1. Introduction and Overview
Thank you for choosing the ECO-WORTHY EnergyTrek 12V 314Ah LiFePO4 Lithium Battery and 20A Charger. This manual provides essential information for the safe and efficient operation of your product. Please read it thoroughly before use.
The ECO-WORTHY 12V 314Ah EnergyTrek LiFePO4 battery is designed for reliable power storage, featuring a robust 200A Battery Management System (BMS) for comprehensive protection. It comes bundled with a versatile 12V/24V 20A LiFePO4 Battery Charger, capable of automatically detecting voltage and offering multiple current options (5A/10A/15A/20A for 12V, 5A/10A for 24V) to ensure safe charging based on battery capacity.
Key features include real-time battery status monitoring via Bluetooth using the 'ECO-WORTHY' app, which displays voltage, current, and capacity. The app supports 9 languages for user convenience. The integrated 200A BMS provides protection against overvoltage, undervoltage, overcurrent, high temperatures, short circuits, and includes a crucial low-temperature cutoff function. Charging stops at -7 °C, discharging at < -20 °C, and charging resumes at ≥ 0 °C, preventing damage and extending battery life, especially in cold conditions.
This battery is highly scalable, compatible with 4P2S/2P4S configurations, allowing connections of up to 4 batteries in series and 4 in parallel. This enables the creation of systems such as 25.6V 1256Ah or 51.2V 628Ah, offering a maximum energy storage capacity of 32.15 kWh for home storage and comprehensive solar installations.
2. Safety Information
Always prioritize safety when handling batteries and electrical equipment. Failure to follow these instructions can result in serious injury or damage to the product.
- BMS Protection: The integrated 200A BMS protects against overvoltage, undervoltage, overcurrent, high temperatures, and short circuits.
- Low-Temperature Operation: The BMS will stop charging if the battery temperature drops below -7 °C and stop discharging if it drops below -20 °C. Charging will resume when the temperature is ≥ 0 °C. Do not attempt to force charge or discharge outside these parameters.
- Ventilation: Ensure adequate ventilation around the battery during charging and discharging to prevent heat buildup.
- Connections: Always ensure connections are secure and correct polarity is observed (positive to positive, negative to negative). Loose connections can cause sparks and overheating.
- Inverter Compatibility: When connecting to an inverter, be aware of potential high inrush currents. Some inverters may trigger the BMS protection due to high startup current (>200A). Consider using a pre-charge resistor or a soft-start feature if available on your inverter.
- Installation in Vehicles: This battery does not possess an ECE R10 certificate. Therefore, it is not permitted for permanent installation in an RV or for connection to the vehicle's electrical system while driving. It can be transported and used within an RV when stationary.
- Water and Moisture: Keep the battery and charger away from water and excessive moisture.
- Children and Pets: Keep the battery and charger out of reach of children and pets.
3. What's in the Box
Upon unpacking, please verify that all components are present and undamaged:
- 1 x ECO-WORTHY EnergyTrek 12V 314Ah LiFePO4 Battery
- 1 x ECO-WORTHY 20A Smart Battery Charger
4. Setup
4.1 Initial Inspection
Before first use, inspect the battery and charger for any visible damage. If any damage is found, do not use the product and contact customer support.
4.2 Connecting the Charger to the Battery
Follow these steps to connect the charger to your battery:
- Step 1: Connect to Mains Power. Plug the charger into a suitable AC power outlet. The charger display will illuminate.
- Step 2: Select Battery Mode. Before connecting to the battery, press the 'MODE' button on the charger to select the appropriate battery type (LiFePO4, AGM, Gel, Lead-Acid) and charging current (5A/10A/15A/20A for 12V, 5A/10A for 24V). The battery type cannot be changed after connecting to the battery.
- Step 3: Connect the Battery. Connect the charger's positive (+) cable (red) to the battery's positive (+) terminal and the negative (-) cable (black) to the battery's negative (-) terminal. Ensure a secure connection. The charger will begin charging automatically.
Figure 4.1: Charger Connection Steps
4.3 Connection Terminals
The battery features M8 terminals for reliable and secure connections, along with an improved Anderson connector for easy and safe plug-and-play connections.
Figure 4.2: M8 Terminals and Anderson Connector
4.4 Series and Parallel Connection
The ECO-WORTHY 12V 314Ah EnergyTrek LiFePO4 battery supports configurations of up to 4 batteries in series and 4 in parallel (4P2S/2P4S). This allows for creating systems up to 25.6V 1256Ah or 51.2V 628Ah, with a maximum energy storage capacity of 32.15 kWh. Ensure all batteries are of the same voltage and capacity when connecting in series or parallel, and follow proper wiring diagrams for safe and balanced operation.
