REDCAMP Foldable Stroller Wagon (Model 18035) Instruction Manual

Introduction

This manual provides essential instructions for the safe and effective use of your REDCAMP Foldable Stroller Wagon, Model 18035. Please read this guide thoroughly before assembly and operation to ensure proper functionality and safety for your children.

Safety Information

• Always secure children with the built-in five-point harness.
• Ensure the wagon is on a stable, level surface before placing or removing children.
• The maximum weight capacity is 110 lbs (55 lbs per seat) for children and 220 lbs for the overall wagon frame. Do not exceed these limits.
• Always engage the foot brake when the wagon is stationary.
• The UPF 50+ canopy provides sun protection; however, do not leave children unattended in direct sunlight for extended periods.
• Keep hands and fingers clear of moving parts during folding and unfolding.
• Regularly inspect all parts for wear, damage, or loose fasteners. Do not use if damaged.
• This wagon is designed for children. Do not use it for purposes other than its intended use.

Image: Detail of the 5-point harness system, crucial for child safety.

Image: Illustration of the one-step foot brake system for secure stops.

Package Contents

Verify that all components are present before assembly:

• REDCAMP Foldable Stroller Wagon Frame
• Removable Canopy
• Adjustable Push Handle
• Retractable Pull Handle
• 2 Cup Holders
• 1 Zippered Pocket
• Storage Bag for Canopy (if applicable)
• Instruction Manual (this document)

Setup

The REDCAMP Stroller Wagon is designed for easy, tool-free setup.

1. Unfolding the Wagon: Place the folded wagon on a flat surface. Release any securing latches. Gently pull the sides of the wagon apart until the frame fully extends and locks into place. Ensure the bottom straps are connected for stability.
2. Attaching the Canopy: Insert the canopy support rods into the designated slots on the wagon frame. Secure the canopy fabric over the rods. The canopy is designed to retract easily with a button press.
3. Adjusting Handles: The push handle can be adjusted to various angles for comfortable pushing. The pull handle is multi-angle and retractable. Adjust both to your preferred height and position.
4. Harness Check: Ensure the five-point harnesses for both seats are accessible and untangled.

Image: Visual guide for folding and unfolding the wagon for storage.

Image: The removable canopy providing sun protection.

Operating Instructions

1. Push and Pull Modes:
   • Push Mode (Stroller): Use the adjustable front handle to push the wagon like a traditional stroller.
   • Pull Mode (Wagon): Extend the retractable rear pull handle to pull the wagon.


   Image: Demonstrating the push (stroller) and pull (wagon) operating modes.
2. Securing Children: Place children in the seats and fasten the 5-point harnesses securely. Adjust straps for a snug fit.
3. Side Entry Function: Unzip the side panel to create a bench-style entry. This allows children to enter and exit independently. Ensure the secure lock is engaged when the side panel is closed.
4. Braking: To stop the wagon, press down firmly on the foot brake located on the rear wheels until it locks. To release, lift the foot brake.
5. Maneuvering: The front wheels swivel 360° for easy steering. The upgraded PVC wheels with a shock-absorbing system provide a smooth ride on various terrains.
6. Storage: Utilize the two cup holders and one zippered pocket for drinks and small essentials.

Image: The side entry feature allowing children to access the wagon independently.

Image: Overview of the wagon's interior, showing integrated storage options.

Maintenance

• Cleaning: The 600D Oxford fabric can be spot cleaned with mild soap and water. Allow to air dry completely. Do not machine wash or tumble dry.
• Frame: Wipe the alloy steel frame with a damp cloth. Avoid abrasive cleaners.
• Wheels: Periodically check wheels for debris and ensure they rotate freely. Clean any accumulated dirt.
• Storage: When not in use, fold the wagon and store it in a dry, cool place away from direct sunlight to prolong its lifespan.

Troubleshooting

Wagon does not fold/unfold smoothly:

Ensure all locking mechanisms are disengaged before folding. Check for any obstructions or trapped fabric. Apply light lubricant to moving joints if necessary.

Wheels are stiff or noisy:

Inspect wheels for debris (e.g., sand, small stones) and remove them. Ensure wheel axles are clean. If noise persists, a small amount of silicone-based lubricant can be applied to the axle points.

Harness is difficult to buckle/unbuckle:

Check for any fabric obstruction or dirt in the buckle mechanism. Ensure all five points are aligned correctly before attempting to buckle.

Specifications

Image: Detailed dimensions of the wagon, including its folded size.

Warranty & Support

REDCAMP products are manufactured to high-quality standards. For warranty information, product support, or to purchase replacement parts, please contact REDCAMP customer service.

Contact Information:

• Visit the official REDCAMP website for support resources.
• Refer to your purchase documentation for specific warranty terms.
