1. Product Overview
The Beurer BiteX Max is a heated insect bite healer designed to provide rapid relief from itching and swelling caused by insect bites and stings. It utilizes targeted heat application, offering a chemical-free solution. This device is suitable for various users, including diabetics and pregnant women, and is equipped with a rechargeable battery and an integrated light for enhanced usability.
- Rapid Relief: Effectively alleviates itching and swelling from mosquito, wasp, bee, and other insect bites through heat.
- Larger Heating Surface: Features an optional enlarged heating ring, ideal for multiple bites or larger affected areas.
- Rechargeable Battery: Easily recharges via USB-C cable, providing up to 500 applications per charge. No disposable batteries required.
- Integrated Light: The BiteSpotLight allows for precise application even in low-light conditions.
- Chemical-Free: Operates solely by heat, avoiding sticky residues or oily sensations associated with creams or sprays.
Figure 1: Beurer BiteX Max device, front view.
2. Safety Information
Please read these instructions carefully before using the device and keep them for future reference. Failure to follow these instructions may result in injury or damage to the device.
- Do not use on open wounds, irritated skin, or mucous membranes.
- Avoid prolonged contact with the skin to prevent burns.
- If you experience excessive pain, redness, or blistering, discontinue use immediately and consult a medical professional.
- Keep the device out of reach of children. Adult supervision is recommended when used by children.
- Consult your doctor before use if you have sensitive skin, circulatory problems, or any pre-existing medical conditions.
- The device is not a substitute for medical treatment. If symptoms persist or worsen, seek medical advice.
- Do not immerse the device in water or other liquids.
- Use only the provided USB-C cable for charging.
3. Package Contents
Verify that all items are present and undamaged upon unpacking:
- 1 x Beurer BiteX Max Insect Bite Healer Pen
- 1 x USB-C Charging Cable
- 1 x User Manual
4. Setup
4.1 Charging the Device
Before first use, fully charge the Beurer BiteX Max. Connect the provided USB-C cable to the device's charging port and plug the other end into a suitable USB power source (e.g., computer, USB wall adapter). The charging indicator light will show the charging status. A full charge provides approximately 500 applications.
Figure 2: USB-C charging port on the Beurer BiteX Max.
5. Operating Instructions
5.1 Powering On/Off
Press and hold the power button (usually marked with a circle and a vertical line) for a few seconds to turn the device on or off. An indicator light will confirm the power status.
5.2 Applying the Device
Place the heating surface of the device directly onto the insect bite. Ensure full contact with the skin. The device offers two treatment programs:
- 3-second program: For sensitive skin. Press the button marked '3s'.
- 6-second program: For normal skin or more intense relief. Press the button marked '6s'.
The device will automatically heat up and then switch off after the selected duration. You may feel a slight warming sensation during treatment. Repeat application if necessary, but allow a short break between treatments on the same spot.
Figure 3: Applying the Beurer BiteX Max to an insect bite.
5.3 Using the BiteSpotLight
The Beurer BiteX Max features an integrated light to help locate insect bites in the dark. Press the light button (usually marked with a lightbulb icon) to activate or deactivate the BiteSpotLight. This feature is particularly useful for outdoor activities at night.
Figure 4: Using the BiteSpotLight for precise application in the dark.
Figure 5: Overview of Beurer BiteX Max controls and features.
6. Maintenance
6.1 Cleaning
Clean the device regularly with a slightly damp, soft cloth. Do not use abrasive cleaning agents or immerse the device in water. Ensure the device is completely dry before storing or recharging.
6.2 Storage
Store the Beurer BiteX Max in a cool, dry place, away from direct sunlight and extreme temperatures. Keep it in its original packaging or a protective case to prevent damage.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Device does not turn on. | Battery is depleted. | Charge the device using the USB-C cable. |
| No heat or insufficient heat. | Poor contact with skin or low battery. | Ensure full contact with the bite. Recharge the device. |
| Itching persists after treatment. | Bite may be severe, or treatment was not applied immediately. | Apply the device as soon as possible after a bite. You may repeat the application after a short break. If symptoms persist, consult a doctor. |
| Device indicator light not working. | Device malfunction or low battery. | Recharge the device. If the issue persists, contact customer support. |
8. Specifications
- Model Number: 10730
- Dimensions (L x W x H): 10.5 x 2.2 x 10.8 cm
- Weight: 150 grams
- Power Source: Rechargeable battery via USB-C
- Programs: 3-second (sensitive skin), 6-second (normal skin)
- Manufacturer: Beurer GmbH
- Country of Origin: China
9. Warranty
This Beurer product is covered by a limited manufacturer's warranty. For specific warranty terms and conditions, please refer to the warranty card included with your purchase or visit the official Beurer website. Keep your proof of purchase for warranty claims.
10. Support
For technical assistance, product inquiries, or to report any issues, please contact Beurer customer service. Contact details, including phone numbers and email addresses, can typically be found on the product packaging, the official Beurer website (www.beurer.com), or in the warranty documentation.
