KENT Pearl RO Water Purifier User Manual

1. Konec produktuview

The KENT Pearl RO Water Purifier is an advanced water purification system designed to provide 100% pure and safe drinking water. It incorporates multiple purification processes including RO, UV, UF, and TDS Control, ensuring the removal of dissolved impurities, bacteria, and viruses while retaining essential natural minerals.

Figure 1: KENT Pearl RO Water Purifier

This purifier features a unique Zero Water Wastage Technology, a detachable storage tank for easy cleaning, and computer-controlled operations for enhanced user convenience and safety.

2. Klíčové vlastnosti

• Multiple Purification Process: Combines Reverse Osmosis (RO), Ultraviolet (UV), Ultrafiltration (UF), and TDS Control to remove dissolved impurities, arsenic, rust, pesticides, fluorides, bacteria, and viruses.
• Byla nulová vodatage Technologie: Re-circulates rejected water to the overhead tank, ensuring no water is wasted during the purification process.
• TDS Control System: Allows adjustment of the purified water's TDS level, retaining essential natural minerals for healthier drinking water.
• Detachable Storage Tank: Features an 8-liter transparent, removable storage tank for easy cleaning and maintenance.
• In-Tank UV Disinfection: Equipped with UV LED light in the storage tank to keep purified water pure for longer durations.
• Computer Controlled Operation: Includes Filter Change Alarm and UV Fail Alarm for timely maintenance alerts.
• High Purification Capacity: Capable of purifying up to 20 liters of water per hour.
• Odolná konstrukce: Built with an ABS food-grade plastic body for enhanced durability and hygiene.
• Versatile Water Source Compatibility: Equally suitable for water from all sources, including bore-wells, overhead storage tanks, water tankers, and municipal taps.

Figure 2: Detailed Features of KENT Pearl

Obrázek 3: Multi-Stage Proces čištění

3. Nastavení a instalace

The KENT Pearl RO Water Purifier is designed for wall-mounted installation. It features push-fit components for leak-proof performance, simplifying the connection process.

3.1 Kontroly před instalací

• Ensure the installation site has adequate space and a stable wall surface for mounting.
• Verify the availability of a water inlet connection and a drainage point.
• Confirm a standard electrical outlet (230V AC, 50 Hz) is within reach.

3.2 Proces instalace

It is highly recommended to have the purifier installed by a certified KENT service technician to ensure proper setup and validate the warranty. The technician will:

1. Čističku bezpečně připevněte na zeď.
2. Connect the water inlet and drain lines using the push-fit connectors.
3. Připojte napájecí zdroj.
4. Perform initial flushing of the system to remove any manufacturing residues.
5. Adjust the TDS controller to the desired level based on your water source and preference.

Figure 4: Zero Water Wastage Process Diagram

The Zero Water Wastage Technology ensures that the rejected water from the RO process is recirculated back to your overhead tank, preventing any water loss. This process is managed by an internal booster pump.

4. Návod k obsluze

4.1 Zapnutí/vypnutí

• To power on the purifier, ensure it is properly connected to the electrical outlet and turn on the main power switch.
• The purifier will automatically begin the purification process when the water level in the storage tank is low.
• It will automatically stop once the tank is full or if there is no inlet water supply.
• To power off, simply turn off the main power switch.

4.2 Dispensing Purified Water

• Place a clean container under the faucet located at the front of the purifier.
• Turn the faucet handle to dispense purified water.
• Close the faucet once the desired amount of water is collected.

4.3 Pochopení indikátorů

The purifier is equipped with LED indicators to show its operational status:

• Indikátor napájení: Illuminates when the purifier is powered on.
• Purification Indicator: Illuminates when the purification process is active.
• Indikátor plné nádrže: Illuminates when the purified water storage tank is full.

5. Údržba

Regular maintenance is crucial for the optimal performance and longevity of your KENT Pearl RO Water Purifier. The computer-controlled operation assists with timely alerts.

5.1 Filter Change Alarm

• The purifier is equipped with a Filter Change Alarm that indicates when the filters need replacement.
• Upon activation of this alarm, contact a certified KENT service technician for filter replacement. Do not attempt to replace filters yourself unless specifically trained.

5.2 UV Fail Alarm

• A UV Fail Alarm will alert you if the UV lamp is malfunctioning or has reached its end of life.
• UV lamp is critical for disinfecting water; if this alarm activates, contact service immediately. Do not consume water from the purifier until the UV lamp is replaced or repaired.

5.3 Cleaning the Detachable Tank

• The transparent, detachable storage tank can be easily removed for manual cleaning.
• Before cleaning, ensure the purifier is powered off and the water supply is disconnected.
• Carefully remove the tank and clean it with a mild soap solution and soft brush. Rinse thoroughly with clean water before reattaching.
• Regular cleaning of the tank helps maintain hygiene and water quality.

5.4 Obecné čištění

• Wipe the exterior of the purifier with a soft, damp tkanina. Nepoužívejte agresivní chemikálie nebo abrazivní čisticí prostředky.
• Keep the area around the purifier clean and free from dust and debris.

6. Řešení problémů

If you encounter any issues with your KENT Pearl RO Water Purifier, refer to the common problems and solutions below. For complex issues, always contact authorized service personnel.

For any issues not listed above or if the solutions do not resolve the problem, please contact KENT customer support.

7. Specifikace

Obrázek 5: Rozměry produktu

8. Záruka a podpora

Your KENT Pearl RO Water Purifier comes with comprehensive warranty and support to ensure peace of mind.

8.1 Informace o záruce

Součástí produktu je a 1-letá záruka on manufacturing defects, along with an additional 3 years of extended service (AMC) free of charge. Terms and conditions apply. Please refer to the warranty card provided with your product for full details.

8.2 Zákaznická podpora

For installation requests, service appointments, or any technical assistance, please contact KENT customer support through the details provided in your product documentation or visit the official KENT webmísto.

Můžete také navštívit Obchod KENT na Amazonu pro více informací.
