1. Introduction
Thank you for choosing the Albott 35,000 BTU Swimming Pool Heater Pump. This manual provides essential information for the safe installation, operation, and maintenance of your new pool heater. Please read this manual thoroughly before installation and use, and retain it for future reference. This unit is designed to efficiently heat and cool pools up to 10,000 gallons, extending your swimming season and enhancing your pool experience.
2. Safety Information
Important Safety Instructions:
- Always disconnect power to the unit before performing any service or maintenance.
- Installation must be performed by a qualified professional in accordance with all local and national electrical and plumbing codes.
- Ensure the power supply matches the unit's requirements (220V, 60Hz).
- Keep children away from the unit during operation.
- Do not operate the unit if any part is damaged or missing.
- Maintain proper clearance around the unit for adequate airflow.
- Never block the air intake or exhaust vents.
3. Product Features
- Dual-Mode Operation: Heats water from 44.6℉ to 104℉ and cools from 44.6℉ to 83℉, allowing for year-round pool comfort.
- Rapid Heating: Delivers 35,000 BTUs of warmth, efficiently heating pools up to 10,000 gallons.
- Smart APP & Control Panel: Control temperature, track energy usage, and set schedules remotely via a dedicated mobile application or directly from the unit's control panel.
- Inverter Energy Efficiency: Variable frequency technology provides a 12.2 COP (Coefficient of Performance), saving up to 70% energy compared to electric heating and 40% more efficient than gas systems.
- Whisper-Quiet Operation: Operates at a low noise level of 35 dB, ensuring a peaceful pool environment.
- Smart Defrost System: Guarantees consistent performance even in colder conditions.
- Easy Installation: Designed for seamless integration with most pool systems.
Image: The Albott 35,000 BTU High-Performance Pool Heat Pump, highlighting its 220V/60Hz power, capacity for up to 10,000 gallons, and energy-efficient design.
Image: Visual representation of maximized heating and savings, indicating 50% faster heating and 40% energy savings with the Albott pool heater.
Image: The Albott pool heater operating quietly at 35 dB next to a pool, with a person relaxing nearby, emphasizing its low noise level.
4. Package Contents
Verify that all components are present in the package:
- Albott 35,000 BTU Swimming Pool Heater Pump Unit
- Instruction Manual
- 2 Connectors
- 4 Dampening Washers
- Drain Assembly
Image: Diagram showing the product dimensions (38.7" x 13.4" x 25.9") and included accessories: Instruction Manual, 2 Connectors, 4 Dampening Washers, and Drain Assembly.
5. Setup and Installation
Proper installation is crucial for the performance and longevity of your pool heater. Consult a qualified professional for electrical and plumbing connections.
5.1 Site Selection
- Place the unit on a solid, level surface.
- Ensure adequate airflow by maintaining at least 20 inches of clearance around the unit.
- Avoid placing the unit near windows or vents of your home to prevent noise disturbance.
5.2 Plumbing Connections
Connect the pool heater to your existing pool filtration system using PVC pipes. The unit includes connectors and dampening washers for secure connections. Ensure all connections are watertight.
Image: Illustrates the use of PVC pipe to link the system and emphasizes ensuring the drain hose remains securely attached during operation. Note: The hose is not included and must be purchased separately.
5.3 Electrical Connections
The Albott pool heater requires a 220V, 60Hz power supply. All electrical wiring must comply with local codes and be performed by a licensed electrician. Ensure a dedicated circuit with appropriate overcurrent protection is used.
5.4 Initial Startup
Before powering on the unit, ensure the pool pump is running and water is flowing through the heater. Check for any leaks in the plumbing connections.
Video: This video demonstrates how to connect the hoses to the pool heat pump and secure them with clamps, providing a visual guide for the plumbing setup.
6. Operating Instructions
Your Albott pool heater offers flexible control options for optimal pool temperature management.
6.1 Control Panel Operation
The integrated control panel allows you to:
- Turn the unit ON/OFF.
- Select heating or cooling mode.
- Set desired water temperature (Heating: 44.6℉-104℉; Cooling: 44.6℉-83℉).
- View current water temperature and operating status.
6.2 Smart App Control
Download the Albott app to your smartphone for remote control and monitoring:
- Pair your device with the pool heater via Wi-Fi.
- Adjust temperature settings from anywhere.
- Monitor energy consumption.
- Set operating schedules.
Image: A hand holding a smartphone displaying the Albott app, demonstrating smart app control to effortlessly manage temperature and switch modes for the pool heater.
6.3 Extending Your Swim Season
The dual-mode system allows you to maintain stable water temperatures year-round, extending your swimming season into cooler months.
Image: A graphic illustrating the extended swimming season with a pool heater pump compared to without, showing stable water temperatures year-round.
7. Maintenance
Regular maintenance ensures optimal performance and extends the lifespan of your Albott pool heater.
- Clean the Coils: Periodically inspect and clean the evaporator coils to remove dirt, leaves, and debris that can obstruct airflow.
- Check Water Flow: Ensure consistent water flow through the unit. Reduced flow can impact heating efficiency.
- Inspect Electrical Connections: Annually, have a qualified electrician inspect all electrical connections for tightness and corrosion.
- Winterization: In regions with freezing temperatures, properly winterize the unit by draining all water and covering it to prevent damage. Refer to the full instruction manual for detailed winterization steps.
- Drain Assembly: Ensure the drain hose remains securely attached during operation to manage condensation.
8. Troubleshooting
If you encounter issues with your pool heater, refer to the following common troubleshooting tips:
| Problem | Possible Cause | Solution |
|---|---|---|
| Unit not turning on | No power, tripped breaker, faulty wiring | Check power supply, reset breaker, consult electrician |
| Insufficient heating/cooling | Low water flow, dirty coils, incorrect temperature setting, unit undersized for pool | Check pool pump, clean coils, verify settings, ensure unit matches pool volume |
| Unusual noise | Debris in fan, loose components, compressor issue | Inspect fan for obstructions, tighten loose parts, contact support if compressor noise persists |
| Water leaks | Loose plumbing connections, damaged pipes, condensation | Tighten connections, repair/replace damaged pipes, ensure drain assembly is clear for condensation |
For more complex issues or if troubleshooting steps do not resolve the problem, please contact customer support.
9. Specifications
| Specification | Detail |
|---|---|
| Model Number | BI02V1-1B2B0 |
| Product Dimensions | 38.8 x 13.4 x 25.9 inches |
| Item Weight | 102.5 pounds |
| Heating Capacity | 35,000 BTU |
| Recommended Pool Size | Up to 10,000 Gallons |
| Power Supply | 220V, 60Hz |
| COP (Coefficient of Performance) | 12.2 |
| Noise Level | As low as 35 dB |
| Manufacturer | EXINDA |
10. Warranty and Support
Your Albott pool heater is backed by a manufacturer's warranty. For specific warranty details, please refer to the documentation included with your product or contact the seller.
- Return Policy: This product typically includes a 30-day return/replacement policy.
- Protection Plans: Extended protection plans, such as a 2-Year Protection Plan, may be available for purchase.
- Customer Support: For technical assistance, troubleshooting, or warranty claims, please contact the seller, Happy Tao, or visit the official Albott website for support resources.
