Εισαγωγή
Welcome to your new Surtime 116CM Ceiling Fan. This manual provides essential information for the safe installation, operation, and maintenance of your ceiling fan. Please read it thoroughly before use and retain it for future reference. Proper installation and use will ensure optimal performance and longevity of your product.
Πληροφορίες Ασφάλειας
Για την αποφυγή τραυματισμών ή υλικών ζημιών, ακολουθείτε πάντα αυτές τις βασικές προφυλάξεις ασφαλείας:
- Ensure the main power supply to the installation area is disconnected at the circuit breaker before beginning any installation, maintenance, or cleaning.
- Η εγκατάσταση πρέπει να εκτελείται από εξειδικευμένο ηλεκτρολόγο σύμφωνα με όλους τους τοπικούς ηλεκτρικούς κώδικες.
- Mount the fan securely to a ceiling joist or a suitable support structure capable of safely supporting the fan's weight (approximately 5.13 kg).
- Do not insert any objects into the fan blades while they are in motion.
- Κρατήστε τα παιδιά και τα κατοικίδια μακριά από τον ανεμιστήρα κατά τη λειτουργία.
- Χρησιμοποιήστε μόνο τον καθορισμένο τόμοtage (220 Volt) για αυτήν τη συσκευή.
- Βεβαιωθείτε ότι όλες οι συνδέσεις είναι ασφαλείς και σωστά μονωμένες.
Περιεχόμενα συσκευασίας
Please verify that all components are present and undamaged before proceeding with installation. If any parts are missing or damaged, contact customer support.
- Ceiling Fan Unit (with 5 blades)
- Τηλεχειριστήριο
- Βάση στήριξης και υλικό
- Σχοινί Ασφαλείας
- Εγχειρίδιο χρήστη
Εικόνα: Πάνωview of the Surtime 116CM Ceiling Fan and its main components.
Προδιαγραφές
| Χαρακτηριστικό | Προσδιορισμός |
|---|---|
| Μάρκα | Surtime |
| Αριθμός μοντέλου | 8217Wt-RGB-46 |
| Χρώμα | Λευκό |
| Διαστάσεις (Διάμετρος x Ύψος) | 116 cm x 26 cm |
| Βάρος | 5.13 κιλά |
| Εξουσία | 28 Watts (Fan), 14W*2 (Light) |
| Τομtage | 220 Volt |
| Υλικό | Acrylonitrile Butadiene Styrene (ABS), Metal, Acrylic |
| Χαρακτηριστικά | Dimmable, Adjustable Color Temperature, RGB Light Ring, Reversible Motor, 6 Fan Speeds, 2-Hour Timer |
| Ελεγχος | Remote Control, Mobile App Control |
| Επίπεδο θορύβου | <35 dB |
| Διάρκεια ζωής πηγής φωτός | 50,000 ώρες |
Image: Detailed product parameters including dimensions, blade quantity, light power, and control methods.
Οδηγίες εγκατάστασης
Follow these steps carefully for proper installation. It is recommended to have two people for installation. If you are unsure about any step, consult a qualified electrician.
Βήμα 1: Προετοιμασία για εγκατάσταση
- Ensure the power supply to the installation area is turned off at the circuit breaker.
- Αποσυσκευάστε όλα τα εξαρτήματα και επαληθεύστε τα με βάση τη λίστα περιεχομένων της συσκευασίας.
Βήμα 2: Τοποθέτηση του βραχίονα
- Secure the mounting bracket to a ceiling joist or a suitable electrical junction box capable of supporting the fan's weight. Use appropriate screws and anchors provided.
Βήμα 3: Καλωδίωση
- Connect the fan's electrical wires to the household wiring according to local electrical codes. Ensure all connections are secure and properly insulated.
- The included safety rope can be used to temporarily support the fan during wiring, allowing for easier single-person installation.
Εικόνα: Λεπτομερής view of the fan's internal wiring and LED module before final assembly.
Step 4: Attaching the Fan Body
- Carefully lift the fan body and attach it to the mounting bracket. Ensure it is securely fastened with the provided screws.
Image: A person demonstrating the installation process of the ceiling fan onto the ceiling mount.
Βήμα 5: Εγκατάσταση λεπίδας
- Attach the five fan blades to the motor housing using the provided screws. Ensure they are firmly secured and balanced.
Βήμα 6: Τελικοί έλεγχοι
- Double-check all connections and ensure no wires are pinched.
- Επαναφέρετε την ισχύ στον διακόπτη κυκλώματος.
Οδηγίες Λειτουργίας
Λειτουργία τηλεχειριστηρίου
The fan is controlled via the included remote. Insert 2 AAA batteries (not included) into the remote control before use.
Image: The remote control for the Surtime ceiling fan, showing various function buttons.
- ON/OFF Light: Turns the main light on or off.
- ΟΛΑ ΑΠΕΝΕΡΓΟΠΟΙΗΜΕΝΑ: Turns off both the fan and the light.
