Tomofree L7 Electric Scooter User Manual

1. Introduction

Thank you for choosing the Tomofree L7 Electric Scooter. This manual provides essential information for the safe operation, assembly, maintenance, and troubleshooting of your new scooter. Please read it thoroughly before your first ride to ensure optimal performance and safety.

The Tomofree L7 is designed for adults seeking a powerful and versatile electric scooter for both urban commuting and off-road adventures. It features a dual motor system, long-range battery, and robust suspension for a comfortable and exhilarating riding experience.

2. Safety Guidelines

Your safety is paramount. Always adhere to the following guidelines:

• Wear Protective Gear: Always wear a helmet, knee pads, elbow pads, and appropriate footwear when riding.
• Local Regulations: Familiarize yourself with and obey all local laws and regulations regarding electric scooter use.
• Pre-Ride Check: Before each ride, inspect the brakes, tires, lights, and all fasteners to ensure they are in good working order.
• Riding Conditions: Avoid riding in heavy rain, snow, ice, or extremely wet conditions. The scooter has an IPX4 waterproof rating, but it is not fully submersible.
• Weight Limit: Do not exceed the maximum load capacity of 330 lbs (150 kg).
• Age Restriction: This scooter is intended for adult riders.
• Awareness: Be aware of your surroundings, pedestrians, and other vehicles. Ride defensively.
• Speed Control: Adjust your speed according to terrain, visibility, and traffic conditions.
• Braking: Use both hydraulic disc brakes for effective stopping. Practice emergency braking in a safe, open area.
• Alcohol/Drugs: Never operate the scooter under the influence of alcohol or drugs.

3. Package Contents

Upon opening your Tomofree L7 Electric Scooter package, please verify that all the following items are included:

• Main Scooter Body
• Adjustable Seat (if Seat Version purchased)
• Charger
• Toolkit (including tools and spare screws for side wings and panels)
• Two Side Wings
• One Tail Wing
• User Manual (this document)

4. Components Overview

Familiarize yourself with the key components of your Tomofree L7 Electric Scooter:

Figure 4.1: Advanced Control System. This image displays the handlebar controls, including the display screen, NFC swipe card unlock, front and rear brake levers, turn signal switch, horn button, motor mode/start button, light control, and twist throttle.

• Dual 3000W Motors (6000W Peak): Provides powerful acceleration and hill-climbing capability.
• 60V 35Ah Lithium Battery: Offers an extended range of up to 55 miles. Features BMS protection and IPX4 waterproof rating.
• 11-inch Tubeless Fat Tires: Designed for all-terrain grip and comfort on various surfaces.
• Quad Shock Absorption System: Features aluminum front forks and high-carbon steel rear shocks for a smooth ride.
• Dual Hydraulic Disc Brakes: Ensures reliable and responsive stopping power.
• 360° LED Lighting System: Includes four front headlights, three clear arrow turn signals, a responsive brake/tail light, and an illuminated brand logo for enhanced visibility.
• LED Display: Provides real-time information such as speed, battery level, and riding mode.
• Twist Throttle: For intuitive speed control.
• Foldable Design: Allows for easy storage and portability.
• Optional Saddle Seat: Provides a comfortable riding position for longer journeys (if included with your version).

5. Setup and Initial Assembly

Your Tomofree L7 Electric Scooter arrives 90% pre-assembled. Follow these steps for final assembly:

1. Unpack: Carefully remove all components from the packaging.
2. Unfold the Scooter: Release the folding mechanism and raise the stem until it locks into place. Ensure the locking mechanism is securely engaged.
3. Attach Handlebars: Secure the handlebars to the stem. Ensure all cables are properly routed and not pinched. Tighten all bolts firmly using the provided toolkit.
4. Install Side and Tail Wings: Attach the side wings and tail wing using the provided screws and tools.
5. Install Seat (if applicable): If your model includes a seat, attach it according to the instructions in the separate seat assembly guide or the main video guide.
6. Initial Charge: Before the first ride, fully charge the battery. Refer to the 'Charging' section for detailed instructions.
7. Pre-Ride Inspection: Perform a thorough pre-ride inspection as outlined in the 'Safety Guidelines' section.

6. Operating Instructions

6.1 Powering On/Off

• To Power On: Swipe your NFC card over the display or press and hold the Power/Light button.
• To Power Off: Press and hold the Power/Light button until the display turns off.

6.2 Riding Modes and Speed Control

The L7 features multiple speed modes. Use the Drive Mode button to cycle through them. The twist throttle controls acceleration.

Figure 6.1: Dual Motor Performance. This image shows the Tomofree L7 in action on off-road terrain, illustrating its powerful dual motor capability (6000W peak output) and ability to handle inclines up to 35 degrees.