Figure 4.3: Battery Dimensions and Configuration Capability
5. Operating Instructions
5.1 Charging the Battery
Use the provided 20A Smart Battery Charger. Select the appropriate voltage and current mode before connecting to the battery. The charger will display the charging status. Charging times vary based on battery capacity and selected current:
- A 12V 100Ah battery fully charges in approximately 5 hours with a 12V 20A current.
- A 12V 314Ah battery fully charges in approximately 16 hours with a 12V 20A current.
- A 24V 100Ah battery fully charges in approximately 10 hours with a 24V 10A current.
Figure 5.1: Charging Efficiency Overview
5.2 Bluetooth Monitoring
Download the 'ECO-WORTHY' app on your smartphone to monitor the battery's status in real-time. The app provides data such as voltage, current, and remaining capacity (SOC). The Bluetooth connection range is up to 25 meters in a straight line without obstacles.
Figure 5.2: Real-time Battery Monitoring via Bluetooth App
5.3 Low-Temperature Operation
The BMS automatically manages charging and discharging in cold conditions:
- Charging is interrupted at -7 °C.
- Discharging is interrupted at < -20 °C.
- Charging resumes at ≥ 0 °C.
This feature protects the battery from damage and extends its lifespan during winter use.
5.4 Storage Mode
The battery features an ultra-low self-consumption storage mode to reduce standby power consumption, preserving charge over longer periods when not in use.
Figure 5.3: Battery Storage Mode for Reduced Self-Consumption
6. Maintenance
Proper maintenance ensures the longevity and performance of your ECO-WORTHY battery:
- Regular Inspection: Periodically check the battery terminals and cables for corrosion or loose connections. Clean terminals if necessary.
- Temperature Management: Avoid operating or storing the battery in extreme temperatures outside the specified range. The BMS provides protection, but optimal performance is achieved within recommended temperatures.
- Charging: Always use the dedicated ECO-WORTHY 20A Smart Battery Charger. Do not use chargers not designed for LiFePO4 batteries.
- Storage: For long-term storage, ensure the battery is charged to approximately 50-70% State of Charge (SOC) and stored in a cool, dry place. The battery's storage mode helps minimize self-discharge.
- Cleaning: Keep the battery clean and free from dust and debris. Use a dry cloth for cleaning.
7. Troubleshooting
7.1 Automatic Alarm and Status Indicators
The battery features unique SOC and status indicator lights for quick detection of battery level and condition. If the battery enters an abnormal state, an alarm will sound automatically. This alarm can be deactivated via the 'ECO-WORTHY' app or the control panel on the battery (if applicable).
Figure 7.1: Battery Internal Components and Protection Features
7.2 BMS Reset
In certain situations, such as after a protection event (e.g., overcurrent shutdown), the BMS may need to be reset. Please note that the BMS can typically only be reset via a charger. It cannot be reset via a button on the battery, through the app, or by simply disconnecting the load and waiting. If the BMS has triggered protection, connect the battery to the ECO-WORTHY 20A Smart Battery Charger to reset it.
7.3 Inverter Inrush Current
If connecting the battery to an inverter and the BMS immediately shuts down, it may be due to a high inrush current from the inverter (>200A). The BMS is designed to protect the battery from excessive current. To mitigate this, consider using a pre-charge resistor or an inverter with a soft-start function to limit the initial current surge.
8. Specifications
Figure 8.1: Charger Specifications Overview
| Feature | Specification |
|---|---|
| Brand | ECO-WORTHY |
| Model Number | 12V 314AH |
| Output Voltage | 12 Volts (DC) |
| Input Voltage | 12 Volts (DC) |
| Current Rating (Charger) | 20 A |
| UPC | 810198856200 |
| Number of Items | 1 |
| Manufacturer | ECO-WORTHY |
| Country of Origin | China |
| Box Contents | 1 x 12V 314Ah LiFePO4 Battery + 1 x 20A Charger |
| BMS Protection | 200A with Low-Temperature Cutoff |
| Low-Temp Charge Cutoff | -7 °C |
| Low-Temp Discharge Cutoff | < -20 °C |
| Charge Resume Temp | ≥ 0 °C |
| Connectivity | Bluetooth (ECO-WORTHY App) |
| Max System Energy (4P2S/2P4S) | 32.15 kWh |
9. Warranty
The ECO-WORTHY EnergyTrek 12V 314Ah LiFePO4 Lithium Battery and 20A Charger come with a 3-year warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use. Please retain your proof of purchase for warranty claims. The warranty does not cover damage caused by misuse, neglect, improper installation, or unauthorized modifications.
10. Support
For technical assistance, troubleshooting, or warranty inquiries, please contact ECO-WORTHY customer support. You can typically find contact information on the official ECO-WORTHY website or through your purchase platform.
Website: www.eco-worthy.com (Please check the official website for the most current contact details and support resources.)
