Hunter X-Core Pro-C Irrigation Sensors
DEPENDABLE SENSOR COMBINATIONS
Maximise Your Irrigation System Management
When paired with an irrigation system, irrigation sensors ensure proper function, prevent damage, and increase water-use efficiency.
Combining sensors is a key practice utilized to maximise irrigation system management. Consider combining an atmospheric sensor, such as a rain, freeze, or wind sensor, with a soil moisture sensor to prevent irrigation from occurring when not needed.
By pairing an ET sensor input with a soil moisture sensor, you can maximise your water savings within any project.
Adding flow sensing, monitoring, and/or management devices along with these sensors will also protect the landscape from damage caused by catastrophic leaks and measure water consumption with water budgets in mind.
 |
Other Model
SENSOR-CONTROLLER COMPATIBILITY GUIDE
| CONTROLLERS | EPA WATERSENSE® CERTIFIED | SMART WATERMARK APPROVED | ||||||
| Explore this chart to find out which controller/sensor combination will best set your project up for lasting success! |  |
 |
||||||
| Product | Station Count | Communication | Sensor Inputs | |||||
| STANDARD | X-Core™ | 2, 4, 6, 8, Fixed | 1 | Yes, with Solar Sync™ | Yes, with Solar Sync™ | |||
| Pro-C™ | Conventional: 4 to 23, Modular
Two-wire: 4 to 32, hybrid EZDS |
2 | Yes, with Solar Sync | Yes, with Solar Sync | ||||
| HYDRAWISE | X2™ | 4, 6, 8, 14, Fixed | WAND for Hydrawise™ | 1 | Yes, with Hydrawise (no on-site ET sensor required) | Yes, with Hydrawise (no on-site ET sensor required) | ||
| HPC | Conventional: 4 to 23, Modular
Two-wire: 4 to 32, hybrid EZDS |
Integral Wi-Fi, Hydrawise | 2 | Yes, with Hydrawise (no on-site ET sensor required) | Yes, with Hydrawise (no on-site ET sensor required) | |||
| Pro-HC | 6, 12, 24, Fixed | Integral Wi-Fi, Hydrawise | 2 | Yes, with Hydrawise (no on-site ET sensor required) | Yes, with Hydrawise (no on-site ET sensor required) | |||
| HCC | Plastic Cabinet: 8 to 38, Modular
Metal Cabinet and Pedestals: 8 to 54, Modular All enclosures: 8 to 54, two-wire EZDS, WVL |
Integral Wi-Fi, Hydrawise | 2 | Yes, with Hydrawise (no on-site ET sensor required) | Yes, with Hydrawise (no on-site ET sensor required) | |||
| ADVANCED/ CENTRALUS | ICC2 | Plastic Cabinet: 8 to 38, Modular
Metal Cabinet and Pedestals: 8 to 54, Modular All enclosures: 8 to 54, two-wire EZDS, WVL |
WIFIKIT, CELLKIT,
LANKIT for Centralus™ |
1 Click or Solar Sync, 1 Flow* | Yes, with Solar Sync | Yes, with Solar Sync | ||
| ACC2 | Conventional: 12 to 54, Modular
Two-wire: 75 to 225 with ICD Decoders |
A2C-LAN, A2C-WIFI,
A2C-LTEM Modules for Centralus |
3 Clik, 1 Solar Sync, 6 Flow | Yes, with Solar Sync | Yes, with Solar Sync | |||
| BATTERY | BTT | 1, 2, Fixed | Bluetooth® for App | |||||
| NODE-BT | 1, 2, 4, Fixed | Bluetooth for App | 2 | |||||
| NODE | 1, 2, 4, 6, Fixed | 1 | ||||||
| XC Hybrid | 6, 12, Fixed | 1 | ||||||
| INTL. ONLY | Eco Logic | 4, 6, Fixed | 1 | |||||
*Centralus Comm Module Required
KNOW YOUR FLOW
Hunter offers various irrigation flow solutions to meet the needs of your project:
Flow Sensing
The Flow-Click™ is a simple and economical flow sensor that allows smaller controllers to detect high-flow conditions and automatically shut down a master valve on alarm.
Flow Management
Uses learned flow for each station to schedule valves on to reach an optimised flow target in system piping.
This allows the controller to automatically get the most watering done in the shortest amount of time, at safe velocities.
Flow Monitoring
Measures and compares actual flow from a flow sensor to the learned flows of all running stations in real time. If the actual flow exceeds the total of the running stations, the controller performs diagnostics to determine whether there is a pipe break or a malfunctioning valve. The controller can then shut down irrigation and alert the owner with the exact information required for repairs.
| COMPATIBLE SENSORS | |||||||||||||||||
| RAIN | FREEZE | WIND | RAIN/ FREEZE/WIND | SOIL | FLOW | ET | |||||||||||
| Mini-Click™ | Wireless Mini-Click™ | Rain-Click™ | Wireless Rain-Click | Freeze-Click™ | Wind-Click | Mini Weather Station | Soil-Click™ | SC-Probe | Flow-Click™
(Flow sensing) |
HFS (Flow management) | Wireless HFS
(Flow management) |
HC Flow Meter
(Flow monitoring) |
Wireless HC Flow Meter
(Flow monitoring) |
Solar Sync
(Includes Rain/Freeze-Click) |
Wireless Solar Sync
(Includes Rain/Freeze-Click) |
Hydrawise | |
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | |||||||
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | |||||||
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ |  |
||||||||
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ |  |
||||||
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | |
||||||
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | |
||||||
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ |
|
 |
|
|
⬤ | ⬤ | |||
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | |||||
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ||||||||||||
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | |||||||||||||
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | |||||||||||||
| ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | ⬤ | |||||||||
⬤ Compatible Compatible with CELLKIT Compatible with Wi-Fi Compatible with WAND
Does your project require more sensors than an irrigation controller accepts?
In some scenarios, projects require more sensor inputs than an irrigation controller allows for. If this is the case, a
sensor may be installed as a common wire interrupt in order to bypass the need for a sensor terminal. This option works best with Soil-Click and Flow-Click Sensors. Simply wire the common wire of the valves/zone associated with the sensor, as shown below.
Smart Irrigation Control with ET Input
Hunter offers two EPA Water Sense-certified ET solutions delivering state-of-the-art smart irrigation control. Choose the solution that works best for your project.
Solar Sync
- On-site wired or wireless sensor
- Adjusts station run times automatically based on solar intensity and temperature readings
- Includes built-in rain and freeze sensors
Hydrawise
- Adjusts station run times and irrigation frequency based on hyperlocal weather data from the internet
- Prevents unnecessary watering with customised predictive watering and forecasting
- Includes Hydrawise remote irrigation monitoring and management
Helping our customers succeed is what drives us. While our passion for innovation and engineering is built into everything we do, it is our commitment to exceptional support that we hope will keep you in the Hunter family of customers for years to come.
