1. Introduction
Thank you for purchasing the LAMA 8K Video Camera. This manual provides detailed instructions for the proper use, setup, and maintenance of your new device. Please read this manual thoroughly before use to ensure optimal performance and to prevent damage.
2. Safety Information
- Do not expose the camera to water or moisture.
- Avoid dropping the camera or subjecting it to strong impacts.
- Keep the camera away from extreme temperatures.
- Do not attempt to disassemble or repair the camera yourself. Contact customer support for assistance.
- Use only the specified battery and accessories.
3. Package Contents
Verify that all items are present in your package:
- 8K Video Camera Body
- 2.4G Remote Control (x1)
- 4500mAh Battery (x1)
- 64GB SD Card (x1)
- USB Cable (x1)
- External Microphone (x1)
- Lens Cap (x1)
- Cleaning Cloth (x1)
- Storage Bag (x1)
- Japanese Instruction Manual (x1)
Figure 3.1: Included accessories with the LAMA 8K Video Camera.
4. Product Overview
The LAMA 8K Video Camera features a 3.0-inch touch screen, an external microphone input, HDMI output, and a USB-C port for versatile connectivity. Its compact design makes it suitable for various recording scenarios.
Figure 4.1: Front view of the LAMA 8K Video Camera.
5. Setup
5.1 Battery Installation and Charging
- Open the battery compartment cover.
- Insert the 4500mAh rechargeable lithium-ion battery, ensuring correct polarity.
- Close the battery compartment cover.
- Connect the camera to a power source using the provided USB-C cable for charging. The camera can be used while charging.
5.2 SD Card Installation
- Locate the SD card slot.
- Insert the included 64GB SD card (or a compatible card up to 256GB) into the slot until it clicks into place. Ensure the card is inserted in the correct orientation.
- To remove, gently press the SD card to release it.
5.3 External Microphone Connection
Connect the external microphone to the designated microphone input port on the camera for enhanced audio recording. This helps effectively suppress noise, making it suitable for meetings, interviews, and lectures.
6. Operating Instructions
6.1 Power On/Off
Press and hold the power button to turn the camera on or off.
6.2 Basic Recording
Once powered on, the camera is ready to record 8K video or capture 64MP photos. Use the 3.0-inch touch screen for intuitive operation.
6.3 270-Degree Rotatable Screen
The screen can be rotated 270 degrees, allowing for easy self-recording and vlogging.
Figure 6.1: 270-degree rotatable screen for self-recording.
6.4 Remote Control Operation
The included 2.4G remote control supports 360-degree remote operation, allowing you to take photos, record videos, and control playback from up to 10 meters away. This is useful for self-portraits or group shots.
Figure 6.2: Using the 2.4G remote control.
6.5 WiFi Functionality
Utilize the WiFi function to connect the camera to your smartphone or tablet. This allows for video transfer, remote control of the camera, and real-time image preview. The operation is straightforward.
6.6 Webcam Function
Connect the camera to your computer via the Type-C cable to use it as a webcam. This feature is ideal for live streaming on platforms like Facebook, YouTube, and Instagram, or for video calls with family and friends.
Figure 6.3: Camera functioning as a webcam.
6.7 HDMI Output
Connect the camera to a TV or projector using an HDMI cable (Type-C cable included supports data transfer and HDMI output) to enjoy your 8K videos and photos on a larger screen. Set the TV's input to HDMI to display the camera's output.
Figure 6.4: HDMI output connection to a TV.
7. Advanced Features
7.1 Loop Recording
When loop recording is enabled, the camera will automatically overwrite the oldest footage when the SD card becomes full, ensuring continuous recording without manual intervention.
7.2 Time-Lapse and Slow Motion
The camera supports time-lapse and slow-motion recording modes, allowing for creative video capture.
7.3 Pause Function
During video recording, press the record button once to pause and again to resume. This allows you to capture only the necessary shots.
Figure 7.1: Using the pause function during recording.
7.4 Automatic and Continuous Shooting
The camera offers automatic photo shooting and continuous shooting modes to capture sequences of images.
Figure 7.2: Continuous shooting mode in action.
7.5 Timed Photo Shooting
Set a timer for 3, 5, 10, or 20 seconds before a photo is taken, allowing you to get into position for group photos or self-portraits.
7.6 Infrared Night Vision LED
The camera is equipped with an infrared night vision LED, enhancing visibility in dark or low-light environments.
Figure 7.3: Infrared night vision capability.
8. Maintenance
- Cleaning the Lens and Screen: Use the provided cleaning cloth or a soft, lint-free cloth to gently wipe the lens and screen. Avoid abrasive materials or harsh chemicals.
- Storage: Store the camera in a cool, dry place, away from direct sunlight and extreme temperatures. When not in use for extended periods, remove the battery.
- Battery Care: Fully charge the battery before first use. Avoid completely draining the battery frequently to prolong its lifespan.
9. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Camera does not power on. | Battery is low or not inserted correctly. | Charge the battery or re-insert it correctly. |
| Cannot record video/take photos. | SD card is full, not inserted, or corrupted. | Insert a formatted SD card, free up space, or try a different card. |
| Poor audio quality. | External microphone not connected properly or settings incorrect. | Ensure external microphone is securely connected. Check audio settings. |
| Difficulty inserting/removing microSD card. | Card slot mechanism is tight. | Apply gentle, firm pressure. Avoid forcing the card to prevent damage. |
10. Specifications
| Feature | Detail |
|---|---|
| Brand | LAMA |
| Photo Sensor Technology | CMOS |
| Video Capture Resolution | 8K (Display Max), 5K (Capture) |
| Max Focal Length | 10 mm |
| Max Aperture | 1 mm |
| Video Capture Format | MP4 |
| Supported Audio Formats | AAC, MP3 |
| Color | Black |
| Special Features | Face Detection |
| Image Sensor Size | 1/3-inch |
| Image Stabilization | No |
| Form Factor | Handheld |
| Number of Batteries | 1 (included) |
| Lens Type | Zoom |
| Focus Function | Manual Focus |
| Display Max Resolution | 8K |
| Supported Image Format | JPEG |
| Aspect Ratio | 16:9 |
| Shooting Functions | Time-lapse, Slow motion, Auto photo, Continuous photo, Loop recording |
| Battery Capacity | 4500mAh |
| Charging Time | Approx. 2.5 hours |
| Usage Time | Approx. 4.5 hours (full charge) |
| Weight | 420g |
| Max SD Card Support | 256GB |
| USB Port | USB2.0 |
| MIC Input | Supported |
| White Balance | Auto/Sunny/Cloudy/Tungsten/Fluorescent |
Figure 10.1: Detailed product specifications.
11. Warranty and Support
The LAMA 8K Video Camera comes with a 1-year warranty. For any inquiries or assistance, our customer service center is available 24 hours. Please feel free to contact us via email.
