1. Introduzione
Thank you for choosing the CAMECHO 11.6-inch Portable Monitor. This manual provides essential information for the proper setup, operation, and maintenance of your device. Please read it thoroughly before use to ensure optimal performance and longevity.
This monitor features a Full HD 1920x1080 display, built-in dual speakers, and versatile connectivity options including HDMI, VGA, AV, BNC, and USB. It is designed for a wide range of applications, from PC and gaming to CCTV surveillance and vehicle systems.
Image 1.1: CAMECHO 11.6-inch Portable Monitor with included remote control.
2. Contenuto della confezione
Si prega di controllare la confezione per verificare la presenza dei seguenti elementi:
- 1 x CAMECHO 11.6-inch Portable Monitor
- 1 x EU Plug Power Cable
- 1 cavo HDMI
- 1 cavo VGA
- 1 x cavo AV
- 1 cavo BNC
- 1 x adattatore di alimentazione
- 1 x telecomando
- Staffa di montaggio 1 x
- 1 x Base Stand
- 1 x Tastiera
3. Caratteristiche del prodotto
- Display: 11.6-inch IPS screen with Full HD 1920x1080 resolution.
- Proporzioni: 16:9 for wide-screen viewing.
- Connettività: Multiple input ports including HDMI, VGA, AV, BNC, and USB.
- Audio: Integrated dual speakers for clear sound output.
- Compatibilità energetica: Supports DC12V-24V power input, suitable for various vehicle types.
- Versatilità: Ideal for PC, DVD, TV, CCTV surveillance, and vehicle backup camera systems.
- Modalità di visualizzazione: Supports copy mode, extend mode, and only mode for flexible use with computers.
Immagine 3.1: posteriore view of the monitor highlighting the built-in dual speakers.
4. Configurazione e installazione
4.1 Montaggio del supporto
- Attach the mounting bracket to the back of the monitor.
- Secure the base stand to the mounting bracket.
- Assicurarsi che tutte le connessioni siano strette e stabili.
Image 4.1: Visual guide for assembling the monitor stand.
4.2 Connessione ai dispositivi
The monitor offers various input ports. Identify the correct port for your device:
- HDMI: For high-definition digital video and audio from devices like PCs, game consoles (e.g., Switch), or Raspberry Pi.
- VGA: For analog video input from PCs or laptops.
- AV: For analog video and audio input from devices like DVRs or older video equipment.
- BNC: Primarily for security cameras (CCTV systems).
- USB: For connecting USB drives or card readers to display media.
- DC IN: Connect the provided power adapter here. The monitor supports 12V-24V power input.
Immagine 4.2: Passoview of monitor ports and their typical connections.
4.3 Accensione
After connecting all necessary cables, press the power button located on the monitor or use the remote control to turn on the device.
5. Istruzioni per l'uso
5.1 Selezione della sorgente di input
Use the 'MODE' button on the monitor or the remote control to cycle through available input sources (HDMI, VGA, AV, BNC, USB) until your desired source is displayed.
5.2 Navigazione nel menu
Use the 'MENU' button to access the on-screen display (OSD) menu. Navigate through options using the 'Increase' and 'Reduce' buttons. Press 'MENU' again to confirm selections or exit the menu.
5.3 Display Modes (for PC connection)
When connected to a computer, the monitor supports various display modes:
- Modalità di copia: Duplicates your computer's display on the monitor.
- Modalità estesa: Extends your computer's desktop, allowing for more screen space.
- Only Mode: Displays content only on the portable monitor, turning off the computer's primary display.
Immagine 5.1: Es.amples of display modes with a laptop connection.
5.4 Applicazioni
The CAMECHO 11.6-inch monitor is suitable for a variety of uses:
- Attività commerciale: Use as a secondary display for meetings or presentations.
- Divertimento: Connect to gaming consoles or media players for movies and games.
- Sorveglianza: Integrate with CCTV systems for monitoring security feeds.
- Vehicle Systems: Compatible with 12-24V systems for use in trucks, buses, or cars.
Image 5.2: Various application scenarios for the portable monitor.
Image 5.3: The monitor supports 12-24V power, making it suitable for a range of vehicles.
6. Manutenzione
6.1 Pulizia dello schermo
Per pulire lo schermo, strofinarlo delicatamente con un panno morbido e privo di lanugine. Per macchie ostinate, strofinare leggermenteampen the cloth with water or a screen-safe cleaning solution. Avoid using harsh chemicals, abrasive materials, or spraying liquid directly onto the screen.
6.2 Cura generale
- Tenere il monitor lontano dalla luce solare diretta, da calore eccessivo e dall'umidità.
- Evitare di posizionare oggetti pesanti sul monitor.
- Do not block the ventilation openings on the back of the monitor.
- Disconnect the power adapter during thunderstorms or when not in use for extended periods.
7. Risoluzione Dei Problemi
| Problema | Possibile causa | Soluzione |
|---|---|---|
| Nessuna immagine sullo schermo | Nessuna alimentazione; Sorgente di ingresso errata; Collegamento del cavo allentato | Check power adapter connection; Select correct input source; Ensure video cables are securely connected. |
| Nessun suono | Volume too low; Muted; Incorrect audio source; Cable issue | Increase volume; Unmute; Ensure audio is enabled on the source device; Check audio cable (if applicable). |
| Immagine tremolante o distorta | Loose cable; Interference; Resolution mismatch | Check video cable connections; Move away from other electronic devices; Adjust resolution on source device to 1920x1080. |
| Il telecomando non funziona | Dead batteries; Obstruction; Out of range | Replace batteries; Remove obstructions between remote and monitor; Ensure you are within range and pointing correctly. |
8. Specifiche
- Marca: CAMECHO
- Modello: K0202UK-Monitor
- Dimensioni dello schermo: 11.6 pollici
- Tipo di pannello: Informazione pubblica
- Risoluzione: 1920x1080 (Full HD)
- Proporzioni: 16:9
- Luminosità: 355 cd/m²
- Rapporto di contrasto: 2536:1
- Tempo di risposta: 3 millisecondi
- Frequenza di aggiornamento: Frequenza 60 Hz
- Video Interfaces: HDMI, VGA, AV, BNC, USB
- Audio: Built-in Dual Speakers, Headphone Output
- Potenza in ingresso: DC12V-24V
- Consumo energetico: 6W
- Colore: FULLCOLOR
- Superficie dello schermo: Opaco
Image 8.1: Energy efficiency label for the CAMECHO monitor.
9. Garanzia e supporto
9.1 Informazioni sulla garanzia
This CAMECHO monitor comes with a Garanzia del produttore di 1 anniLa presente garanzia copre i difetti di materiali e fabbricazione in condizioni di normale utilizzo. Si prega di conservare la prova d'acquisto per eventuali reclami in garanzia.
9.2 Assistenza clienti
For any questions, technical assistance, or warranty inquiries, please contact CAMECHO customer support. We aim to respond to all online inquiries within 24 hours.
E-mail: CAMECHOVIP@126.com
