FUVISION 4G LTE Cellular Trail Camera User Manual

Perkenalan

Thank you for choosing the FUVISION 4G LTE Cellular Trail Camera. This manual provides detailed instructions for setting up, operating, and maintaining your camera to ensure optimal performance. This camera is designed for remote monitoring of wildlife, property, or other outdoor areas, offering high-resolution imaging and cellular connectivity for real-time alerts and viewing.

Apa yang ada di dalam kotak

Carefully unpack all components and check for any damage. If any items are missing or damaged, please contact customer support.

• 1 x 4G LTE Cellular Trail Camera
• 1 x 5W Solar Power Panel
• 1 x Bracket for solar panel
• 1 x Detailed user manual (this document)
• Rechargeable Batteries (pre-installed or included separately)

Image: All components included in the package, laid out on a table.

Produk Selesaiview

The FUVISION 4G LTE Cellular Trail Camera is a robust and versatile device designed for outdoor surveillance. It features a durable, camouflage-patterned casing, an integrated solar panel for continuous power, and advanced imaging capabilities.

Fitur Utama:

• Konektivitas 4G LTE: Enables remote viewing and direct app notifications without Wi-Fi.
• Pengambilan Gambar Resolusi Tinggi: 2.7K Ultra HD video and 14MP photos for clear imaging.
• Penglihatan Malam: Enhanced low-light night vision for clear recordings in darkness.
• Kecepatan Pemicu Cepat: 0.2-second trigger speed to capture fast-moving subjects.
• Dual Activation: Triggered by PIR motion or via the mobile app.
• Tenaga Berkelanjutan: 7800mAh battery with a 5W solar panel for extended operation.
• Desain Tahan Lama: Peringkat tahan air IP67 untuk penggunaan di luar ruangan.
• Opsi Penyimpanan: Supports up to 128GB Micro SD cards (not included) and offers cloud storage.

Image: Visual representation of the camera's key functionalities, including its robust design and connectivity features.

Panduan Pengaturan

Follow these steps for the initial setup of your FUVISION Trail Camera.

1. Unboxing dan Pengecekan Komponen

Refer to the 'What's in the Box' section to ensure all components are present.

2. Pemasangan Baterai dan Kartu SIM

1. Open the camera's latch to access the battery compartment.
2. Ensure the 7800mAh rechargeable batteries are correctly inserted.
3. Insert the pre-installed SIM card into its designated slot. Note: This camera works with the pre-installed SIM card only.
4. Close the compartment securely to maintain the IP67 waterproof seal.

3. Unduh dan Pasangkan Aplikasi

1. Download the official FUVISION app from your smartphone's app store (iOS compatible).
2. Open the app and follow the on-screen instructions to create an account and pair your camera.
3. Scan the QR code on the camera or follow the app's discovery process.
4. Once paired, you will receive a confirmation message.

Image: The trail camera in an outdoor setting, highlighting its 4G LTE connectivity and app control features for remote monitoring.

4. Koneksi Panel Surya

Connect the 5W solar panel to the camera's charging port. Mount the solar panel in a location that receives ample direct sunlight to ensure continuous charging of the internal battery.

Petunjuk Pengoperasian

Your FUVISION Trail Camera offers flexible operation modes for various monitoring needs.

Mode Pengambilan:

• PIR Motion Trigger: The camera automatically captures photos or videos when motion is detected by the Passive Infrared (PIR) sensor.
• App Activation: Manually trigger photo or video capture, or initiate live streaming directly from the mobile app.

Image: The camera can be activated by motion detection or controlled remotely via the mobile application for real-time monitoring.

Viewing and Storage:

• Siaran Langsung: Access 2.7K live video feed through the app.
• Photo/Video Playback: View captured 14MP photos and 2.7K videos directly from the app.
• Penyimpanan Lokal: Recordings are saved to a Micro SD card (up to 128GB, not included).
• Penyimpanan Awan: Utilize the 30-day free trial for cloud storage and playback functionality.

Gambar: Examples of the high-resolution photo (14MP) and video (2.7K UHD) capabilities of the camera, showcasing detailed captures of wildlife.

Penglihatan Malam:

The camera is equipped with enhanced non-glow night vision, allowing it to capture clear images and videos in complete darkness without emitting visible light that could disturb wildlife.

Image: The camera's night vision captures clear images of animals in low-light conditions, making it difficult for them to detect the camera.

Pemeliharaan

Proper maintenance ensures the longevity and optimal performance of your trail camera.

Pembersihan:

• Wipe the camera lens and solar panel regularly with a soft, clean cloth to remove dust and debris.
• Jangan gunakan pembersih atau pelarut yang bersifat abrasif.

Manajemen Baterai:

The integrated 5W solar panel helps maintain the 7800mAh battery charge. For best results, ensure the solar panel is positioned to receive maximum sunlight. If the camera is stored for extended periods, fully charge the batteries before storage and recharge periodically.

Image: The camera's solar panel provides continuous power, ensuring extended operation in the field.

Penyimpanan:

When not in use, store the camera in a cool, dry place away from direct sunlight and extreme temperatures.

Penyelesaian Masalah

Jika Anda mengalami masalah dengan kamera Anda, lihat masalah umum dan solusi berikut:

Spesifikasi

Garansi dan Dukungan

FUVISION products are designed for reliability and performance. For warranty information and technical support, please refer to the contact details provided with your purchase or visit the official FUVISION weblokasi.

Untuk bantuan tambahan, Anda juga dapat merujuk ke Panduan Pengguna (PDF) tersedia daring.
