Legrand 077213 Mosaic Socket Outlet Instruction Manual

1. Uvod

This manual provides essential information for the safe and correct installation, operation, and maintenance of the Legrand 077213 Mosaic Socket Outlet. Please read these instructions carefully before proceeding with installation or use, and retain them for future reference.

2. Sigurnosne informacije

UPOZORENJE: Electrical work should only be performed by qualified and authorized personnel. Failure to follow these instructions can result in electric shock, fire, or serious injury.

• Always disconnect power at the main circuit breaker or fuse box before installing or servicing the device.
• Ensure all wiring connections are secure and comply with local electrical codes and regulations.
• Ne postavljati u mokro ili damp lokacijama, osim ako nisu posebno namijenjene za takva okruženja.
• Do not exceed the specified electrical ratings of the socket outlet.

3. Sadržaj paketa

Prije početka instalacije provjerite jesu li sve komponente prisutne i neoštećene:

• 1 x Legrand 077213 Mosaic Socket Outlet module
• Upute za instalaciju (ovaj dokument)

4. Postavljanje i instalacija

The Legrand 077213 is a plugless module designed for integration into a compatible Mosaic mounting frame or support. It does not come with an integrated plug for direct connection to a power source.

1. Isključivanje struje: Before starting, ensure the main power supply to the installation area is switched off at the circuit breaker. Use a voltagtesterom kako biste potvrdili da nema napajanja.
2. Priprema montaže: If not already in place, install the appropriate Legrand Mosaic mounting frame or box according to its specific instructions.
3. Ožičenje: Connect the electrical wires to the terminals on the back of the 077213 socket module. Ensure correct polarity (Live, Neutral, Earth) as indicated on the device. Tighten terminal screws securely to prevent loose connections.
4. Umetanje modula: Carefully clip the 077213 socket module into the designated slot within the Mosaic mounting frame. Ensure it sits flush and is securely fastened.
5. Instalacija poklopca: Attach the decorative cover plate (if applicable and sold separately) over the installed module and frame.
6. Obnova napajanja: Once installation is complete and all connections are verified, restore power at the main circuit breaker.

Image 1: Legrand 077213 Mosaic Socket Outlet module. This image shows the front view of the yellow socket module, ready for installation into a compatible Mosaic frame.

5. Uputstvo za upotrebu

Once installed and powered, the Legrand 077213 Mosaic Socket Outlet functions as a standard electrical outlet. To use:

1. Ensure the device you wish to connect is compatible with the socket's electrical ratings.
2. Insert the plug of your electrical appliance firmly into the socket outlet.
3. To disconnect, pull the plug directly out of the socket. Do not pull by the cord.

6. Održavanje

The Legrand 077213 Mosaic Socket Outlet requires minimal maintenance. Regular inspection and cleaning can help ensure its longevity and safe operation.

• čišćenje: Disconnect power before cleaning. Wipe the surface with a soft, dry, or slightly damp krpu. Ne koristite abrazivna sredstva za čišćenje, rastvarače ili prekomjernu vlagu.
• inspekcija: Periodically check the socket for any signs of damage, such as cracks, discoloration, or loose connections. If any damage is observed, disconnect power and have the unit inspected and replaced by a qualified electrician.

7. Otkrivanje problema

If the socket outlet is not functioning correctly, consider the following common issues:

• Nema napajanja: Check the circuit breaker or fuse for the circuit. Ensure it has not tripped. Verify that the main power supply to the building is active.
• Slaba veza: If you suspect a loose wire, disconnect power and have a qualified electrician inspect the wiring connections.
• Oštećena utičnica: Ako utičnica izgleda fizički oštećeno, mora je zamijeniti kvalificirani električar.

If problems persist after checking these points, contact a qualified electrician for assistance.

8. Specifikacije

9. Informacije o garanciji

Legrand products are manufactured to high standards and are covered by a limited warranty against defects in materials and workmanship. The specific terms and duration of the warranty may vary by region and product type. Please refer to the official Legrand website or contact customer support for detailed warranty information applicable to your purchase.

10. Podrška

For technical assistance, product inquiries, or to report an issue, please contact Legrand customer support through their official website or the contact information provided with your purchase. When contacting support, please have your product model (077213) and purchase details ready.

Legrand Official Webstranica: www.legrand.com
