1. Producto terminadoview
The ACEFAST A55 USB C Charger Block is a 30W fast wall charger featuring a unique crystal design and an intelligent LED screen display. Engineered with the latest GaN chipset, it provides efficient and rapid charging for a wide range of devices, including smartphones, tablets, and laptops. Its compact and foldable design makes it ideal for both home and travel use, while multiple built-in protections ensure safe operation.
Figura 1: Frente view of the ACEFAST A55 charger, highlighting its crystal design and LED display.
2. Características principales
- Strong Power Delivery: Equipped with the latest GaN chipset, this 30W charger delivers fast charging to various devices, including phones, tablets, and laptops.
- Amplia compatibilidad: Supports fast charging for virtually all USB-A and USB-C devices, such as MacBook Pro, iPad Pro, iPhone 13/14/15 Pro/Pro Max, and more.
- Pantalla inteligente LED: Features a real-time LED screen that displays charging power. The screen automatically turns off once the device is fully charged.
- Intelligent Output & Multiple Protection: FCC certified, the charger includes comprehensive safety features such as Over Temperature Protection, Overcurrent Protection, Overvoltage Protection, Over Power Protection, and Short-Circuit Protection.
- Diseño portátil: Compact size with foldable prongs for easy transport and storage.
Figura 2: Sobreview of the multiple protection mechanisms integrated into the charger for safe and efficient operation.
3. ¿Qué hay en la caja?
Your ACEFAST A55 USB C Charger Block package includes:
- 1 x ACEFAST Charger 30W
- 1 cable USB-C
- 1 x Manual Guide
4. Instrucciones de configuración
- Deshacer: Carefully remove the ACEFAST A55 charger and included USB-C cable from its packaging.
- Desplegar puntas: If the charger's prongs are folded, gently flip them out until they lock into place.
- Cable de conexión: Insert one end of the USB-C cable into the USB-C port on the charger.
- Enchufe al tomacorriente: Insert the charger into a standard wall power outlet (120 Volts AC).
- Conectar dispositivo: Plug the other end of the USB-C cable into your compatible device (e.g., smartphone, tablet, laptop).
Figure 3: Proper connection of the charger to a wall outlet and a mobile device.
5. Instrucciones de funcionamiento
Once connected, the ACEFAST A55 charger will automatically begin charging your device. The intelligent LED screen display will activate to show the real-time charging power (wattage) being delivered to your device.
- Visualización de potencia en tiempo real: Observe the LED screen to monitor the charging wattage. This display provides immediate feedback on the charging speed.
- Apagado automático de pantalla: The LED display is designed to automatically turn off once your connected device reaches a full charge, conserving energy and indicating completion.
- Control de temperatura: The charger incorporates an intelligent temperature control chip that continuously monitors and regulates the internal temperature to prevent overheating during charging.
Figure 4: The charger's intelligent temperature control system ensures stable and safe charging.
Official Product Video: ACEFAST A55 PD30W USB C Charger Purple
Video 1: An official product video from ACEFAST demonstrating the features and usage of the A55 PD30W USB C Charger in purple. This video highlights the LED display, GaN technology, and compatibility with various devices.
6. Mantenimiento
To ensure the longevity and optimal performance of your ACEFAST A55 charger, follow these maintenance guidelines:
- Limpieza: Disconnect the charger from the power outlet and your device before cleaning. Use a soft, dry cloth to wipe the surface. Avoid using liquid cleaners or abrasive materials.
- Almacenamiento: When not in use, store the charger in a cool, dry place away from direct sunlight and extreme temperatures. The foldable prongs allow for compact storage.
- Manejo: Avoid dropping the charger or subjecting it to strong impacts. Do not attempt to disassemble or modify the charger, as this will void the warranty and may cause damage.
7. Solución de problemas
If you encounter issues with your ACEFAST A55 charger, please refer to the following common solutions:
| Problema | Posible causa | Solución |
|---|---|---|
| Charger not powering on / LED display off | No power from outlet; loose connection; faulty outlet. | Try plugging the charger into a different, known-working wall outlet. Ensure the charger is firmly seated in the outlet. |
| El dispositivo no se carga | Loose cable connection; incompatible cable; device issue; charger fault. | Ensure both ends of the USB-C cable are securely connected. Try using a different USB-C cable. Test the charger with another compatible device. |
| LED display not showing wattage or flickering | Intermittent connection; device not drawing power; specific device behavior. | Ensure a stable connection. Note that some devices may not draw consistent power, causing the display to fluctuate. The display may also turn off automatically when fully charged. |
| Carga lenta | Cable no compatible con carga rápida; dispositivo no compatible con carga rápida; aplicaciones en segundo plano en el dispositivo. | Use the included ACEFAST USB-C cable or another high-quality, fast-charging compatible cable. Ensure your device supports 30W fast charging. Close unnecessary background applications on your device. |
If the problem persists after trying these solutions, please contact ACEFAST customer service for further assistance.
8. Especificaciones
| Atributo | Detalle |
|---|---|
| Marca | MEJOR |
| Número de modelo | A55 |
| Potencia de salida | 30 W |
| Tecnología de conectividad | Con cable (USB tipo C) |
| Tipo de conector | USB tipo C |
| Dispositivos compatibles | Phones, Tablets, Laptops (e.g., iPhone 14, MacBook Pro, iPad Pro) |
| Característica especial | Fast Charging, LED Intelligent Screen Display, Foldable Prongs |
| Color | Púrpura |
| Vol de entradatage | 120 voltios (CA) |
| Peso del artículo | 4.6 onzas |
| Dimensiones del paquete | 5.79 x 3.62 x 1.61 pulgadas |
| Fabricante | ShenZhen Houshuxia Technology Co.,LTD |
9. Garantía y soporte
ACEFAST provides a worry-free Garantía de 24 meses for the A55 USB C Charger Block. For any product-related inquiries, technical support, or warranty claims, please contact our friendly customer service team. Refer to the contact information provided in your product packaging or visit the official ACEFAST websitio para detalles de soporte.
