Wireless Intercom Manual
Model: HI05
Unlimited Communication, Unlimited Life!
Features
| * Full Duplex * Long Standby Time * 5 Ringtones Avaliable * Adjustable Volume * 1640ft Working Range |
* Type-C Charge Port * Rechargeable Battery * Low Battery Alert * Clear & Loud Voice |
Instruduction
The ChunHee HI05 Wireless Intercom is a simple and secure way to communicate between multiple intercoms within an area of up to 1,640ft (500m).
- Please read this manual thoroughly. It will help us to know how to use this intercom system and make the operation easier.
- The intercom contains non-repairable parts. Opening them may damage sensitive components and will void the warranty.
Parts List
 |
Intercom |
 |
Charge Station |
 |
USB Cable |
 |
Charge Adapter |
 |
User’s Manual |
* The product does not include lanyards and screws.
Specification
| Technology | Full Duplex |
| Frequency | 2404-2480 MHZ |
| Output Power | 2 W |
| Channel Quantity | 1 |
| Battery Cell Composition | Lithium Polymer |
| Battery Capacity | 1000mAh |
| Working Range | 500 Meters i.e. 1640ft |
| Weight | 95g |
| Standby Time(Fully Power) | 72-96 Hours |
| Operating Temperature | -20℉ -140℉ |
| Chimes Quantity | 5 Chimes |
| Volume Levels | 8 Levels |
| Size | 9.4*5.4*14.6cm(Including Charging Seat) |
* Actual working range may vary depending on the installation and operating environment
Overview
| ① Antenna ② Lanyard Hole ③ Speaker ④ Volume Decrease ⑤ Volume Increase ⑥ Power ⑦ Hang Up |
⑧ Call/Answer ⑨ Indicator ⑩ Mic ⑪ Charge Port ⑫ Lanyard Hole ⑬ Wall-mount Hole ⑭ Anti-slip Pad |
Basic Operate
- Turn ON/OFF
Turn ON: Hold the
button for 5 seconds till hear “Power On”to release.
Turn OFF: Hold the button for 5 seconds till hear“Power OFF”to release. - Volume Change
When the intercom on the ringing or calling status: Press the
to decrease the volume, Press the
to increase the volume levels.
* There are 8 volume levels available, you will hear a “Do”voice prompt sound when you press the or if the volume level is on the 1 (Min.) or 8 (Max.) level. - Intercom Pair
Hold the and buttons at the same time on the one intercom for 5 seconds till hear a “Searching” voice prompt to release.
Hold the and buttons at the same time on the other intercom that you need to connect for 5 seconds till hear a “Successful” voice prompt to pair. - Change the Ringtone
Hold the
button for 5 seconds until hear the ringtone to release the button to change the ringtone of the intercom (5 Chimes available).
*Note: You will hear a beep sound at first, but please keep holding the button till hear a ringtone sound to release. - Talk
Like a phone use:
Step 1: Press the
to calling the person you wanna talk with.
Step 2: The person you called press the to answer you. Then both of you can talk with each other.
Step 3: Press the button to finish the calling.
Video Guide
Indicator
* Charging Status:
- Turn off status: Red color while charging.
- Turn on status: Red color and with flashes blue color every 5 second.
Note: The light will goes out while fully charged.
* Standby Status: Blue color flashes every 5 seconds.
Low Battery Alert
On a full charge, the standby time of the intercom is about 7296 Hours. (Please charge the intercom before first use.) There has a low battery alert while the radio is low battery, it will send a voice prompt every 20 seconds until it is turned off. (If the radio runs out of power and turns off, turn it on when fully charged.)
Warm Tips
- The microphone will beep while the device is within 1 meter.
Please don’t worry about it, just need to separate them from each other. - We suggest to place the product into the charge station to charge, it will protect the intercom.
- The intercom system does have not a waterproof design, please take the product away from water.
- The intercom system is powered by battery, please Do not place the the product in a flammable or explosive environment.
Troubleshooting
Q1: Can’t turn on the intercom.
A1: 1. Charge for the intercom at least 1 hour. 2. Wait 5 seconds then hold the power button for 5-8s till hear ‘Power On’ voice prompt.
Q2: The voice is weak or intermittent during receiving.
A2: 1. Recharge the battery. 2. Increase the volume level.
Q3: Can’t communicate with other intercom
A3: 1. Pair for the intercom. 2. All intercoms press the hang up button to stop talk, then one of the intercom press the Green Call button to make a new call, other intercoms waiting for the calling.
Q4: Unable to hear anyone because of too much noise and hiss.
A4: 1. Move towards other members (make the distance of the intercoms within 150ft). 2. Move to an open and flat area, restart the intercom, and try again. 3. Stay away from equipment that will cause interference. *If you have any question about the intercom, please contact us without hesitant!
Customer Guarantee
We provide a 30-day money-back guarantee for any reason (free shipping) and 1-year warranty (transportation prepaid) to the original purchaser against manufacturing defects in materials and workmanship.
Note: This Warranty is void if the damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration, improper or abnormal usage, or faulty installation, or any other reason.
Customer Service
Contact our friendly support team for quick solutions.
Friendly reminder: When contacting us for help, be sure to have your product handy for troubleshooting!
Contact us
* Order list–Choose the order–Get help with order.
* Contact our email to get service..
Email: Chunheeus@126.com
