1. Introduction
This manual provides detailed instructions for the safe installation, operation, and maintenance of your Garwarm 26.4-inch Black Flush Mount Ceiling Fan with Lights, Model TT-JD2003-6B. Please read this manual thoroughly before installation and use, and retain it for future reference.
2. Important Safety Information
- Always disconnect power at the circuit breaker before installation or servicing.
- Installation must be performed by a qualified electrician in accordance with all local and national electrical codes.
- Ensure the mounting structure can support the weight of the fan fixture.
- Do not bend fan blades during installation or cleaning.
- Keep hands clear of the fan blades when the fan is operating.
- Use only E26 base bulbs, maximum 60W (bulbs not included).
- Glass components are fragile. Handle with care to prevent breakage and injury.
3. Package Contents
Verify that all components are present before beginning installation:
- Ceiling Fan Unit (with integrated motor and light sockets)
- Fan Blades (3 included)
- Light Kit (integrated)
- Remote Control
- Mounting Bracket
- Hardware Pack (screws, wire caps, wrench)
- Glass Lampshades (6 included)
4. Product Specifications
| Feature | Specification |
|---|---|
| Brand | Garwarm |
| Model Number | TT-JD2003-6B |
| Color | Black Glass |
| Material | Glass, Iron, Polycarbonate |
| Style | Farmhouse/Rustic/Industrial |
| Light Fixture Form | Ceiling Fan Light |
| Product Dimensions | 26.37"L x 26.37"W x 10.23"H (67cm x 67cm x 26cm) |
| Power Source | DC |
| Installation Type | Flush Mount |
| Control Method | Remote Control |
| Light Source Type | E26 (Bulbs not included, Max 60W) |
| Number of Light Sources | 6 |
| Wattage | 30 watts (fan motor) |
| Number of Blades | 3 |
| Air Flow Capacity | 8.2 Cubic Meters Per Minute |
| Special Features | Timer (1/2/4/8H), Reversible Motor, 6 Wind Speeds |
| Item Weight | 12.1 pounds |
5. Setup and Installation
Follow these steps for proper installation. For a visual guide, refer to the installation video provided below.
- Unpack and Inspect: Carefully open the carton and inspect all components against the package contents list.
- Assemble Motor and Base: Fix the motor head to the base. Ensure the gear washer is placed correctly and tighten firmly using the provided wrench.
- Attach Fan Blades: Use the special screws to fix the three fan blades to the motor. Ensure the blades are flat and securely tightened. English letters on the blades indicate the direction of the blade surface.
- Connect Internal Wiring: Correctly connect the motor wires and light source wires to the controller ports.
- Mounting Bracket Installation: Fix the mounting bracket to the ceiling with screws. Ensure it is securely fastened to a suitable support structure.
- Electrical Connection: IMPORTANT: Ensure power supply is cut off at the circuit breaker. Strictly and accurately connect the live wire (L) and neutral wire (N) of the lamp to the live wire (L) and neutral wire (N) of the power supply. Tighten with wire caps and check for secure connections.
- Attach Fan Unit to Mounting Bracket: Carefully lift the assembled fan unit and attach it to the ceiling mounting bracket, securing it with screws.
- Install Blade Decorative Cover: Turn the blade decorative cover clockwise and tighten it.
- Install Glass Lampshades: Use the specially provided wrench to unscrew the outer teeth of the lamp head. Carefully place the glass lampshade over the bulb socket. Caution: Glass is fragile. Do not stand directly below the glass during installation.
- Install Light Bulbs: Screw in the E26 light sources (bulbs not included) into the sockets.
- Remote Control Holder: Install the remote control holder to a convenient wall location using screws.
Installation Video Guide
This video demonstrates the step-by-step installation process for the Garwarm ceiling fan with lights, including unpacking, assembly of motor and blades, wiring connections, and final mounting. (Source: Garwarm Home Decor Store)
Product Dimensions
Image showing the product dimensions: 26.37 inches (67cm) diameter and 10.23 inches (26cm) height. Also indicates compatibility with E26 bulbs (Max 60W, not included).
6. Operating Instructions
Your Garwarm ceiling fan with lights is controlled by the included remote. Ensure the remote has working batteries.
Remote Control Functions
The remote control allows you to manage all fan and light functions. Buttons include: Turn on/off, Light on/off, 6 Speed settings, Natural wind mode, Timer settings (1/2/4/8 hours), Forward/Reverse rotation, and Stop/Code alignment.
- Power On/Off: Press the power button to turn the fan and lights on or off.
- Light Control: Press the light button to turn the lights on or off independently of the fan.
- Fan Speed: Select from 6 wind speed levels (1-6) to adjust airflow.
- Natural Wind Mode: Activates a fluctuating fan speed to simulate natural breezes.
- Timer Function: Set the fan to automatically turn off after 1, 2, 4, or 8 hours.
- Reversible Motor: Use the forward/reverse button to change the direction of the fan blades. This allows for downward airflow in summer for cooling and upward airflow in winter to circulate warm air.
Fan Speed Settings
The fan offers 6 speed settings: 1-2 for a gentle 'Sleep Wind', 3-4 for a 'Natural Wind', and 5-6 for a 'Strong Wind' to suit various comfort levels.
Reversible Motor Function
The reversible DC motor allows you to change the fan's direction for seasonal comfort. Downward airflow provides a cool breeze in summer, while upward airflow helps circulate warm air in winter.
Quiet Operation and Timer
The fan operates at a low noise level of 35dB, ensuring a quiet environment. The integrated timer allows for automatic shut-off after 1, 2, 4, or 8 hours.
7. Maintenance
- Cleaning: To clean the fan, wipe with a soft, damp cloth. Do not use abrasive cleaners or solvents. Ensure power is off before cleaning.
- Bulb Replacement: Ensure power is off before replacing bulbs. Allow bulbs to cool completely before handling.
- Tightness Check: Periodically check all screws and connections for tightness.
8. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Fan does not operate | No power supply; Loose wiring; Remote control battery low. | Check circuit breaker; Verify all wire connections are secure; Replace remote control batteries. |
| Lights do not turn on | Bulbs are faulty or not installed correctly; Loose wiring; No power supply. | Check and replace bulbs; Verify light kit wiring; Check circuit breaker. |
| Fan makes excessive noise | Loose screws on fan blades or mounting bracket; Fan not balanced. | Tighten all screws; Ensure fan blades are securely attached and balanced. |
| Remote control not working | Batteries are dead or incorrectly inserted; Remote not paired with fan. | Replace batteries, ensuring correct polarity; Refer to remote pairing instructions (usually involves pressing a 'code alignment' button). |
9. Warranty and Support
For warranty information or technical support, please contact Garwarm customer service through the retailer where the product was purchased. Keep your purchase receipt as proof of purchase.
Manufacturer: Garwarm
