BAKAJI 2000W Wall-Mounted Infrared Quartz Heater

1. Important Safety Instructions

Please read all instructions carefully before using the heater. Failure to follow these instructions may result in electric shock, fire, or serious injury.

• Electrical Safety: Ensure the power supply matches the voltage specified on the heater's rating label. Do not overload electrical circuits. Always unplug the heater before cleaning or maintenance.
• Placement: Mount the heater securely to a wall, ensuring adequate clearance from combustible materials (curtains, furniture, etc.). Do not cover the heater.
• Outdoor Use: This heater is rated IP34 for splash resistance, making it suitable for outdoor use in covered areas. However, do not expose it directly to heavy rain or immerse it in water.
• Children and Pets: Keep children and pets away from the heater, especially when it is operating, as surfaces can become very hot.
• Ventilation: Ensure proper ventilation around the heater. Do not use in confined spaces.
• Damaged Cord: Do not operate the heater with a damaged cord or plug. Contact qualified personnel for repair.

2. Product Overview

The BAKAJI 2000W Wall-Mounted Infrared Quartz Heater provides efficient and rapid heating for both indoor and outdoor environments. Its robust steel construction and IP34 splash resistance ensure durability and suitability for various settings.

• High-Efficiency Quartz Tubes: Equipped with three high-efficiency quartz heating elements for quick and uniform heat distribution.
• Adjustable Power: Offers three power levels (650W, 1350W, 2000W) to suit different heating needs and optimize energy consumption.
• Wall-Mounted Design: Space-saving design for secure wall installation, ideal for terraces, balconies, verandas, and other outdoor areas.
• Splash Resistant (IP34): Protected against splashing water, ensuring reliable operation even in humid conditions or light rain.
• Pull-Cord Control: Easy operation via a convenient pull-cord switch.
• Durable Construction: Made with a compact steel structure and an aluminum outer frame for enhanced longevity.

Figure 2.1: Overview of the BAKAJI Wall-Mounted Infrared Quartz Heater.

Figure 2.2: Heater highlighting weather resistance, aluminum outer frame, and safety grill.

3. Package Contents

Verify that all components are present and undamaged upon opening the package. If any items are missing or damaged, contact customer support.

• 1x BAKAJI 2000W Wall-Mounted Infrared Quartz Heater
• 1x Mounting Hardware Kit (screws, wall anchors)
• 1x User Manual

4. Setup and Installation

This heater is designed for wall-mounted installation. Choose a suitable location that provides adequate clearance from flammable materials and allows for proper heat distribution.

1. Select Location: Choose a sturdy wall surface, preferably under a covered area if installing outdoors. Ensure there is at least 1 meter (3.3 feet) clearance from ceilings, walls, and any combustible materials.
2. Mark Drilling Points: Hold the heater against the wall at the desired mounting height. Mark the positions for the mounting holes using a pencil.
3. Drill Holes: Drill holes at the marked positions. Insert the provided wall anchors into the drilled holes.
4. Mount Heater: Align the heater's mounting brackets with the anchors and secure it to the wall using the provided screws. Ensure the heater is firmly attached and level.
5. Connect Power: Plug the 1.5-meter power cable into a suitable electrical outlet. Ensure the outlet is protected and rated for the heater's power consumption (2000W).

Note: For outdoor installations, ensure the electrical outlet is weather-resistant and protected from direct water exposure, even though the heater itself is splash-resistant (IP34).

5. Operating Instructions

The heater is controlled by a pull-cord switch located at the bottom of the unit. Each pull cycles through the power settings.

1. Turn On: Ensure the heater is securely mounted and plugged into a power outlet. Pull the cord once to turn the heater ON at the lowest power setting (650W).
2. Adjust Power:
   • Pull the cord a second time for medium power (1350W).
   • Pull the cord a third time for maximum power (2000W).
3. Turn Off: Pull the cord a fourth time to turn the heater OFF.

The quartz heating elements will glow orange when active, indicating heat output.

Figure 5.1: Heater illustrating the three adjustable power levels.

6. Maintenance

Regular cleaning and maintenance will ensure the longevity and efficient operation of your heater.

• Cleaning: Always unplug the heater and allow it to cool completely before cleaning. Use a soft, damp cloth to wipe the exterior surfaces. Do not use abrasive cleaners or solvents.
• Dust Removal: Periodically remove dust from the heating elements and grill using a soft brush or vacuum cleaner with a brush attachment.
• Storage: If storing the heater for an extended period, ensure it is clean and dry. Store it in a cool, dry place, preferably in its original packaging.
• Inspection: Regularly inspect the power cord and plug for any signs of damage. If damage is found, do not use the heater and contact qualified service personnel.

7. Troubleshooting

If you encounter issues with your heater, refer to the following common problems and solutions:

If the problem persists after attempting these solutions, please contact customer support.

8. Specifications

Technical details for the BAKAJI 2000W Wall-Mounted Infrared Quartz Heater:

Figure 8.1: Heater dimensions diagram.

9. Warranty and Support

This product comes with a standard manufacturer's warranty. For specific warranty details, please refer to the documentation included with your purchase or visit the BAKAJI official website.

For technical support, troubleshooting assistance, or to inquire about replacement parts, please contact BAKAJI customer service. Contact information can typically be found on the product packaging or the brand's official online presence.

When contacting support, please have your product model number (2000W Wall-Mounted Infrared Quartz Heater) and ASIN (B0G6FZSZ1C) available.
