SAN HIMA CapeTop Rooftop Tent Instruction Manual

1. Introduction

Thank you for choosing the SAN HIMA CapeTop Rooftop Tent. This manual provides essential information for the safe and efficient setup, operation, and maintenance of your new rooftop tent. Designed for 2-3 people, the CapeTop offers a spacious interior (84.65 x 51.18 x 40.94 inches) while remaining lightweight at 131.5 lbs, thanks to its Snap Fold System and aluminum construction. It features durable 600D Oxford fabric with a full blackout lining (2,000mm waterproof) and a 150D Oxford fabric canopy with silver lining (3,000mm waterproof, UPF 50+), ensuring comfort across four seasons. Enjoy modern conveniences like a digital panel with USB-C, USB-A, and CIG sockets, an adjustable amber LED strip light, and an integrated AC duct hole. Please read this manual thoroughly before use.

Figure 1: The SAN HIMA CapeTop Rooftop Tent in its deployed state.

2. Package Contents

Verify that all items listed below are included in your package:

• 1 x San Hima CapeTop Rooftop Tent
• 1 x Mattress
• 1 x Anti-condensation Mat
• 1 x Telescopic Ladder
• 1 x LED Strip Light

Figure 2: Included components of the CapeTop Rooftop Tent package.

3. Safety Information

• Ensure the rooftop tent is securely mounted to your vehicle's roof rack system before driving.
• Adhere to your vehicle's roof load capacity and the tent's weight limits.
• Always use the telescopic ladder on stable, level ground. Ensure all ladder rungs are fully extended and locked before climbing.
• Do not exceed the maximum occupancy of 3 people.
• Avoid using open flames or heating appliances inside the tent.
• In strong winds, consider lowering the tent or securing it with additional guy ropes.
• Regularly inspect all components for wear and tear, especially before and after trips.

4. Setup and Installation

4.1 Mounting the Tent to Your Vehicle

The CapeTop rooftop tent is designed for secure mounting on most vehicle roof rack systems. The mounting process involves attaching the tent's base rails to your vehicle's crossbars using the provided hardware. Ensure the tent is centered and evenly distributed on your roof rack for optimal stability.

4.2 Deploying the Tent

Once securely mounted, deploying the CapeTop tent is a quick process:

1. Unlatch the buckles securing the tent's hard shell.
2. Gently push the top shell upwards. Gas struts will assist in opening the tent fully.
3. Extend the telescopic ladder to the desired length, ensuring it is firmly planted on level ground and locked into position. The ladder also supports the extended floor section.
4. Insert the support bars for the window awnings and the main entrance awning.
5. Attach the shoe pockets to the designated slots near the ladder.

Figure 3: Quick setup process of the CapeTop Rooftop Tent.

5. Operating the Tent

5.1 Interior Features

The CapeTop tent offers a comfortable and functional interior:

• Mattress: Enjoy a 2.17-inch high-density foam mattress for a comfortable night's sleep.
• Digital Panel: Located inside, the digital panel provides USB-C, USB-A, and CIG sockets for charging devices.
• LED Strip Light: An adjustable amber LED strip light allows you to set the perfect ambiance.
• AC Duct Hole: A built-in duct hole allows for easy connection of an AC hose for climate control.
• Storage: Ceiling organizers and exterior shoe pockets help keep your essentials tidy.

Figure 4: Comfortable 2.17-inch high-density foam mattress.

Figure 5: Digital control panel for charging devices.

Figure 6: AC duct hole for climate control.

5.2 Ventilation and Light Control

The tent features multiple openings for ventilation and light control:

• Dual side windows, a rear window, and a front door are equipped with fine meshes to keep insects out while allowing airflow.
• The main body fabric includes a blackout lining to ensure a dark interior for sleeping.
• The full-coverage canopy with silver lining provides UPF 50+ protection and helps block morning sun.

Figure 7: Interior with windows open for maximized airflow.

Figure 8: Light shielding technology ensures a dark interior.

6. Maintenance and Care

• Cleaning: Hand wash the fabric components with mild soap and water. Do not use harsh chemicals or abrasive cleaners.
• Drying: Ensure the tent is completely dry before packing it away to prevent mold and mildew.
• Storage: Store the tent in a cool, dry place when not in use.
• Inspection: Periodically check all zippers, seams, and hardware for any signs of damage or wear.

7. Troubleshooting

• Condensation: Use the anti-condensation mat provided. Ensure adequate ventilation by opening windows (with mesh) when possible.
• Sticking Zippers: Clean zippers with a soft brush and apply a silicone-based lubricant if necessary.
• Tent Not Opening/Closing Smoothly: Check for any fabric caught in the hinges or gas struts. Ensure the tent is on level ground.

8. Specifications

9. Warranty and Support

The SAN HIMA CapeTop Rooftop Tent comes with a 1 Year Warranty. For any support inquiries, troubleshooting assistance, or warranty claims, please refer to the contact information provided with your purchase or visit the official SAN HIMA website.