• Speed Modes: The scooter offers 3 speed modes. Select the appropriate mode based on your riding environment and experience level.
• Twist Throttle: Gently twist the throttle to accelerate. Release to decelerate.
• Braking: Use the front and rear hydraulic disc brakes for controlled stopping. Apply both brakes simultaneously for optimal braking performance.

6.3 Lighting and Signals

Figure 6.2: 360° Visibility. This image highlights the scooter's comprehensive lighting system, including quad headlights, brake light, and turn signals, ensuring visibility in various conditions.

• Headlights: Press the Power/Light button to turn the headlights on or off.
• Turn Signals: Use the turn signal switch on the handlebar to indicate turns.
• Brake Light: The rear brake light illuminates automatically when brakes are applied.

6.4 Folding and Transport

Figure 6.3: Easy Folding. This image demonstrates the scooter's foldable design, making it convenient for transport and storage, such as in a car trunk.

The L7 features a quick-folding mechanism for easy storage and transport. Ensure the scooter is powered off before folding. Secure the folding latch firmly before lifting or transporting.

7. Charging Instructions

Proper charging extends battery life and ensures safe operation.

Figure 7.1: Battery and Range. This image emphasizes the scooter's 60V 35Ah lithium battery, providing up to 55 miles of range and a charging time of 6-7 hours with the 5A fast charger.

1. Connect Charger: Plug the charger into the scooter's charging port.
2. Connect to Power: Plug the charger into a standard electrical outlet.
3. Charging Indicator: The charger will typically have an indicator light (e.g., red for charging, green for fully charged).
4. Charging Time: A full charge takes approximately 6-7 hours with the 5A fast charger.
5. Disconnect: Once fully charged, disconnect the charger from the outlet first, then from the scooter.

Important: Only use the charger provided by Tomofree. Do not overcharge the battery. Store the scooter in a cool, dry place when not in use, and avoid extreme temperatures.

8. Maintenance

Regular maintenance ensures the longevity and safe operation of your scooter.

8.1 Tires

Figure 8.1: 11-inch Off-Road Tires. This image provides a detailed view of the robust 11-inch tubeless fat tires, designed for superior grip and performance across various terrains, including off-road and city roads.

• Tire Pressure: Check tire pressure regularly. Maintain the recommended PSI (refer to the tire sidewall or specifications section).
• Tire Wear: Inspect tires for signs of wear, punctures, or damage. Replace worn tires promptly.

8.2 Brakes

• Brake Pads: Check brake pads for wear. Replace them when they are thin.
• Brake Levers: Ensure brake levers operate smoothly and provide firm stopping power. Adjust cable tension if necessary.
• Hydraulic Fluid: For hydraulic brakes, check fluid levels periodically and have them serviced by a qualified technician if needed.

8.3 General Cleaning and Storage

• Cleaning: Wipe down the scooter with a damp cloth. Do not use high-pressure water jets or immerse the scooter in water.
• Storage: Store the scooter in a dry, cool place away from direct sunlight and extreme temperatures. If storing for an extended period, charge the battery to about 50-70% and recharge every 1-2 months.

8.4 Suspension

Figure 8.2: Full Suspension System. This image illustrates the scooter's quad shock absorption system, featuring both front and rear shock absorbers, which contribute to a smooth ride over varied terrain.

• Inspection: Periodically check the front and rear suspension components for any signs of damage or leaks.
• Cleaning: Keep suspension components clean from dirt and debris to ensure smooth operation.

9. Troubleshooting

This section addresses common issues you might encounter with your Tomofree L7 Electric Scooter.

If you encounter an issue not listed here or if the suggested solutions do not resolve the problem, please contact Tomofree customer support.

10. Specifications

Key technical specifications for the Tomofree L7 Electric Scooter:

11. Warranty and Support

Tomofree is committed to providing high-quality products and excellent customer service.

11.1 Warranty Information

The Tomofree L7 Electric Scooter comes with a 1-year limited warranty. This warranty covers manufacturing defects and workmanship under normal use. Please retain your proof of purchase for warranty claims. The warranty does not cover damage due to misuse, accidents, unauthorized modifications, or normal wear and tear.

11.2 Customer Support

For any questions, technical assistance, or warranty claims, please contact our dedicated support team:

• 24/7 Customer Support: Available around the clock for your convenience.
• 1-on-1 Tech Callback: Personalized technical assistance.
• Authorized Repair Centers: Service support across dozens of U.S. authorized repair centers.
• Lifetime Technical Support: Ongoing support for the lifespan of your product.
• Phone: +1-518-614-6355
• Email: Service@tomofree.com

Figure 11.1: After-Sales Service. This image displays the contact information and support options available for Tomofree customers, including 24/7 customer support and technical assistance.
