intratone 17-0263 Dina Create 4G Video Intercom
AUDIO CALL
VIDEO CALL
 |
 |
 |
|
In The Box
Tools Needed
Dimension
Product Description
Wire Connection
| MAGNET LOCK | ELECTRIC LOCK |
 |
 |
| MAGNET LOCK | ELECTRIC LOCK |
|
|
LEDs
DIAGNOSTIC
 |
Init of the module |
 |
Searching for network |
 |
NO VIDEO CALL |
LED Connection
| Technical specifications : | ||
| Operating voltage | 12 — 24Vc.c | |
| Radio frequency characteristics | E-GSM900 (880 — 915MHz) | +31.2dBm |
| DCS1800 (1710 — 1785MHz) | +28.1dBm | |
| band VIII (880-915MHz) | +23.6dBm | |
| band I (1920-1980MHz) | +23.3dBm | |
| bond XX (832-862MHz) | +20.5dBm | |
| bond III (1710-1785MHz) | +22.7dBm | |
| bond VII (2500-2570MHz) | +22.3dBm | |
| Storage Temperatures range | -10 to +40°C | |
| Operating Temperatures range | -10 to +40°C | |
| Operating environment | IP54 | |
| Dimensions | 90*183*72.5 | |
Customer Support
Warranty operating guarantees:
The 4G IP V2 transmission module is guaranteed within a temperature range of -10°C and +40°C and at a relative humidity level not exceeding 70%. It must be installed according to the Top/Bottom directions given in these instructions and on the device.
The installation must be carried out by qualified personnel with the necessary knowledge for a safe assembly of the equipment.
This kit includes the necessary elements to ensure a safe installation of the equipment.
The equipment must be installed in an area where access is limited (technical room, height …) to qualified personnel.
Finland, Norway, Sweden : Do not install outside because of extreme temperature
End-of-life recycling of the product:
The 4G IP V2 transmission module and its accessories must not be discarded with unsorted municipal waste, but must be disposed of via the WEEE (Waste Electrical and Electronic Equipment) collection and recycling system.
Simplified declaration of conformity
The undersigned, COGELEC, declares that access control type radio equipment for collective housing is in compliance with the Radio Equipment Regulations 2017. The full text of the declaration of conformity is available at the following internet address: http://certificates.intratone.com/
Simplified declaration of conformity
The undersigned, COGELEC, declares that access control type radio equipment for collective housing is in compliance with Directive 2014/53 / EU (RED).The full text of the EU declaration of conformity is available at the following internet address: http://certificates.intratone.com/
