L80 Series Formula Typing Wireless Mechanical Keyboard
User Guide

Start Reading
Please read this manual guide and cautions to ensure that using this product correctly.
Details

A .Type-C Port
B. Indicator
C . Feet
D. Mode Switch
E . Silicone Pads

Product Specification

Product Name: LIME 80
Keyboard Type: Mechanical Keyboard
Key Quantity: 83 Keys
Keyboard Material: ABS Case + PBT
Keycaps Character Technology Dye Sublimation
Large Key Structure: Costar
Stabilizers Rating: 5V-1A
Connect Interface: USI3 Type-C Cable
Length: 180cm
Dimensions: 325.162,45mm
Origin: Shenzhen, China
Web: www. IQUNIX.store
Support E-mail: support@iqunix.store
Three Ways of Connecting Devices
Bluetooth Connection Mode

Three Ways of Connecting Devices

Bluetooth Connection Mode

1. Toggle the keyboard Mode and Switch to the wireless side
2. Press FN+1, then hold FN+1 for 5 seconds if the Indicator blinks in blue light. (Bluetooth matching mode on when blue light blinks.)
3. Enable Bluetooth matching (Computer / Phone / Tablet)
4. Select the matching device (IQUNIX LIME80 BT 1]
5. Indicator light turning off when matching successfully.

 If you need to connect a new device, please hold FN+1 for 5 seconds to remove the previous device. When the LED indicator blinks blue light, you can connect your device following Step 3.

2.4GHz Connection Mode

1. Toggle the keyboard Mode Switch to the wireless side.
2. Plug the 2.4GHz receiver into your computer.
3. Press FN+4 to enter 2.4GHz matching mode (2.4GHz matching mode on when pink light blinks.)
4. The indicator light turning off means successful matching.

Wired Connection Mode

For Wireless Version, toggle the keyboard

1. Mode Switch to wired side.
2. Plug the USB cable into your device.

 Function Keys Combinations

LED Indicator Keys Combinations (RGB Version)

Special Keys Combinations (Hold for 5 seconds)
Special Keys Combinations us (Wireless Mode)

LED Indicator Status Description

Device Charging and Battery Status

Bluetooth Device Matching
Special Status
2.4GHz Mode

Mac / Windows Layout Switch

Hold for 5 seconds to switch the layout between macOS and Windows systems.

To learn more details, please reach out to us on the official website or on social media. Official website: www.IQUNIX.store
Follow us: @ IQUNIXDownload IQUNIX Official App

https://www.iqunix.com/downloadh5.html

(Brand: IQUNIX
Origin: China
Shenzhen Silver Storm Technology Co., Ltd.
400-1788-905
