SMACO Vollgesichts-Tauchmaske – Bedienungsanleitung

1. Einleitung

This manual provides comprehensive instructions for the safe and effective use, maintenance, and troubleshooting of your SMACO Full Face Diving Mask. Designed for both snorkeling and recreational diving, this mask offers a comfortable and immersive underwater experience. Please read this manual thoroughly before first use.

Figure 1: SMACO Full Face Diving Mask with Snorkel and Camera Mount.

2. Produktmerkmale

• Breite Kompatibilität: The SMACO M8058C can be used as a snorkeling mask or a diving mask (by removing the snorkel). It is compatible with SMACO S400/S400 Plus/S400 Pro/S700/S700 Max scuba tanks, expanding your diving and snorkeling possibilities.
• Smooth Breathing Design: Features separate channels for inhaling and exhaling, ensuring exhaled CO₂ and residual O₂ are quickly expelled. This unique system prevents fogging and keeps seawater out of your mouth, allowing for relaxed breathing through both nose and mouth.
• Optimal Fit & Easy Doffing: Equipped with an adjustable 5-point head harness for an excellent and secure fit that conforms to various facial contours. A quick-release pull tab allows for fast and easy removal of the mask.
• Immersive Panoramic View: Provides a 180° panoramic view for an unobstructed and immersive underwater experience. Includes a detachable camera mount for capturing underwater moments.
• Safe and Odorless Material: Constructed from premium food-grade silicone, ensuring no odor, oxidation, discoloration, or skin allergies.

3. Komponenten

The SMACO Full Face Diving Mask package typically includes the following components:

• Full Face Diving Mask (M8058C)
• Detachable Snorkel
• Kamerahalterung
• Benutzerhandbuch (dieses Dokument)

Figure 2: Key features including Action Camera Mount, Quick Release Pull Button, and Exhaust Valve.

4. Einrichtung

4.1. Fitting the Mask

1. Ensure the mask is clean and free of debris.
2. Hold the mask by the frame and place your chin into the bottom of the mask.
3. Pull the adjustable 5-point head harness over your head, ensuring it sits comfortably and securely.
4. Adjust the straps evenly until the silicone skirt forms a tight seal around your face. The mask should feel snug but not uncomfortably tight.

Figure 3: The 5-point strap system allows for precise adjustment to fit various face shapes.

4.2. Attaching the Snorkel

For snorkeling use, attach the snorkel to the designated port on top of the mask. Ensure it clicks securely into place.

4.3. Attaching to Scuba Tank (for Diving)

To use the mask for diving with a SMACO scuba tank (S400/S400 Plus/S400 Pro/S700/S700 Max):

1. Remove the mouthpiece from the second stage Regler.
2. Connect mouthpiece and air intake holes of the mask.
3. Wrap the zip tie around the connection.
4. Subtract the excess part of the zip tie.

Figure 4: Steps for connecting the mask to a diving tank regulator.

4.4. Anbringen einer Kamera

The mask features a detachable camera mount on the top. Attach your action camera to this mount to record your underwater adventures.

5. Bedienungsanleitung

5.1. Snorkeling Use

With the snorkel attached, the mask's dry top system prevents water entry when submerged. The separate breathing channels ensure fresh air intake and efficient CO₂ expulsion, minimizing fogging and allowing natural breathing.

Figure 5: The Dry Top System automatically closes the air valve when submerged to prevent water entry.

5.2. Diving Use

When connected to a compatible SMACO scuba tank, the mask functions as a full-face diving mask. Ensure the snorkel is removed and the regulator is securely attached. The mask's design allows for comfortable breathing and a wide field of vision underwater.

Figure 6: The mask can be used for both snorkeling and diving by adjusting the setup.

5.3. Breathing System

The mask's innovative breathing system separates inhaled fresh air from exhaled CO₂. This design minimizes the rebreathing of carbon dioxide and prevents the mask from fogging, providing clear vision throughout your activity.

Figure 7: Experience a 180° panoramic view with anti-leak and anti-fog properties.

6. Sicherheitshinweise

• Always inspect the mask for any damage or wear before each use.
• Ensure a proper seal is achieved to prevent water leakage.
• Do not use the mask if you have facial hair that interferes with the seal.
• Never dive alone. Always use with a buddy.
• Familiarize yourself with the mask's quick-release mechanism for emergency removal.
• For diving, ensure you are properly trained and certified. Always follow safe diving practices.
• Avoid rapid ascents while diving to prevent pressure-related injuries.
• Do not use the mask if you feel unwell or experience any discomfort.

7. Wartung und Pflege

• Reinigung: After each use, rinse the mask thoroughly with fresh water to remove salt, sand, and chlorine. Use a mild soap if necessary, but avoid abrasive cleaners or solvents.
• Trocknen: Allow the mask to air dry completely in a shaded area, away from direct sunlight, before storing.
• Lagerung: Store the mask in a cool, dry place, preferably in its original packaging or a protective bag, to prevent scratches and deformation. Avoid storing it under heavy objects or in direct sunlight.
• Inspektion: Periodically check the silicone skirt, straps, and lens for any signs of wear, cracks, or damage. Replace any damaged components immediately.

8. Fehlerbehebung

9. Spezifikationen

10. Garantie und Support

The SMACO Full Face Diving Mask comes with a 1 Jahre Produktgarantie ab Kaufdatum.

For warranty claims, technical support, or any inquiries regarding your product, please contact SMACO customer service through the retailer where you purchased the product or visit the official SMACO webWebsite für Kontaktinformationen.

Bitte bewahren Sie Ihren Kaufbeleg zur Überprüfung der Garantie auf.
