integrated Zebra SE4710 scanner.
3.3 Funzionamento del touch screen
The 5.5-inch full touch screen supports operation with gloves and wet hands, enhancing usability in various work conditions. The display offers a resolution of 1440 x 720 pixels.
Image 3.3: The Tera P150's 5.5-inch full touch screen, illustrating its responsiveness and clarity.
Funzionalità della fotocamera 3.4
The device is equipped with a 13.0 MP rear camera and a 5.0 MP front camera for documentation and communication purposes.
Immagine 3.4: Primo piano view of the Tera P150, highlighting the 13.0 MP rear camera and 5.0 MP front camera.
4. Manutenzione
4.1 Rugged Design and IP67 Rating
The Tera P150 features an IP67 rating, indicating resistance to dust and water ingress. It is also designed to withstand drops from up to 4.9 feet (1.5 meters), making it suitable for demanding environments.
Image 4.1: Visual representation of the Tera P150's IP67 water and dust resistance, and its 4.9ft drop resistance.
Video 4.1: Demonstration of the Tera P150's IP67-rated protection, showcasing its durability against water and drops.
4.2 Pulizia
Utilizzare un morbido, damp cloth to clean the device. Avoid harsh chemicals or abrasive materials that could damage the screen or casing.
5. Risoluzione Dei Problemi
5.1 Il dispositivo non si accende
- Assicurarsi che la batteria sia installata correttamente e completamente carica.
- Connect the device to the charger and attempt to power on.
5.2 Scanning Issues
- Verify the barcode is clean and undamaged.
- Garantire condizioni di illuminazione adeguate.
- Check the scanning application settings.
5.3 Performance Lag
- Chiudere le applicazioni in background non necessarie.
- Cancella cache e temporaneo files.
- Riavviare il dispositivo.
6. Specifiche
| Caratteristica | Dettaglio |
|---|---|
| Numero di modello | P150 |
| Sistema operativo | Androide 12 |
| Processore | MTK CPU |
| Memoria RAM | 4 GB |
| ROM (Archiviazione) | 64 GB |
| Lettore di codici a barre | Zebra SE4710 |
| Display | 5.5-inch Full Touch Screen |
| Valutazione della durata | IP67, 4.9 ft Drop Resistant |
| Batteria | 5000 mAh Removable |
| Telecamera posteriore | 13.0 MP |
| Fotocamera frontale | 5.0 MP |
| Connettività | 4G, GPS, USB |
| Peso dell'articolo | 1.3 libbre |
| Dimensioni del pacco | 7.6 x 4.2 x 2.9 pollici |
Video 6.1: Un overview of the Tera P150's key features, including its IP67 rating, 4GB RAM, 64GB storage, Android 12 OS, and 5.5-inch touch screen.
7. Informazioni sulla garanzia
Please refer to the warranty card included with your product for detailed warranty terms and conditions. Keep your proof of purchase for any warranty claims.
8. Supporto
For technical assistance, troubleshooting, or further inquiries, please contact Tera customer support. Contact information can be found on the official Tera websito o nella guida rapida.
