Introduction
This manual provides essential information for the safe and effective use of your MT Helmets Track SV Pure Full Face Helmet. Please read these instructions carefully before using your helmet and retain them for future reference.
The MT Helmets Track SV Pure Full Face Helmet is designed for motorcyclists, offering a blend of modern trail design with advanced technical solutions for performance and safety on and off-road. Key features include a lightweight and durable HIRP (High Impact Resistant Polymer) shell, a retractable MT-ESP sun visor, removable antibacterial interior padding, and an ERS (Emergency Release System). The helmet is ECE 22.06 approved, ensuring high safety standards, and is prepared for UCS intercom integration.
1. Setup and Initial Adjustment
1.1 Proper Helmet Fit
A helmet must fit snugly to provide maximum protection. To check the fit:
- Place the helmet on your head. It should feel tight and exert even pressure around your head.
- Fasten the chin strap securely.
- With the strap fastened, try to move the helmet from side to side and up and down. Your skin should move with the helmet. If the helmet slides independently, it is too large.
- Ensure there are no pressure points that cause discomfort.
1.2 Chin Strap Adjustment
The chin strap is crucial for keeping the helmet in place. Ensure it is always fastened correctly.
- Thread the strap through the D-rings (or buckle system) as instructed by the specific closure type.
- Pull the strap until it is tight against your throat, without causing discomfort.
- There should be no slack, and you should not be able to pull the helmet off your head when the strap is fastened.
1.3 Visor Operation
The clear outer visor can be opened and closed using the tab located on the lower edge. It features multiple detent positions for airflow control.
1.4 Retractable Sun Visor (MT-ESP)
The integrated MT-ESP sun visor can be deployed or retracted using the slider mechanism located on the side of the helmet. Use the sun visor only in bright conditions and retract it in low light or at night.
Image 1.1: Front view of the MT Helmets Track SV Pure Full Face Helmet. This image displays the overall shape, the main clear visor, and the chin ventilation system. The helmet is shown in a grey finish.
2. Operating Your Helmet
2.1 Wearing the Helmet
Always wear your helmet correctly and securely fastened when riding. Ensure the visor is clean and free from obstructions for clear vision.
2.2 Ventilation System
The Track SV helmet features adjustable ventilation ports on the chin and top of the helmet. These can be opened or closed to control airflow and reduce fogging or heat buildup. Experiment with different settings to find your preferred comfort level.
2.3 Emergency Release System (ERS)
The ERS allows for quick and safe removal of the cheek pads by emergency personnel in the event of an accident. This system helps to minimize movement of the rider's head and neck during helmet removal. Do not attempt to use the ERS yourself unless you are trained to do so in an emergency situation.
3. Maintenance and Care
3.1 Cleaning the Helmet Shell
Clean the helmet shell with a soft cloth, warm water, and mild soap. Avoid harsh chemicals, solvents, or abrasive cleaners, as these can damage the helmet's finish and protective properties.
3.2 Visor Cleaning and Removal
Clean the visor with warm water and a soft cloth. For stubborn dirt, use a helmet-specific visor cleaner. To remove the visor for thorough cleaning or replacement, refer to the quick-release mechanism instructions (typically a lever or button near the visor pivot points). Reinstall carefully, ensuring it clicks securely into place.
3.3 Interior Padding Care
The interior padding is removable and washable. Gently detach the padding components. Hand wash them in cool water with mild soap, or machine wash on a delicate cycle in a laundry bag. Allow to air dry completely before reinstalling. Do not tumble dry or expose to direct heat.
3.4 Storage
Store your helmet in a cool, dry place away from direct sunlight and extreme temperatures. Use a helmet bag to protect it from scratches and dust. Do not store the helmet near chemicals or solvents.
4. Troubleshooting
4.1 Visor Fogging
If your visor fogs up, ensure the ventilation ports are open. You can also slightly crack open the main visor to allow more airflow. Anti-fog treatments or Pinlock inserts (if compatible and installed) can also help.
4.2 Loose Interior Padding
If the interior padding feels loose after cleaning or prolonged use, ensure all snaps and attachment points are securely fastened. If padding is worn, consider replacing it.
4.3 Chin Strap Issues
If the chin strap is difficult to fasten or unfasten, check for any obstructions or damage to the buckle mechanism. Ensure the strap is not twisted. If the buckle is damaged, the helmet should not be used.
5. Specifications
| Feature | Detail |
|---|---|
| Model Name | Track SV Pure Full Face Helmet |
| Shell Material | HIRP (High Impact Resistant Polymer) |
| Safety Standard | ECE 22.06 Homologation |
| Sun Visor | Integrated Retractable MT-ESP |
| Interior | Removable, Washable, Antibacterial Padding |
| Emergency System | ERS (Emergency Release System) |
| Intercom Ready | UCS Intercom Integration Prepared |
| Approximate Weight | 1500 g (varies by size) |
| Package Dimensions | 40 x 30 x 30 cm |
6. Warranty Information
This MT Helmets Track SV Pure Full Face Helmet comes with a two-year manufacturer's warranty. Please retain your proof of purchase for any warranty claims. The warranty covers manufacturing defects and material faults under normal use. It does not cover damage caused by accidents, misuse, unauthorized modifications, or normal wear and tear.
7. Support and Contact
For further assistance, spare parts, or specific inquiries not covered in this manual, please contact your authorized MT Helmets dealer or visit the official MT Helmets website. Always ensure any repairs or modifications are performed by qualified professionals using genuine MT Helmets parts.