- Ταχύτητα ανεμιστήρα (1-6): Ρυθμίζει την ταχύτητα του ανεμιστήρα από 1 (χαμηλότερη) έως 6 (υψηλότερη).
- Timer (2H): Sets a 2-hour timer for the fan to automatically turn off.
- 3 CCT: Cycles through 3 color temperatures for the main light (Warm White 3000K, Natural White 4500K, Cool White 6500K).
- Φως νύχτας: Activates a low-brightness night light mode.
- F/R (Forward/Reverse): Changes the fan's rotation direction for seasonal use.
- RGB Change: Cycles through various RGB color modes for the side ring light.
- Φωτεινότητα +/-: Adjusts the brightness level of the main light.
- Θερμοκρασία χρώματος +/-: Fine-tunes the color temperature of the main light.
Image: Various side-illuminated RGB lighting modes and white light options.
Έλεγχος εφαρμογών για κινητά
The fan can also be controlled via a dedicated mobile application.
- Σαρώστε τον παρακάτω κωδικό QR ή επισκεφτείτε το https://www.jasonghost.com/fanlamppro/ to download the "Fan Lamp Pro" app.
- Install the app on your smartphone and register an account if prompted.
- Turn on the fan's main power supply. Within 5 seconds of powering on, open the app and repeatedly tap the "Pair" button. The fan light will blink or emit a sound to confirm successful pairing.
- Once paired, you can control all fan and light functions directly from the app interface.
Image: Screenshot of the mobile application interface for controlling the fan and light functions, including a QR code for download.
Seasonal Operation (Forward/Reverse Mode)
The fan features a reversible DC motor, allowing for optimal air circulation throughout the year.
- Θερινή λειτουργία (Εμπρός): Blades rotate counter-clockwise, pushing air downwards to create a cooling breeze. This mode is ideal for warmer months.
- Χειμερινή λειτουργία (αντίστροφη): Blades rotate clockwise, drawing air upwards to circulate warm air trapped near the ceiling, distributing it evenly throughout the room. This helps to reduce heating costs in colder months.
Image: Illustration of the fan's reversible motor function, demonstrating airflow for summer cooling and winter heat distribution.
Συντήρηση
Regular maintenance ensures the longevity and efficient operation of your ceiling fan.
Καθάρισμα
- Always turn off the power supply to the fan at the circuit breaker before cleaning.
- Χρησιμοποιήστε ένα μαλακό, δamp cloth to wipe down the fan blades, motor housing, and light cover.
- Avoid using abrasive cleaners, solvents, or harsh chemicals, as these can damage the finish or electrical components.
- Do not immerse the fan or any electrical parts in water.
Γενική Φροντίδα
- Periodically check all screws and connections to ensure they remain secure. Tighten any loose fasteners.
- The integrated LED light module is designed for a long lifespan (50,000 hours) and typically does not require replacement.
Αντιμετώπιση προβλημάτων
If you encounter any issues with your Surtime ceiling fan, refer to the following common problems and solutions:
- Ο ανεμιστήρας δεν ανάβει:
- Check if the main power supply is connected and the circuit breaker is on.
- Ensure the remote control batteries are correctly inserted and charged.
- Verify that the fan is properly paired with the remote or mobile app.
- Το φως δεν ανάβει:
- Confirm the main power supply is active.
- Ensure the light function is activated on the remote or app.
- Το τηλεχειριστήριο δεν αποκρίνεται:
- Αντικαταστήστε τις μπαταρίες στο τηλεχειριστήριο.
- Re-pair the remote with the fan (refer to the pairing instructions in the Mobile App Control section, as the process is often similar for remotes).
- Fan makes excessive noise:
- Ensure all fan blades are securely attached and balanced.
- Check if the mounting bracket is firmly secured to the ceiling.
- Verify that no wires or other objects are interfering with the fan's rotation.
- RGB LED ring turns on by itself:
- This may indicate a firmware issue or external interference. Try re-pairing the remote/app. If the issue persists, contact customer support.
- Remote control batteries drain quickly:
- Ensure you are using high-quality batteries. If the issue persists, it may indicate a remote control fault.
- Fan settings reset after power cut:
- This is a characteristic for some models. The fan will return to its default off state after a power interruption.
Εγγύηση και υποστήριξη
Your Surtime ceiling fan comes with a standard manufacturer's warranty. Please retain your proof of purchase for any warranty claims.
For technical support, warranty inquiries, or replacement parts, please contact Surtime customer service through the retailer where you purchased the product or visit the official Surtime website για στοιχεία επικοινωνίας.
Πληροφορίες Ανακύκλωσης
Please dispose of the product and its components responsibly at the end of their lifespan. Do not dispose of electrical appliances with general household waste.
For information on recycling light bulbs and electrical appliances, consult local regulations or visit relevant recycling information webιστότοποι:
