1. Pendahuluan
Terima kasih sudah membeliasing the ZDK Mini Projector, Model GC03. This portable projector is designed to provide a versatile and immersive viewing experience, supporting native 1080P Full HD resolution and offering wireless connectivity options. With its compact design and multiple input interfaces, it is ideal for home entertainment, outdoor movie nights, and presentations. Please read this manual thoroughly before operating the device to ensure proper use and to maximize its performance and longevity.
Figure 1: ZDK Mini Projector showcasing its key features including WiFi connectivity, 1080P support, 4K HDMI compatibility, and up to 200-inch display capability.
2. Isi Paket
Harap periksa isi paket saat membuka kotak untuk memastikan semua barang ada:
- ZDK Mini Video Projector (Model GC03)
- Kontrol Jarak Jauh
- Adaptor DC
- Kabel HDMI
- AV Kabel
- User Manual (dokumen ini)
3. Panduan Pengaturan
3.1 Sambungan Daya
- Connect the DC Adapter to the projector's DC IN port.
- Plug the DC Adapter into a power outlet.
- Tekan tombol daya pada proyektor atau remote control untuk menghidupkan perangkat.
3.2 Placement and Focus Adjustment
Place the projector on a stable, flat surface. The optimal projection distance ranges from 0.8 to 5 meters, yielding a screen size of 30 to 300 inches. Adjust the focus ring on the projector lens until the image appears clear and sharp on the screen or wall.
Figure 2: Visual comparison demonstrating the superior brightness (10000 Lumens) and resolution (1080P) of the ZDK Projector compared to a typical 5000 Lumens, 720P projector.
3.3 Pilihan Konektivitas
The ZDK Mini Projector offers various connectivity options for different devices:
- HDMI: Connect TV sticks, laptops, PCs, gaming consoles (PS5), or DVD players using the provided HDMI cable.
- Kabel USB: Insert a USB flash disk to play media files secara langsung.
- DARI: Use the AV cable to connect older devices with AV output.
- Wi-Fi (Screen Mirroring): Wirelessly connect your iOS or Android smartphone/tablet for screen mirroring.
Gambar 3: Lebihview of the projector's input interfaces and examples of compatible devices, including HDMI, USB, and AV connections.
4. Petunjuk Pengoperasian
4.1 Menavigasi Menu
Use the remote control or the buttons on top of the projector to navigate the on-screen menu. The directional arrows allow you to move through options, and the OK/Enter button confirms selections. The Back button returns to the previous screen.
4.2 Memilih Sumber Input
From the main menu, select the desired input source (e.g., HDMI, USB, AV, Screen Mirroring) corresponding to your connected device.
4.3 Pencermian Layar Nirkabel (iOS/Android)
To mirror your smartphone or tablet screen wirelessly:
- Select the "Screen Mirroring" or "WiFi Display" option from the projector's input menu.
- Pastikan perangkat seluler Anda dan proyektor terhubung ke jaringan Wi-Fi yang sama.
- On your iOS device, open Control Center and tap "Screen Mirroring" or "AirPlay Mirroring," then select the projector's name.
- On your Android device, go to Settings > Connected devices > Connection preferences > Cast (or similar, depending on your device model), then select the projector's name.
- The mobile device's screen should now be displayed on the projector.
Figure 4: Demonstration of wireless screen mirroring functionality, allowing seamless projection from iOS and Android smartphones.
Note: For cable connection with smartphones, an additional HDMI adapter (Lightning to HDMI for iOS, Micro USB/Type C to HDMI for Android) is required and not included.
Figure 5: Illustrates the necessary adapters for wired smartphone connectivity to the projector. These adapters must be purchased separately.
4.4 Adjusting Projection Size and Aspect Ratio
The projector supports a zoom function to manually adjust the image size from 100% to 75%. This can be done via the projector's menu settings. The standard picture format is 16:9, and it is compatible with 4:3 aspect ratios.
5. Pemeliharaan
5.1 Membersihkan Lensa
Gunakan kain lembut dan bebas serat yang dirancang khusus untuk lensa optik untuk menyeka lensa proyektor dengan lembut. Hindari penggunaan pembersih abrasif atau tekanan berlebihan, karena dapat menggores lensa.
5.2 Membersihkan Badan Proyektor
Wipe the exterior of the projector with a soft, dry cloth. Do not use liquid cleaners or sprays directly on the projector.
5.3 Ventilasi
Ensure the projector's ventilation vents are not blocked to prevent overheating. The projector features an advanced fan cooling system designed for efficient heat dissipation and extended lamp life (up to 60,000 hours).
6. Penyelesaian masalah
| Masalah | Kemungkinan Penyebab | Larutan |
|---|---|---|
| Tidak ada gambar di layar |
|
|
| Gambar buram |
|
|
| Tidak ada suara |
|
|
| Pencerminan layar tidak berfungsi |
|
|
7. Spesifikasi
| Merek | ZDK |
| Nomor Model | GC03 |
| Dimensi Produk | Ukuran 15.49x11.61x6.81 cm |
| Berat Barang | 898 gram (1.10 pon) |
| Teknologi Tampilan | Layar LCD |
| Resolusi Asli | 1920 x 1080 Pixels (Full HD Supported) |
| Kecerahan | 10000 lumen cahaya |
| Ukuran Proyeksi | 30-300 inci |
| Jarak Proyeksi | 0.8-5 meter |
| Rasio Aspek | 16:9 (Compatible with 4:3) |
| Konektivitas | Wi-Fi, HDMI, USB, AV |
| Lamp Kehidupan | Hingga 60,000 jam |
| Speaker internal | Ya |
| Sumber Daya | Power line (120 Volts) |
| Opsi Pemasangan | Ceiling Mount, Wall Mount, Tripod Mount, Tabletop |
Figure 6: The ZDK Mini Projector's compact and lightweight design makes it highly portable, easily fitting into a backpack for on-the-go entertainment.
8. Garansi dan Dukungan
ZDK provides after-sales service for its products. If you encounter any issues or have questions regarding your ZDK Mini Projector, please do not hesitate to contact our customer support team. We are committed to providing assistance and will respond to your inquiries within 24 hours.
For support, please refer to the contact information provided on the product packaging or the official ZDK weblokasi.
