brother logobrother DCPL1630W Multi Function PrinterD036JX00
UK
Version 0
Quick Setup Guide

DCP-L1630W/DCP-L1632W

DCPL1630W Multi Function Printer

Read the Product Safety Guide first, then read this Quick Setup Guide for the correct installation procedure.
Not all models are available in all countries.
brother DCPL1630W Multi Function Printer - icon The latest manuals are available on the Brother support website: support.brother.com/manuals

Unpack the machine and check the components

brother DCPL1630W Multi Function Printer - componentsRemove the protective tape or film covering the machine and the supplies. brother DCPL1630W Multi Function Printer - components 1

NOTE:

  • The components included in the box may differ depending on your country.
  • The available connection interfaces vary depending on the model.
  • If you use a wired connection, you must purchase the correct cable for the interface you want to use.
  • USB cable
    We recommend using a USB 2.0 cable (Type A/B) that is no more than  2 metres long.
  • Network cable
    Use a straight-through Category 5 (or greater) twisted-pair cable.
  • The screens and images in this Quick Setup Guide show the DCP-L1632W.
  • Brother aims to reduce waste and save both raw materials and the energy required to produce them.
  • Read more about our environmental work at www.brotherearth.com.
  • Save all packing materials and the box in case you need to ship your machine.

Remove the packing materials and install the toner cartridge

brother DCPL1630W Multi Function Printer - assembly

Load paper in the paper tray

brother DCPL1630W Multi Function Printer - assembly 1brother DCPL1630W Multi Function Printer - assembly 2

Connect the power cord and turn the machine on

brother DCPL1630W Multi Function Printer - assembly 3

Select your country/language (Initial setup only)

After turning the machine on, you may be required to set your country or language (depending on your machine).
If required, follow the on-screen instructions.

Select your language (if needed)

  • Press Menu.
  • Press brother DCPL1630W Multi Function Printer - icon 1 todisplay [Initial Setupl,and then press OK.
  • Press brother DCPL1630W Multi Function Printer - icon 1todisplay [Local Languagel, and then press OK.
  • Press brother DCPL1630W Multi Function Printer - icon 1 to select your language, and then press OK.
  • Press Stop/Exit.

Connect your computer or mobile device to your machine

Follow these steps to complete the setup using one of the connection types available on your machine.
Visit setup.brother.com to download and install Brother software. brother DCPL1630W Multi Function Printer - assembly 4Follow the on-screen instructions and prompts.
Setup Finished
You can now print and scan using your machine.
Important Notice for Network Security:
The default password to manage this machine’s settings is located on the back of the machine and marked “Pwd”.
We recommend immediately changing the default password to protect your machine from unauthorised access.
Can’t Connect? Check the following: brother DCPL1630W Multi Function Printer - assembly 5

Manual wireless setup (Wireless models)

If the wireless setup is unsuccessful, set up the connection manually.
Find your SSID (Network Name) and Network
Key (Password) on your wireless access point or router and write them in the table provided below.

SSID (Network Name)
Network Key (Password)

brother DCPL1630W Multi Function Printer - assembly 6Press Menu, and then select
[Network] >
[WLAN (Wi-Fi)] >
[Find Network).
Follow the LCD instructions
If you cannot find this information, ask your network administrator or wireless access point or router manufacturer.
Select the SSID (Network Name) for your access point or router and enter the Network Key (Password).
Press and hold (or press repeatedly) brother DCPL1630W Multi Function Printer - icon 1 to select one of the following characters:
0123456789abcdefghijkimnopgrstuvwxyz
ABCDEFGHIJKLMNOPQRSTUVWXYZ
(space)l”#8%8′()*+.-./;<=>?@N”_{l}~
Go to 6 to install software.
When the wireless setup is successful, the  LCD displays [Connected].
If the setup is unsuccessful, restart your Brother machine and your wireless access point or router, and repeat 7.
If still unsuccessful, visit support.brother.com.
For detailed machine information and prod the Online User’s Guide a support brother manuals.
© 2024 Brother Industries, Ltd. All rights reserved.            brother logobrother DCPL1630W Multi Function Printer - Bar code
