OUXI R7 Electric Bike User Manual

1. Introduction

Welcome to the OUXI R7 Electric Bike user manual. This guide provides essential information for the safe assembly, operation, maintenance, and troubleshooting of your new electric bicycle. Please read this manual thoroughly before your first ride to ensure optimal performance and safety.

2. Safety Information

Your safety is paramount. Always wear a helmet and appropriate safety gear when riding. Familiarize yourself with local e-bike regulations.

• Pre-Ride Check: Before each ride, inspect brakes, tires, battery, and all fasteners.
• Helmet Use: Always wear a certified helmet.
• Visibility: Use front and rear lights, especially during low light conditions.
• Weather Conditions: Exercise caution in wet or slippery conditions.
• Weight Limit: Do not exceed the maximum weight recommendation of 330 pounds.
• Battery Safety: Only use the provided charger. Do not tamper with the battery.

3. Setup and Assembly

Your OUXI R7 Electric Bike arrives 85% pre-assembled. Follow these steps to complete the assembly. A tool kit is included.

3.1 Unboxing and Initial Inspection

Carefully remove the electric bike from its packaging. Inspect all components for any signs of damage during transit.

3.2 Adjusting the Stem and Handlebar

Loosen the three bolts on the stem, turn the e-bike stem forward 180 degrees, and then tighten the three bolts. Loosen the four screws on the handlebar clamp, place the handlebar on the stem, adjust the angle to ensure it is level, and then tighten the four screws.

Image: A person adjusting the stem and handlebar of the OUXI R7 electric bike. This image illustrates the process of loosening and tightening bolts to correctly position the handlebar.

3.3 Installing the Front Wheel

Remove the fixing rod from the front fork. Align the front fork with the axle in the center of the front wheel. Insert the black quick release lever into the axle hole in the center of the wheel and lock the clamp securely.

Image: Close-up of the OUXI R7 electric bike's front wheel and fork during installation. This image shows the front wheel being aligned with the fork and the quick release mechanism.

3.4 Installing the Headlight and Front Fender

Loosen the screw on the front fork using the included tool. Attach the front fender and headlight in place. Tighten the screw and adjust the angle of the headlight for optimal visibility. Connect the headlight's connector to the main wire.

Image: A person installing the headlight and front fender on the OUXI R7 electric bike. This image highlights the front lighting system and fender attachment.

3.5 Installing the Pedals

Identify the left pedal (marked "L") and install it by turning counterclockwise. Identify the right pedal (marked "R") and install it by turning clockwise. Ensure both pedals are securely tightened.

Image: Close-up of the OUXI R7 electric bike's pedals. This image shows the pedal design and attachment point.

3.6 Installing the Seat and Rear Reflector

Insert the seat post into the frame and adjust the seat to a suitable height for comfortable riding. Secure the quick-release clamp. Place the non-slip band inside the half circle of the rear seat tube, then attach the warning light and tighten the screws.

Image: The OUXI R7 electric bike with its adjustable seat and rear reflector. This image demonstrates the proper positioning of the seat and the rear safety light.

3.7 Installing the Battery and Initial Charge

Carefully slide the 48V 13Ah removable battery into its compartment on the bike frame. Ensure it clicks securely into place. Before your first ride, fully charge the battery using the provided charger. The charger light will show "red" while charging and turn "green" when fully charged.

Image: The removable 48V 13Ah battery being installed into the OUXI R7 electric bike frame. This image also shows the charging process with indicator lights.

3.8 Inflating the Tires

Unscrew the lug nuts and inflate the 20" x 4.0" fat tires to the recommended pressure using a pump. Refer to the tire sidewall for specific pressure recommendations.

Image: A person inflating the fat tires of the OUXI R7 electric bike. This image emphasizes the importance of proper tire pressure for performance and safety.

4. Operating Instructions

4.1 Powering On/Off and Display Functions

To power on the bike, press and hold the power button on the LCD display. The display shows speed, battery level, PAS (Pedal Assist System) level, and distance. Use the '+' and '-' buttons to adjust PAS levels.

4.2 Riding Modes

The OUXI R7 offers multiple riding modes:

• Throttle Mode: Engage the throttle for motor-only propulsion.
• Pedal Assist Mode (5 levels): The motor provides assistance as you pedal. Adjust the level of assistance using the display.
• Booster Mode: Provides an extra boost of power.
• Cruise Mode: Maintains a set speed without continuous throttle input.
• Normal Bike Mode: Ride without any electrical assistance.

4.3 Gear Shifting

Your e-bike is equipped with a 7-speed gear system. Use the gear shifter on the handlebar to change gears according to terrain and desired speed. Shift smoothly to avoid strain on the drivetrain.

4.4 Braking System

The OUXI R7 features dual disc brakes for reliable stopping power. Apply both front and rear brakes simultaneously for effective and safe deceleration.

Image: Close-up view of the large dual disc brake rotors on the OUXI R7 electric bike. This image illustrates the braking mechanism for enhanced safety.

4.5 Lights

Activate the bright front and rear lights for increased visibility during night rides or in low-light conditions.

5. Maintenance

Regular maintenance ensures the longevity and safe operation of your OUXI R7 Electric Bike.

• Battery Care: Charge the battery regularly, even when not in use, to maintain its health. Avoid fully discharging the battery. Store in a cool, dry place.
• Tire Pressure: Check tire pressure before each ride. Maintain recommended PSI for optimal performance and safety.
• Brake Inspection: Regularly check brake pads and rotors for wear. Ensure brake levers are responsive.
• Chain Lubrication: Keep the chain clean and lubricated to prevent rust and ensure smooth gear changes.
• Fastener Check: Periodically check all bolts and screws for tightness.
• Cleaning: Clean your e-bike with a damp cloth. Avoid high-pressure washing directly on electrical components.

6. Troubleshooting

If you encounter issues with your OUXI R7, refer to the following common troubleshooting tips:

• Bike Not Powering On: Check if the battery is fully charged and securely installed. Ensure all electrical connections are firm.
• Motor Not Assisting: Verify the PAS level on the display. Check if the throttle is engaged or if there's an error code on the display.
• Brakes Squealing/Ineffective: Inspect brake pads for wear and replace if necessary. Ensure rotors are clean. Brakes may need adjustment or bleeding.
• Unusual Noises: Check for loose components, rubbing parts (e.g., fenders, brake rotors), or issues with the chain or gears.

For persistent issues, contact customer support.

7. Specifications

Image: Detailed diagram of the OUXI R7 electric bike showing key dimensions and load capacity.

8. Warranty and Support

The OUXI R7 Electric Bike comes with a 1-year manufacturer's warranty. For any questions, technical support, or warranty claims, please contact OUXI customer service.

• Email: ouxisupport@163.com
• Phone Number: 2137569618
• WhatsApp: +8615836892011

Image: OUXI customer support details, including contact information for assistance.
