Sissejuhatus
This manual provides detailed instructions for the VENTION External USB DAC 7.1 Sound Card (Model CVAB0). This device enhances your audio experience with virtual 7.1 surround sound, high-fidelity 24-bit/192kHz audio, and versatile connectivity, making it suitable for gaming, movies, and general audio use across various platforms.
Pildi kirjeldus: Esikülg view of the VENTION External USB DAC 7.1 Sound Card, showcasing its sleek design and dynamic RGB lighting. The device features a central control knob and several buttons for audio adjustments.
Toote omadused
- Immersive 7.1 Virtual Surround Sound: Utilizes advanced audio processing for virtual 7.1 surround sound, providing an immersive listening experience for gaming and movies by clearly distinguishing sounds from different directions.
- Kõrge täpsusega heli: Supports 24-bit/192kHz high-resolution audio with a professional DSP sound card chip, ensuring clear, detailed, and rich sound quality.
- Mitmekülgne ühenduvus: Equipped with USB-C and three 3.5mm jacks (for microphone, headphones, and other audio devices). Supports both TRS and TRRS microphones.
- Lai ühilduvus: Compatible with PCs, laptops, gaming consoles (PS5, PS4, Xbox One, Nintendo Switch), and speaker systems. Driver-free support for Windows 8/8.1/10/11, Mac OS, and Linux systems.
- Powerful Sound Adjustment and Control: Features an independent equalizer with 16 preset sound effects. Includes volume control, one-click mute, and one-click switching between Game, Movie, and Standard audio modes.
- Optimeeritud mängimiseks: Precise sound effects help capture key audio cues in games, improving reaction times. Four additional game sound effects are available.
- Dual Output Support: Allows simultaneous connection of headphones and external speakers.
- RGB valgustus: Features vibrant RGB lighting, specifically designed to enhance your gaming setup.
- Easy Software Installation: Install the VENTION Audio Center software for full audio performance and customization. The software supports multiple languages.
Seadistamine
1. Riistvara ühendus
- Connect the VENTION External USB DAC to your computer or gaming console using the provided USB-C cable.
- Ühendage kõrvaklapid kõrvaklappide pesasse.
- If using a microphone, connect it to the microphone jack.
- For external speakers, connect them to the audio output jack.
Pildi kirjeldus: A diagram illustrating the available ports on the VENTION sound card, including the microphone input, headphone connection, and a general audio interface for headphones or speakers. It highlights the dual output capability.
2. Driver Installation (Optional for Full Features)
The device supports driver-free operation on Windows 8/8.1/10/11, Mac OS, and Linux for basic functionality. However, to unlock the full performance, including virtual 7.1 surround sound and advanced equalizer settings, it is recommended to install the VENTION Audio Center software.
- Visit the official VENTION website to download the latest VENTION Audio Center software.
- Installimise lõpuleviimiseks järgige ekraanil kuvatavaid juhiseid.
- Taaskäivitage arvuti, kui seda küsitakse.
Pildi kirjeldus: A compatibility chart detailing various 3.5mm jack devices (headphones, headsets, speakers, microphones, audio cables) and USB-connected devices (laptops, desktops, PS4/PS5, Switch). It also lists supported operating systems: macOS, Windows, and Linux.
Kasutusjuhised
1. Põhilised juhtnupud
- Helitugevuse juhtimine: Use the central knob to adjust the master volume.
- Vaigistamise funktsioon: Press the dedicated mute button to quickly mute/unmute audio.
- Mikrofoni vaigistamine: Press the microphone mute button to mute/unmute your microphone.
2. Helirežiimid
The sound card offers three distinct audio modes for different scenarios. Press the mode button to cycle through them:
- Mängurežiim: Enhances gaming positioning and sound effects for a more immersive and competitive experience.
- Filmi režiim: Optimized for cinematic audio, providing a rich and enveloping soundstage filmide jaoks.
- Standardrežiim: A balanced audio profile suitable for music listening, calls, and general use.
Pildi kirjeldus: An illustration depicting the three one-touch switchable audio modes: Game Mode for enhanced positioning, Movie Mode for immersive viewing and listening, and Standard Mode for clear music and calls.
3. Game/Voice Volume Control
The device features independent control for game audio volume and voice chat volume.
- Mängu helitugevuse reguleerimine: Press and hold the "GAME VOL" button to increase the game volume (main application) and decrease the voice chat volume (secondary application).
