Ambrane trådløs gamingcontroller OP-WLGC01 brugermanual

1. Introduktion

Thank you for choosing the Ambrane Wireless Gaming Controller OP-WLGC01. This controller is designed to provide an immersive gaming experience across multiple platforms, including PC (Windows), PS3 Console, and Android TV. Featuring 2.4GHz wireless technology, dual vibration motors, and dynamic RGB lighting, this manual will guide you through its setup, operation, and maintenance.

Image 1.1: The Ambrane Wireless Gaming Controller OP-WLGC01, showcasing its transparent design and illuminated elements.

2. Produktet er slutview

The Ambrane OP-WLGC01 controller combines advanced features with a unique aesthetic. Key components and features include:

• Gennemsigtigt design: A visually distinct transparent casing.
• 2.4 GHz trådløs teknologi: Ensures stable and responsive connectivity.
• Integrated Dual Intensity Motor: Provides haptic feedback for an immersive gaming experience.
• Illuminated Pad (RGB Lighting): Features 16.8 million colors with breathing RGB effects.
• Ergonomisk design: Easy-to-hold body for comfortable extended gaming sessions.
• Specialfunktionsknapper: Dedicated Turbo and Clear buttons for enhanced gameplay.

Image 2.1: Illustration of the dual vibrating motors providing haptic feedback.

Image 2.2: The controller displaying its dynamic 16.8 million color breathing RGB lighting effect.

3. Opsætning

3.1 Opladning af controlleren

Before initial use, fully charge the controller. The integrated 800mAh battery provides up to 12 hours of gameplay on a full charge.

1. Connect the provided Type-C charging cable to the charging port on the controller.
2. Tilslut den anden ende af kablet til en USB-strømkilde (f.eks. en computers USB-port eller en USB-vægadapter).
3. The indicator lights on the controller will show charging status and turn off or change color when fully charged.

Image 3.1: The controller highlighting its Type-C charging port and other features.

3.2 Tilslutning til enheder

The controller utilizes 2.4GHz wireless technology for connection. It is compatible with PC (Windows systems, supporting X-Input & D-Input modes), PS3 consoles, and Android TV devices.

1. Insert the 2.4GHz USB receiver (dongle) into an available USB port on your PC, PS3 console, or Android TV.
2. Turn on the controller by pressing the MODE button.
3. The controller will automatically pair with the receiver. The indicator lights will stabilize once connected.
4. For PC, ensure the correct input mode (X-Input or D-Input) is selected if prompted by your game or system.

Image 3.2: The controller demonstrating its compatibility with PS3 Console, Windows System, Android TV, and PC.

4. Betjeningsvejledning

4.1 Knaplayout og funktioner

Sæt dig ind i controllerens knaplayout for optimal gameplay.

Image 4.1: Detailed diagram of the controller's buttons, including joysticks, directional pad, action buttons (A, B, X, Y), shoulder buttons (L1, L2, R1, R2), SELECT, START, TURBO, CLEAR, MODE, and RGB Control.

• Venstre/højre joysticks: For analog movement and camera control.
• Directional Button (D-Pad): Til præcis retningsbestemt input.
• Handlingsknapper (A, B, X, Y): Standardspilhandlinger.
• Skulderknapper (L1, L2, R1, R2): Til forskellige funktioner i spillet.
• SELECT/START: Menu and pause functions.
• MODE knap: Power on/off and mode switching.
• RGB kontrol: Button or combination for adjusting RGB lighting effects.

4.2 Turbo-tilstand

The Turbo mode allows for rapid and continuous actions by repeatedly pressing a single button. This can be useful for certain in-game scenarios.

1. Press and hold the desired action button (e.g., A, B, X, Y, L1, R1).
2. Mens du holder handlingsknappen nede, skal du trykke på TURBO knap én gang.
3. Release both buttons. The selected action button will now perform rapid presses when held down.

Billede 4.2: Nærbillede view of the TURBO and CLEAR special function buttons.

4.3 Clearing Turbo Mode

To deactivate Turbo mode for a specific button:

1. Press and hold the action button for which Turbo mode is active.
2. Mens du holder handlingsknappen nede, skal du trykke på KLAR knap én gang.
3. Release both buttons. Turbo mode for that button is now deactivated.

To clear all Turbo settings, press and hold the KLAR knap i cirka 3 sekunder.

5. Vedligeholdelse

Korrekt vedligeholdelse sikrer din controllers levetid og optimale ydeevne.

• Rensning: Brug en blød, tør klud til at tørre controlleren af. Ved genstridigt snavs, tør letampSkyl kluden med vand. Undgå skrappe kemikalier eller slibende materialer.
• Opbevaring: Opbevar controlleren et køligt, tørt sted væk fra direkte sollys og ekstreme temperaturer.
• Batteripleje: Undgå at aflade batteriet helt ofte. Hvis controlleren opbevares i længere tid, skal den oplades til ca. 50% for at forlænge batteriets levetid.
• Undgå dråber: Protect the controller from physical impact, which can damage internal components.

6. Fejlfinding

7. Specifikationer

8. Garanti og support

This Ambrane product comes with a 365-day (1 Year) brand warranty against any manufacturing-related issues.

For warranty claims, technical support, or any inquiries, please contact Ambrane customer service:

• E-mail: Care@ambraneindia.com

Gem venligst din købskvittering for garantivalidering.
