EKC 102C1 Temperature Controller
The buttons
Set menu
- Push the upper button until a parameter is shown
- Push the upper or the lower button and nd that parameter you want to change
- Push the middle button until the parameter value is shown
- Push the upper or the lower button and select the new value
- Push the middle button again to enter the value.
Set temperature
- Push the middle button until the temperature value is shown
- Push the upper or the lower button and select the new value
- Push the middle button to select the setting.
See temperature at the other temperature sensor
- Push briefly the lower button
Manuel start or stop of a defrost - Push the lower button for four seconds.
Light emmiting diode
= refrigeration
= defrost
Flashes fast at alarm
See alarm code
Push briefly the upper button
Start-up:
Regulation starts when the voltage is on.
Go through the survey of factory settings. Make any necessary changes in the respective parameters.
| Parameters | Min.- value | Max.- value | Factory setting | Actual setting | |
| Function | Codes | ||||
| Normal operation | |||||
| Temperature (set point) | — | -50°C | 90°C | 2°C | |
| Thermostat | |||||
| Differential | r01 | 0,1 K | 20 K | 2 K | |
| Max. limitation of setpoint setting | r02 | -49°C | 90°C | 90°C | |
| Min. limitation of setpoint setting | r03 | -50°C | 89°C | -10°C | |
| Adjustment of temperature indication | r04 | -20 K | 20 K | 0 K | |
| Temperature unit (°C/°F) | r05 | °C | °F | °C | |
| Correction of the signal from Sair | r09 | -10 K | 10 K | 0 K | |
| Manual service, stop regulation, start regulation (-1, 0, 1) | r12 | -1 | 1 | 1 | |
| Displacement of reference during night operation | r13 | -10 K | 10 K | 0 K | |
| Alarm | |||||
| Delay for temperature alarm | A03 | 0 min | 240 min | 30 min | |
| Delay for door alarm | A04 | 0 min | 240 min | 60 min | |
| Delay for temperature alarm after defrost | A12 | 0 min | 240 min | 90 min | |
| High alarm limit | A13 | -50°C | 50°C | 8°C | |
| Low alarm limit | A14 | -50°C | 50°C | -30°C | |
| Compressor | |||||
| Min. ON-time | c01 | 0 min | 30 min | 0 min | |
| Min. OFF-time | c02 | 0 min | 30 min | 0 min | |
| Compressor relay must cutin and out inversely (NC-function) | c30 | OFF | On | OFF | |
| Defrost | |||||
| Defrost method (0=none / 1*=natural / 2=gas) | d01 | 0 | 2 | 1 | |
| Defrost stop temperature | d02 | 0°C | 25°C | 6°C | |
| Interval between defrost starts | d03 | 0 hours | 48 hours | 8 hours | |
| Max. defrost duration | d04 | 0 min | 180 min | 45 min | |
| Displacement of time on cutin of defrost at start-up | d05 | 0 min | 240 min | 0 min | |
| Defrost sensor 0=time, 1=S5, 2=Sair | d10 | 0 | 2 | 0 | |
| Defrost at start-up | d13 | no | yes | no | |
| Max. aggregate refrigeration time between two defrosts | d18 | 0 hours | 48 hours | 0 hours | |
| Defrost on demand – S5 temperature’s permitted variation during frost build-up. On central plant choose 20 K (=off) | d19 | 0 K | 20 k | 20 K | |
| Miscellaneous | |||||
| Delay of output signals after start-up | o01 | 0 s | 600 s | 5 s | |
| Input signal on DI1. Function: (0=not used. , 1= door alarm when open. 2=defrost start (pulse-pressure). 3=ext.main switch. 4=night operation | o02 | 0 | 4 | 0 | |
| Access code 1 (all settings) | o05 | 0 | 100 | 0 | |
| Used sensor type (Pt /PTC/NTC) | o06 | Pt | ntc | Pt | |
| Display step = 0.5 (normal 0.1 at Pt sensor) | o15 | no | yes | no | |
| Access code 2 (partly access) | o64 | 0 | 100 | 0 | |
| Save the controllers present settings to the programming key. Select your own number. | o65 | 0 | 25 | 0 | |
| Load a set of settings from the programming key (previ- ously saved via o65 function) | o66 | 0 | 25 | 0 | |
| Replace the controllers factory settings with the present settings | o67 | OFF | On | OFF | |
| Select application for S5 sensor (0=defrost sensor, 1= product sensor) | o70 | 0 | 1 | 0 | |
| Select application for relay 2: 1=defrost, 2= alarm relay, 3= drain valve | o71 | 1 | 3 | 3 | |
| Period time between each time the drain valve is activated | o94 | 1 min | 35 min | 2 min | |
| Opening time for the drain valve (During defrost is the valve open) | o95 | 2 s | 30 s | 2 s | |
| Seconds setting. This setting is added to the minutes in 094 | P54 | 0s | 60 s | 0 s | |
| Service | |||||
| Temperature measured with S5 sensor | u09 | ||||
| Status on DI1 input. on/1=closed | u10 | ||||
| Status on relay for cooling Can be controlled manually, but only when r12=-1 | u58 | ||||
| Status on relay 2 Can be controlled manually, but only when r12=-1 | u70 | ||||
* 1 => Electric if o71 = 1
SW = 1.3X
| Alarm code display | |
| A1 | High temperature alarm |
| A2 | Low temperature alarm |
| A4 | Door alarm |
| A45 | Standby mode |
| Fault code display | |
| E1 | Fault in controller |
| E27 | S5 sensor error |
| E29 | Sair sensor error |
| Status code display | |
| S0 | Regulating |
| S2 | ON-time Compressor |
| S3 | OFF-time Compressor |
| S10 | Refrigeration stopped by main switch |
| S11 | Refrigeration stopped by thermostat |
| S14 | Defrost sequence. Defrosting |
| S17 | Door open (open DI input) |
| S20 | Emergency cooling |
| S25 | Manual control of outputs |
| S32 | Delay of output at start-up |
| non | The defrost temperature cannot be dis- played. There is no sensor |
| -d- | Defrost in progress / First cooling after defrost |
| PS | Password required. Set password |
Factory setting
If you need to return to the factory-set values, it can be done in this way:
– Cut out the supply voltage to the controller
– Keep upper and lower button depressed at the same time as you recon nect the supply voltage
Instructions RI8LH453 © Danfoss