- Adjusting Voice Volume: Conversely, press and hold the "VOICE VOL" button to increase the voice chat volume and decrease the game volume accordingly.
Pildi kirjeldus: A visual representation of the Game Volume and Voice Volume controls, indicating how to adjust the balance between game audio and voice chat.
4. VENTION Audio Center Software
Once installed, the VENTION Audio Center software provides advanced customization options:
- Equalizer: Fine-tune audio frequencies with the independent equalizer, offering 16 preset sound effects.
- 7.1 Ruumiline heli: Enable and configure the virtual 7.1 surround sound feature for precise directional audio.
- Gaming Sound Effects: Access and apply four additional game-specific sound effects (FPS, RPG, MMORPG, Sports).
Pildi kirjeldus: A screenshot of the VENTION Audio Center software interface, showing the independent equalizer adjustment with various frequency bands and 16 sound effects. It also highlights four new game sound effects: FPS, RPG, MMORPG, and Sports.
Pildi kirjeldus: A gamer using a headset in front of a monitor, with an overlay indicating "7.1 Gaming Sound Channels." The text emphasizes precise distinction of footsteps, shots, and environmental sounds for complex game battles. A note below mentions that the virtual 7.1 surround sound function requires the VENTION Audio Center software.
Hooldus
- Hoidke seadet puhtana, pühkides seda pehme kuiva lapiga. Vältige vedelate puhastusvahendite kasutamist.
- Hoidke seadet jahedas ja kuivas kohas, eemal otsesest päikesevalgusest ja äärmuslikest temperatuuridest.
- Vältige seadme maha pillamist või tugevate löökide allutamist.
- Veenduge, et kaablid oleksid kindlalt ühendatud, kuid mitte liigse jõuga, et vältida portide kahjustamist.
Veaotsing
- Heliväljund puudub:
- Check all cable connections (USB, headphones, speakers).
- Ensure the device is selected as the default audio output in your operating system's sound settings.
- Verify that the volume is not muted on the device or in your system settings.
- If using the VENTION Audio Center software, ensure it is correctly installed and configured.
- Mikrofon ei tööta:
- Ensure the microphone is properly connected to the correct jack.
- Check if the microphone is muted on the device or in your system's sound input settings.
- Verify that the VENTION device is selected as the default input device.
- Confirm your microphone type (TRS/TRRS) is compatible.
- Tarkvara/draiveri probleemid:
- If experiencing issues with advanced features (e.g., 7.1 surround sound, equalizer), ensure the VENTION Audio Center software is installed correctly and is up to date.
- Try reinstalling the software if problems persist.
- Consult the VENTION support website for the latest drivers and troubleshooting guides.
- Halb helikvaliteet:
- Ensure you are using high-quality audio sources.
- Check your equalizer settings in the VENTION Audio Center software; reset to default if necessary.
- Test with different headphones/speakers to rule out issues with peripherals.
Tehnilised andmed
| Kaubamärk | Vention |
| Mudeli number | CVAB0 |
| Liides | USB 3.0 (USB-C connection) |
| Heliväljundi režiim | 7.1 Virtuaalne ruumiline heli |
| Max Samplingi määr | 192 kHz / 24-bitine |
| Ühilduvad seadmed | PS5, PS4, Xbox One, Nintendo Switch, PC, Headphones |
| Ühilduvad platvormid | Windows 8/8.1/10/11, Mac OS, Linux |
| Riistvara platvorm | Personaalarvuti |
Pildi kirjeldus: A close-up image of a DSP (Digital Signal Processor) sound card chip, emphasizing the high-quality sound capabilities. The text highlights that with a DSP sound card chip, the 192kHz@24bit sampling rate offers higher audio resolution and a wider dynamic range than standard CD quality (44.1kHz@16bit).
Garantii teave
Specific warranty details for the VENTION External USB DAC 7.1 Sound Card (Model CVAB0) are typically provided with the product packaging or on the official VENTION webveebisait. Kõige täpsemate ja ajakohasemate garantiitingimuste saamiseks vaadake palun neid allikaid.
Toetus
For technical support, product inquiries, or further assistance, please visit the official VENTION support website. You can usually find contact information, FAQs, and additional resources there.
Interneti-ressursid:
- Official VENTION Websait: www.ventiontech.com (või asjakohane piirkondlik sait)
- Product Support Page: Check the VENTION website for a dedicated support page for model CVAB0.
