Manual
Desktop 2D
Multidimensional Code
Reader
HD202
Specifications:
- Warranty: 2 years
- Light Source: 630nm LED Laser +/- 10nm
- Sensor: CMOS
- Scanning method: automatically (when you bring the code closer)
- Interface: USB, Virtual COM
- Cable length: 200 cm
- Ingress protection: IP54
- Device dimensions: 5.5 x 4.5 x 2 cm
- Package dimensions: 21.5 x 10 x 7.5 cm
- Device weight: 110 g
- Weight with packaging: 190 g
- Operating temperature: 0 to 45°C
- Storage temperature: -20 to 70°C
- Operating Humidity: 5 to 95%
- Storage Humidity: 5 to 95%
- 1D Code Readable: CodaBar, Code 11, Code 32, Code 39, Code 93, Code 128, IATA 2 of 5, Interleaved 2 of 5 (ITF), GS1 DataBar, HongKong 2 of 5, Matrix 2 of 5, MSI Plessey, NEC 2 of 5, Pharmacode Plessey, Straight 2 of 5, Telepen, Trioptic, UPC/EAN/JAN, Codablock F, microPDF, GS1 Composite
- 2D Readable Codes: MaxiCode, DataMatrix (ECC 200), QR Code, microQR, Aztec, HanXin, GoCode
Set contents:
- Stationary multidimensional code reader
- USB cable
- Manual
Features:
- Scanning: Automatic (when you hold the code)
- Type of barcodes scanned: 1D and 2D barcodes, including QR and Aztec, from paper labels and phone screens
- Interface: USB, Virtual COM
- Ingress protection: IP54
Factory Setting
Interface configuration
Baud
Barcode scanning modes
Add trailing characters to a barcode
Reading inverted codes
Light signal settings
- Light signal brightness setting
Beep settings
- Beep duration
Delay scanning the same barcode
Hide trailing barcode characters
Adding Prefix and Sufix
- Prefix setting:
Suffix setting
Barcode settings
Numeric codes
