1. Introduction
Welcome to your ULTIMEA Poseidon M30 2.1 Channel Soundbar. This manual provides essential information for the proper setup, operation, and maintenance of your sound system. Please read these instructions carefully before using the product to ensure optimal performance and longevity.
2. Package Contents
Verify that all items listed below are included in your package:
- 1 x Soundbar
- 1 x Wireless Subwoofer
- 1 x Soundbar Power Supply
- 1 x Subwoofer Power Supply
- 1 x HDMI Cable
- 2 x Wall Brackets
- 2 x Mounting Screws
- 4 x Wall Mounting Kits
3. Product Overview
The ULTIMEA Poseidon M30 is a 2.1 channel sound system designed to enhance your audio experience. It features a soundbar with precision-tuned drivers and a wireless subwoofer for deep bass. The system delivers up to 240W peak power, providing clear dialogue, detailed mid-range, and powerful bass for various media.
This image displays the ULTIMEA Poseidon M30 soundbar positioned below a television, accompanied by its wireless subwoofer. It highlights the system's 2.1 channel audio and 240W peak power capabilities, providing an immersive home audio experience.
The soundbar incorporates mica-reinforced diaphragms, which increase driver rigidity by up to 30%. This design suppresses cone breakup and unwanted resonance, reducing distortion by up to 20% for cleaner and more accurate sound.
This diagram provides an internal view of the ULTIMEA Poseidon M30 audio system, detailing the 2.25-inch midrange drivers within the soundbar and the 5.25-inch driver of the wireless subwoofer. It visually explains the true 2.1 channel audio system.
4. Setup
4.1. Placement
Position the soundbar centrally below your television for optimal stereo imaging. The wireless subwoofer offers flexible placement options, allowing you to position it anywhere in your room without the need for audio cables, optimizing bass distribution.
The image shows the ULTIMEA wireless subwoofer positioned on the floor beside a wooden cabinet, illustrating its compact design and the flexibility of placement due to its wireless connectivity, allowing for optimal sound distribution without spatial limitations.
4.2. Connections
The Poseidon M30 offers multiple connectivity options:
- HDMI ARC: Connect an HDMI cable from the soundbar's HDMI ARC port to your TV's HDMI ARC port. This allows for audio return channel functionality, enabling TV audio to be sent to the soundbar and control via the TV remote.
- Optical: Connect an optical cable from the soundbar's optical input to your TV's optical output.
- Bluetooth 6.0: For wireless audio streaming from compatible devices. Refer to the 'Bluetooth Pairing' section for detailed instructions.
This image features a close-up of an HDMI cable, highlighting its role in HDMI audio transmission. It signifies one of the primary methods for connecting the ULTIMEA Poseidon M30 soundbar to a television or other audio sources for high-quality digital sound.
4.3. Power On
Connect the soundbar and subwoofer to their respective power supplies and plug them into a wall outlet. The units will automatically power on or enter standby mode. Press the power button on the soundbar or remote control to turn the system on.
5. Operating Instructions
5.1. Basic Controls
Use the buttons on the soundbar or the provided remote control to manage power, adjust volume, and select input sources (HDMI, Optical, Bluetooth).
5.2. Sound Modes
The soundbar features 6 preset sound modes, allowing you to instantly optimize audio settings for different content types:
- Movies: Enhances cinematic soundscapes.
- Music: Provides balanced audio for musical playback.
- Games: Optimizes audio for gaming environments.
- Voices: Focuses on vocal clarity.
- Sports: Accentuates sports commentary and ambient sounds.
- Night: Reduces dynamic range for quieter listening.
This graphic presents the six distinct preset sound modes offered by the ULTIMEA Poseidon M30 soundbar. These modes allow users to instantly optimize audio settings for various content types, enhancing the listening experience.
5.3. VoiceMX Technology
VoiceMX technology utilizes advanced DSP algorithms to isolate and amplify speech frequencies in real-time. By dynamically amplifying the speech range from 120 Hz to 6 kHz with adaptive EQ and gain control, dialogue remains clear and easy to follow in any scene.
The image depicts a user enjoying television, with visual effects representing sound waves originating from the soundbar. This illustrates the VoiceMX technology, which enhances vocal clarity by dynamically optimizing speech frequencies, ensuring crystal-clear dialogue in any scene.
5.4. BassMX Technology
The wireless subwoofer features BassMX Deep Bass Technology, incorporating an 18mm long-excursion driver, a tuned 6.5-liter enclosure, and a high-density magnetic circuit. This optimizes bass frequencies from 45–150Hz for deeper, tighter, and more realistic sound at any volume.
5.5. App Control
Customize your sound experience using the Ultimea app. The app features a 10-band equalizer and 121 preset equalizer matrices, allowing you to fine-tune the sound for movies, music, and games. OTA updates ensure your system remains up to date with the latest features.
