Perkenalan
This manual provides detailed instructions for the safe installation, operation, and maintenance of your WAC Lighting Ion 2in LED Round Recessed Light. Please read this manual thoroughly before installation and retain it for future reference.
Informasi Keselamatan Penting
- PERINGATAN: Risiko sengatan listrik. Putuskan sambungan daya pada sekring atau pemutus arus sebelum memasang atau menyervis.
- PERINGATAN: Risk of fire. Use only with specified dimmers.
- Pemasangan harus dilakukan oleh teknisi listrik yang berkualifikasi sesuai dengan Kode Kelistrikan Nasional dan kode setempat.
- Pastikan semua sambungan listrik terpasang dengan aman dan terisolasi dengan benar.
- Do not modify the fixture. Any modifications may void the warranty and create safety hazards.
- Suitable for wet locations, IC-Rated for direct contact with insulation, and Airtight.
- Volume operasitage: 120V-277V AC.
Isi Paket
Confirm all components are present before beginning installation.
- LED Light and Trim
- LED Driver and Cable
- Housing or Frame-in Kit (New Construction)
- Paket Perangkat Keras Pemasangan
- Instruksi Manual (dokumen ini)
Pengaturan dan Instalasi
This section outlines the steps for installing your WAC Lighting Ion recessed light. A frame-in kit is included for new construction installations.
1. Prepare the Installation Area
Ensure power is disconnected at the circuit breaker. Identify the desired location for the fixture. This fixture requires a 3-inch round ceiling cutout. The ceiling thickness should be between 0.5 inches and 1.5 inches.
This image displays a technical diagram with dimensions for the frame-in kit and the driver box. It shows the overall length of the frame-in kit, the cutout size, and the dimensions of the external driver box, including its height and width.
2. Install the Frame-in Kit (New Construction)
Position the frame-in kit in the ceiling joists. Secure the frame-in kit using appropriate mounting hardware. The adjustable bars allow for flexible positioning between joists.
This image illustrates the main components of the WAC Lighting Ion recessed light: the metal frame-in kit, the separate driver box with wiring, and the round LED light engine with retention clips. It shows how the driver box connects to the light engine and how the frame-in kit supports the entire assembly.
3. Sambungan Listrik
The driver box includes 5 knockouts for electrical connections. Connect the universal input driver (120V-277V) to the main power supply according to local electrical codes. Use the male-to-female quick connect locking cable to join the light engine to the driver box.
4. Install the Light Engine
Once the frame-in kit is secured and electrical connections are made, insert the LED light engine into the 3-inch ceiling cutout. The retention clips on the light engine will hold it securely in place.
Petunjuk Pengoperasian
1. Nyalakan
Restore power at the circuit breaker. The light should illuminate.
2. 5-CCT Selectable Color Temperature
The Ion fixture features a 5-CCT selectable switch located on the driver box. Before final installation of the light engine, select your desired color temperature from the following options: 2700K, 3000K, 3500K, 4000K, or 5000K. Adjust the switch to the preferred setting.
This image highlights the 5-CCT (Correlated Color Temperature) selectable switch, typically found on the driver box. It shows the different Kelvin temperature options (2700K, 3000K, 3500K, 4000K, 5000K) that can be chosen by sliding the switch.
3. Fungsi Peredupan
This fixture is compatible with electronic low voltage (ELV) or TRIAC dimmers. It provides smooth and continuous dimming. With ELV dimmers, it dims down to 10%, and with TRIAC dimmers, it dims down to 5%.
Pemeliharaan
- Ensure power is off before performing any maintenance.
- Bersihkan perlengkapan tersebut dengan kain lembut dan kering. Jangan gunakan pembersih abrasif atau pelarut.
- The LED module is replaceable, with a rated life of 50,000 hours. Contact WAC Lighting for replacement parts if needed.
Penyelesaian Masalah
| Masalah | Kemungkinan Penyebab | Larutan |
|---|---|---|
| Lampu tidak menyala. | Tidak ada catu daya. Sambungan kabel longgar. Faulty switch or dimmer. |
Periksa pemutus arus dan sakelar dinding. Pastikan semua sambungan kabel aman. Test with a known working switch or bypass the switch temporarily. |
| Lampu berkedip-kedip atau redup secara tidak konsisten. | Dimmer tidak kompatibel. Kabel longgar. Sirkuit kelebihan beban. |
Ensure dimmer is ELV or TRIAC compatible. Periksa semua koneksi kabel. Reduce load on the circuit or consult an electrician. |
| Suhu warna salah. | Sakelar CCT diatur secara tidak benar. | Turn off power, access the driver box, and adjust the 5-CCT selectable switch to the desired setting. |
Spesifikasi
- Model: R2DRDN-F9CS-WT
- Merek: Pencahayaan WAC
- Jenis: 2in LED Round Recessed Light
- Kekuatan: 9W
- Lumen yang Dikirim: 725lm
- CRI: 90
- Nilai Jam: 50,000
- Suhu Warna: 5-CCT Selectable (2700K, 3000K, 3500K, 4000K, 5000K)
- Jil.tage: 120V-277V Universal
- Peredupan: ELV (to 10%), TRIAC (to 5%)
- Ukuran Potongan: 3 inci (bulat)
- Ketebalan Plafon: 0.5 inci hingga 1.5 inci
- Bahan: Die-cast aluminum with 20-gauge steel driver box
- Sertifikasi: ETL & cETL UL #1598, IC-Rated, Airtight, CEC Title 24 Compliant, Energy Star 2.0 Certified, Title 24 JA8-2016
- Pemakaian Dalam/Luar Ruangan: Dalam Ruangan, Luar Ruangan (Terdaftar untuk Lokasi Basah)
- Dimensi Produk: 12.4"L x 10.43"W x 4.25"H (Frame-in kit and driver box)
Garansi dan Dukungan
This WAC Lighting product is covered by a 5-year manufacturer's warranty. For warranty claims or technical support, please contact WAC Lighting customer service. Retain your proof of purchase for warranty validation.
For additional information or support, visit the official WAC Lighting websitus atau hubungi departemen layanan pelanggan mereka.
WAC Lighting is a registered trademark. All rights reserved.
