QIBOX Portable Bottle Warmer (Model XP-W17C) Instruction Manual

1. Introduction

Thank you for choosing the QIBOX Portable Bottle Warmer. This device is designed to provide a convenient and efficient way to warm breast milk, formula, or water for your baby, especially when traveling or on the go. Please read this manual carefully before use to ensure proper operation and safety.

2. Important Safety Information

• Always supervise the warmer during operation.
• Do not immerse the main unit in water or other liquids.
• Ensure the charging port is dry before connecting the charger.
• Keep out of reach of children.
• Always check the temperature of the milk/water before feeding your baby to prevent burns.
• Use only the provided charging cable and adapter.
• Do not use if the device is damaged.
• The inner chamber is made of SUS 316L food-grade stainless steel. Ensure all parts that come into contact with milk/water are clean.

3. Package Contents

Verify that all items are present in your package:

• QIBOX Portable Bottle Warmer Unit
• USB-C Charging Cable
• Wall Adapter (30W Fast Charger)
• Cleaning Brush
• User Manual

4. Product Overview

The QIBOX Portable Bottle Warmer features a sleek design with intuitive controls for easy operation.

Figure 1: Front view of the QIBOX Portable Bottle Warmer showing the digital display and control buttons.

Key Features:

• Digital Display: Shows current temperature and battery level.
• Control Buttons: Power on/off, temperature adjustment, and mode selection.
• SUS 316L Stainless Steel Inner Chamber: Food-grade material for safety and durability.
• Leak-Proof Lid: Designed with a silicone seal to prevent spills.
• USB-C Charging Port: For fast and convenient charging.

5. Setup

Before first use, please follow these steps:

1. Clean the Warmer: Separate the lid, silicone parts, and the inner heating chamber. Wash all parts that come into contact with milk/water using warm soapy water. Rinse thoroughly and allow to air dry completely.
2. Charge the Battery: Connect the warmer to the provided 30W fast charger using the USB-C cable. The battery icon on the screen will indicate charging status. A full charge takes approximately 2 hours.
3. Assemble: Once all parts are dry, reassemble the warmer, ensuring the silicone seal on the lid is properly seated to prevent leaks.

Figure 2: The USB-C charging port located at the base of the warmer.

6. Operating Instructions

6.1 Warming Milk or Formula

1. Fill the Warmer: Pour the desired amount of breast milk or formula into the inner chamber. The warmer has a 17oz capacity.
2. Power On: Press and hold the power button until the screen illuminates.
3. Select Temperature: Use the temperature adjustment buttons (+/-) to set the desired temperature (e.g., 98°F for breast milk). The warmer offers precise temperature control from 99°F to 212°F.
4. Start Warming: The warmer will automatically begin heating to the set temperature. The display will show the current temperature as it rises.
5. Ready for Feeding: Once the target temperature is reached, the warmer will maintain it for up to 24 hours. Always check the milk temperature before feeding.

Figure 3: The warmer in operation, indicating fast heating times for milk and water.

Note: Warming 4oz of refrigerated milk to 98°F takes approximately 3 minutes and 50 seconds. Warming 4oz of room-temperature water to 113°F takes approximately 3 minutes.

6.2 Heating Water

The warmer can also heat water for formula preparation or other uses.

1. Fill the warmer with the desired amount of water.
2. Power on the device.
3. Set the desired water temperature using the +/- buttons. For boiling water, set to 212°F.
4. The warmer will heat the water to the set temperature and maintain it.

Figure 4: Internal view highlighting the 16000mAh battery, providing extended use.

7. Charging

The QIBOX Portable Bottle Warmer is equipped with a 16000mAh battery for extended use and 30W fast charging capability.

• Connect the USB-C cable to the charging port at the bottom of the warmer and to the 30W wall adapter.
• A full charge takes less than 2 hours.
• One full charge can heat approximately 8 (4-oz) portions of refrigerated breast milk or 20 (4-oz) portions of water.

8. Maintenance and Cleaning

Regular cleaning ensures hygiene and extends the life of your warmer.

1. Daily Cleaning: After each use, empty any remaining liquid. Disassemble the lid and inner chamber. Wash with warm soapy water and rinse thoroughly. Use the provided cleaning brush to reach all corners.
2. Drying: Allow all parts to air dry completely before reassembling or storing to prevent mold growth.
3. Descaling: If mineral deposits build up in the heating chamber, descale using a solution of white vinegar and water. Fill the chamber with equal parts vinegar and water, let it sit for 30 minutes, then rinse thoroughly.
4. Exterior: Wipe the exterior of the warmer with a damp cloth. Do not use abrasive cleaners.

Figure 5: The included cleaning brush helps maintain hygiene of the warmer's interior.

9. Troubleshooting

10. Specifications

• Model: XP-W17C
• Power: 120W
• Battery Capacity: 16000mAh Lithium Ion (included)
• Charging: 30W Fast Charge (USB-C)
• Material: SUS 316L Stainless Steel (inner chamber), BPA-free materials
• Capacity: 17 ounces (approx. 500ml)
• Temperature Range: 99°F to 212°F (37°C to 100°C)
• Product Dimensions: 8.13 x 8.13 x 25.4 cm
• Item Weight: 1.04 kg

11. Official Product Videos

Watch these official videos for visual guidance on using your QIBOX Portable Bottle Warmer.

12. Warranty and Support

For warranty information and customer support, please refer to the contact details provided on the product packaging or visit the official QIBOX website. Keep your purchase receipt as proof of purchase.

Manufacturer: QIBOX

Place of Business: Zhongshan Xiangpai Electric Appliance Co., Ltd, No. 9, Area A, Yong'an Road, Dongxing Community, Dongfeng Town, Zhongshan City, Guangdong Province, +860755-28447653