This image showcases two smartphones displaying the ULTIMEA app, demonstrating its advanced equalizer and customization options. Users can fine-tune their sound settings for movies, music, and games directly from their mobile device, providing personalized audio control.
5.6. Bluetooth Pairing
The soundbar supports Bluetooth 6.0 for fast and stable wireless streaming. To pair your device:
- Press the Bluetooth button on the remote control or soundbar to enter Bluetooth pairing mode. The indicator light will flash.
- On your mobile device, search for "ULTIMEA Poseidon M30" in the Bluetooth settings.
- Select the soundbar to connect. Once connected, the indicator light will become solid.
Bluetooth 6.0 delivers faster pairing, more stable wireless connections, and lower latency, ensuring reliable audio synchronization for music, podcasts, or videos.
6. Maintenance
To ensure the longevity and optimal performance of your ULTIMEA Poseidon M30 soundbar and subwoofer, follow these maintenance guidelines:
- Cleaning: Use a soft, dry cloth to clean the surfaces of the soundbar and subwoofer. Avoid using liquid cleaners, aerosols, or abrasive materials, as they may damage the finish.
- Ventilation: Ensure that the ventilation openings on the soundbar and subwoofer are not blocked. Proper airflow prevents overheating.
- Storage: If storing the unit for an extended period, disconnect it from the power source and store it in a cool, dry place away from direct sunlight and extreme temperatures.
- Avoid Moisture: Keep the devices away from water, humidity, and any liquids.
7. Troubleshooting
If you encounter issues with your ULTIMEA Poseidon M30, refer to the following common problems and solutions:
- No Power:
- Ensure both the soundbar and subwoofer power cables are securely plugged into a working electrical outlet.
- Check if the power indicator lights are on. If not, try a different outlet. - No Sound:
- Verify the correct input source is selected on the soundbar (HDMI, Optical, Bluetooth).
- Check the volume levels on both the soundbar and your connected device (TV, smartphone).
- Ensure all audio cables (HDMI, Optical) are securely connected.
- If using HDMI ARC, confirm your TV's HDMI ARC port is enabled and the TV's audio output is set to external speakers.
- For Bluetooth, ensure the device is paired correctly and within range. - Subwoofer Not Connecting:
- Ensure the subwoofer is powered on and its indicator light is active.
- The subwoofer should automatically pair with the soundbar. If not, refer to the manual for manual pairing instructions (if applicable).
- Move the subwoofer closer to the soundbar to rule out interference. - Distorted Sound:
- Reduce the volume to see if distortion decreases.
- Check audio source quality. Try a different source or input.
- Ensure cables are not damaged or loose. - Remote Control Not Working:
- Replace the batteries in the remote control.
- Ensure there are no obstructions between the remote and the soundbar's sensor.
8. Specifications
Detailed technical specifications for the ULTIMEA Poseidon M30 Soundbar System:
| Feature | Detail |
|---|---|
| Brand | ULTIMEA |
| Model Name | Poseidon M30 |
| Model Number | UC000 |
| Speaker Type | 2.1ch Sound Bar with Wireless Subwoofer |
| Number of Audio Channels | 2.1 |
| Maximum Speaker Power Output | 240 Watts (Peak) |
| Frequency Response | 45Hz–18kHz |
| Maximum SPL | 95dB |
| Signal-to-Noise Ratio | 102 dB |
| Connectivity Technology | HDMI ARC, Optical, Bluetooth 6.0 |
| Wireless Technology | Bluetooth 6.0 |
| Bluetooth Range | 15 Metres |
| Subwoofer Connectivity Technology | Wireless |
| Audio Driver Size (Subwoofer) | 18 Millimetres (long-excursion) |
| Control Method | App, Remote Control |
| Mounting Type | Table Mounting, Wall Mounted |
| Compatible Devices | Desktop, Home Theatre, Television |
| Power Source | Corded Electric |
| Soundbar Dimensions (D x W x H) | 9D x 60W x 7H centimetres (approx. 23.6 inches length) |
| Subwoofer Dimensions (W x D x H) | 15W x 30D x 20H centimetres |
| Item Weight | 5 Kilograms (total system) |
| Color | Black |
This technical drawing provides precise dimensions for both the ULTIMEA Poseidon M30 soundbar (600mm length, 90mm depth, 70mm height) and its wireless subwoofer (150mm width, 300mm depth, 200mm height). These measurements are crucial for planning placement and installation.
9. Warranty and Support
Your ULTIMEA Poseidon M30 Soundbar is covered by a manufacturer's warranty against defects in materials and workmanship. Please refer to the warranty card included in your package for specific terms and conditions, including the warranty period and coverage details.
For technical support, troubleshooting assistance, or warranty claims, please contact ULTIMEA customer service through the official website or the contact information provided in your product documentation. When contacting support, please have your model number (UC000) and purchase details ready.
