Edifier P230 USB-C Wired Earphones User Manual

Introduction

The Edifier P230 USB-C Wired Earphones are designed to provide a high-quality audio experience with modern device compatibility. Featuring a 12.4mm dynamic driver and USB-C connectivity, these earphones offer clear sound and reliable performance. This manual provides instructions for setup, operation, maintenance, and troubleshooting to ensure optimal use of your earphones.

What's in the Box

Please check the contents of your package. If any items are missing or damaged, contact your retailer.

• Edifier P230 USB-C Wired Earphones
• Eartips (S/M/L sizes)
• User Manual

Product Overview

The Edifier P230 earphones feature an in-ear design with an integrated USB-C connector and in-line controls for convenient audio management.

Figure 1: Overview of the Edifier P230 USB-C Wired Earphones, displaying the left and right earpieces, the in-line control unit, and the USB-C plug.

Figure 2: Detail of the USB-C connector, ensuring compatibility with modern devices.

In-line Control Functions

The in-line remote allows for easy control of audio playback, calls, and voice assistant activation.

Figure 3: In-line remote control functions.

• Volume Up: Press '+' button once.
• Volume Down: Press '-' button once.
• Play/Pause: Press the center button once.
• Answer/End Call: Press the center button once.
• Next Track: Press the center button twice.
• Previous Track: Press the center button three times.
• Activate Voice Assistant: Press and hold the center button.

Setup

1. Selecting Ear Tips

The Edifier P230 earphones come with three sizes of ear tips (Small, Medium, Large). Proper ear tip selection is crucial for comfort, sound quality, and noise isolation.

1. Try each size of ear tip to determine which provides the best seal and comfort in your ear canal.
2. A good seal will result in improved bass response and passive noise isolation.

2. Connecting to Your Device

The Edifier P230 earphones connect via a USB-C port.

1. Locate the USB-C port on your smartphone, laptop, or tablet.
2. Insert the USB-C connector of the earphones firmly into the device's USB-C port.
3. Your device should automatically recognize the earphones. If not, check your device's audio output settings.

Operating Instructions

Audio Playback

Once connected, you can play audio from your device. Use the in-line controls as described in the Product Overview section to manage playback and volume.

Making and Receiving Calls

The earphones feature an omnidirectional microphone for clear voice pickup.

• To Answer a Call: Press the center button on the in-line remote once.
• To End a Call: Press the center button on the in-line remote once during a call.

Using the Companion App (Android Only)

For Android users, a companion app is available to customize your listening experience.

1. Download the Edifier Connect app from the Google Play Store.
2. Connect your P230 earphones to your Android device.
3. Open the app to access four preset EQ modes and fully customizable equalizer settings.

Maintenance

Cleaning

• Gently wipe the earphones and ear tips with a soft, dry, lint-free cloth.
• For ear tips, you may use a slightly damp cloth with mild soap, then rinse and dry thoroughly before reattaching.
• Do not use harsh chemicals, cleaning solvents, or strong detergents.

Storage

• Store the earphones in a clean, dry place when not in use.
• Avoid extreme temperatures and direct sunlight.
• The oxygen-free copper wiring with nylon reinforcement is designed to be tangle-resistant, but proper coiling can extend cable life.

Water and Dust Resistance

The Edifier P230 earphones are IP54 rated, meaning they are protected against limited dust ingress and water splashes from any direction. This rating does not imply full waterproofing. Do not submerge the earphones in water.

Troubleshooting

If you encounter issues with your Edifier P230 earphones, refer to the following common solutions:

• No Sound or Low Volume:
  • Ensure the USB-C connector is fully inserted into your device.
  • Check your device's volume settings and the in-line volume controls.
  • Verify that the earphones are selected as the audio output device in your device's sound settings.
  • Test with another device to rule out a device-specific issue.
• Poor Sound Quality (e.g., lack of bass, muffled sound):
  • Ensure you are using the correct size ear tips for a secure and comfortable seal in your ear canal.
  • Clean any debris from the ear tips or earphone nozzles.
  • For Android users, check the EQ settings in the Edifier Connect app.
• Microphone Not Working:
  • Ensure the earphones are properly connected.
  • Check your device's microphone input settings to ensure the earphones are selected.
  • Ensure the microphone is not obstructed.
• In-line Controls Not Responding:
  • Ensure the earphones are securely connected to your device.
  • Some devices or applications may have limited support for all in-line control functions.

Specifications

Warranty and Support

Warranty Information

Edifier products typically come with a limited warranty. Please refer to the warranty card included with your product or visit the official Edifier website for detailed warranty terms and conditions specific to your region.

Customer Support

For further assistance, technical support, or inquiries, please visit the official Edifier support website or contact their customer service department. Contact details can usually be found on the Edifier website or in your product packaging.

Edifier Official Website: www.edifier.com
