1. Sikkerhedsinstruktioner
Read and understand all safety warnings and instructions before operating this grass trimmer. Failure to follow the warnings and instructions may result in electric shock, fire, and/or serious injury.
- Bær øjenbeskyttelse: Always wear safety glasses or goggles with side shields when operating the trimmer.
- Brug passende tøj: Wear long pants, long sleeves, and sturdy footwear. Do not wear loose clothing or jewelry that could get caught in moving parts.
- Hold tilskuere væk: Sørg for, at børn, kæledyr og andre personer er i sikker afstand (mindst 15 meter / 50 fod) fra driftsområdet.
- Inspicer arbejdsområdet: Før du starter, skal du rydde området for alle genstande, der kan blive slynget ud af skæretråden, såsom sten, glasskår eller ståltråd.
- Bevar et fast greb: Always hold the trimmer firmly with both hands during operation.
- Undgå våde forhold: Do not operate the trimmer in wet grass or rain.
- Batterisikkerhed: Use only the specified battery pack and charger. Do not charge the battery in damp eller våde steder.
- Opretholdelse: Disconnect the battery pack before performing any maintenance, cleaning, or when replacing the cutting line.
2. Pakkens indhold
Carefully unpack all items and ensure you have received everything listed below. If any items are missing or damaged, contact RYOBI customer service.
- Cordless Grass Trimmer Unit
- Battery Pack (e.g., 18V ONE+ 2.0Ah)
- Batterioplader
- Sikkerhedsvagt
- Hjælpehåndtag
- Brugermanual
Image 1: The RYOBI 5133005460 Cordless Grass Trimmer shown with its included battery pack and charger.
3. Opsætning
3.1. Opladning af batteriet
- Connect the charger to a standard power outlet. The charger indicator light will illuminate.
- Skub batteripakken ind i opladeren, indtil den klikker på plads.
- Allow the battery to charge fully. The indicator light on the charger will change (e.g., from red to green) when charging is complete. Refer to the charger's specific instructions for details.
- Once charged, disconnect the battery from the charger and unplug the charger from the outlet.
3.2. Samling af trimmeren
Note: Ensure the battery pack is removed before assembly.
- Fastgør sikkerhedsskærmen: Align the safety guard with the mounting slots on the trimmer head. Secure it with the provided screws or clips, ensuring it is firmly attached.
- Installer hjælpehåndtaget: Skub ekstrahåndtaget på trimmerens skaft. Juster dets position for komfortabel betjening, og stram låsemekanismen.
- Adjust Shaft Length (if applicable): If your model features an adjustable shaft, extend or retract it to a comfortable working height and secure it.
4. Betjeningsvejledning
4.1. Isætning og fjernelse af batteriet
- For at indsætte: Align the battery pack with the battery port on the trimmer handle. Slide it in until it clicks securely into place.
- For at fjerne: Press the battery release latch (usually located on the battery pack) and slide the battery out of the port.
4.2. Start og stop af trimmeren
- At begynde: Ensure the battery is fully inserted. Press and hold the safety lock-off button (if present), then squeeze the trigger switch.
- At stoppe: Slip afbryderen. Skæretråden vil stoppe med at dreje.
4.3. Trimningsteknikker
For best results and to prevent damage, use the following techniques:
- Fejende bevægelse: Move the trimmer from side to side in a sweeping motion, cutting small amounts of grass at a time.
- Vinkel: Hold the trimmer at a slight angle to the ground for effective cutting.
- Undgå forhindringer: Keep the cutting line away from hard objects like fences, walls, and trees to prevent line breakage and damage to the trimmer.
- Kantning: Some models allow the head to pivot for edging. Consult your specific model's features for this function.
Image 2: A person demonstrating the use of a RYOBI grass trimmer for general lawn maintenance.
Image 3: A woman operating a RYOBI grass trimmer to trim along a garden path, showcasing typical usage.
5. Vedligeholdelse
Regular maintenance ensures optimal performance and extends the life of your trimmer. Always remove the battery pack before performing any maintenance.
5.1. Rensning
- Rengør trimmerhuset og beskyttelsesskærmen efter hver brug.amp klæde.
- Remove any grass clippings or debris from the cutting head and ventilation slots.
- Do not use harsh detergents or solvents, as these can damage plastic parts.
5.2. Udskiftning af skæretråden
The cutting line will wear down with use and needs to be replaced periodically.
- Sørg for, at batteripakken er fjernet.
- Refer to your trimmer head's specific instructions for line replacement. Most models involve removing the spool cap, winding new line onto the spool, and reassembling.
- Use only the recommended diameter and type of cutting line specified by RYOBI for this model.
5.3. Batteripleje og -opbevaring
- Opbevar batteripakken et køligt, tørt sted, væk fra direkte sollys og ekstreme temperaturer.
- Ved langtidsopbevaring skal batteriet oplades til cirka 50% kapacitet.
- Do not store the battery pack connected to the trimmer or charger.
6. Fejlfinding
Hvis du støder på problemer, kan du se tabellen nedenfor for almindelige problemer og løsninger.
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Trimmeren starter ikke. | Batteriet er ikke isat korrekt eller ikke opladet. Sikkerhedslåsen er ikke aktiveret. | Ensure battery is fully inserted and charged. Press safety lock-off button before squeezing trigger. |
| Skæretråden går ikke fremad. | Line is tangled, too short, or spool is empty. | Remove battery, inspect cutting head for tangles. Replace cutting line if necessary. |
| Dårlig skæreydelse. | Dull or worn cutting line. Trimmer used on excessively thick vegetation. | Replace cutting line. Avoid cutting very thick weeds; use appropriate tools for heavy brush. |
| Batteriet oplades ikke. | Oplader ikke tilsluttet. Defekt batteri eller oplader. | Check power connection. Try another outlet. If problem persists, contact customer service. |
7. Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | RYOBI |
| Modelnummer | 5133005460 |
| Strømkilde | Batteridrevet |
| Skærebredde | 23 centimeter |
| Produktmål (L x B x H) | 50 x 50 x 28 cm |
| Varens vægt | 6 kilo |
| Montering påkrævet | Ja |
| International artikelkode | 04892210203366 |
8. Garanti og support
RYOBI products are manufactured to high-quality standards and are backed by a manufacturer's warranty. For specific warranty details, please refer to the warranty card included with your product or visit the official RYOBI webwebsted.
For technical assistance, spare parts, or to locate an authorized service center, please contact RYOBI customer support through their official webwebstedet eller kontaktoplysningerne i din produktdokumentation.
Online support: www.ryobi.eu (eller relevant regionalt webwebsted)
