VANNECT X390AS 4-in-1 Foldable Walking Pad Treadmill User Manual

1. Important Safety Information

Please read this manual carefully before using the VANNECT Walking Pad Treadmill. Keep this manual for future reference.

• Always place the treadmill on a flat, stable surface.
• Ensure adequate clear space (at least 0.6 meters) around the treadmill during operation.
• Keep children and pets away from the treadmill during use.
• Do not exceed the maximum weight capacity of 150 kg.
• Wear appropriate athletic footwear and clothing.
• If you experience pain, dizziness, or shortness of breath, stop exercising immediately.
• Unplug the treadmill from the power outlet when not in use or before cleaning/maintenance.
• Do not use the treadmill if it is damaged or malfunctioning. Contact customer support.
• This appliance is intended for household use only.

2. Package Contents

The package includes the following items:

• 1 x VANNECT X390AS Walking Pad Treadmill
• 1 x Remote Control
• 1 x Power Cord
• 1 x User Manual (this document)
• Tools for belt adjustment (if necessary)

3. Product Overview

Key Features

• 4-in-1 Functionality: Offers a speed range of 1 to 10 km/h, suitable for working, walking, and running, with an adjustable 9% incline.
• Adjustable 9% Incline: Manually switch between flat and 9% incline modes to optimize calorie burning and muscle strengthening.
• Powerful & Silent Motor: Equipped with an upgraded 2.75 HP motor, operating at less than 40 dB, ensuring quiet workouts.
• Durable Construction: High-quality carbon steel frame supports up to 150 kg.
• Advanced Running Belt: Features a spacious 100 × 40 cm, 5-layer anti-slip belt for safety and durability.
• Shock Absorption System: 8 silicone shock absorbers and 2 pads reduce impact on knees and muscles.
• LED Display & Remote Control: Real-time tracking of time, speed, distance, and calories. Convenient remote for speed adjustment and pause function.
• Compact & Portable: Foldable design (116 × 50.5 × 12.5 cm) with integrated wheels for easy storage under furniture.
• No Assembly Required: Ready to use right out of the box.

Product Visuals

Figure 3.1: The VANNECT X390AS Walking Pad Treadmill, showcasing its sleek design and compact form factor.

Figure 3.2: Detail of the 5-layer anti-slip running belt and the 10 integrated shock absorbers, designed to reduce knee and ankle pressure.

Figure 3.3: The LED display showing real-time data and the wireless remote control for convenient speed adjustments.

Figure 3.4: Visual guide to the treadmill's versatile usage modes, including incline, working (1-3 km/h), walking (4-6 km/h), and running (7-10 km/h).

Figure 3.5: Demonstrates the treadmill's portability and easy storage under furniture, highlighting its integrated transport wheels.

Figure 3.6: A user integrating the walking pad into a home office setup with a standing desk, promoting an active workday.

Figure 3.7: Internal view of the treadmill's reinforced steel structure and powerful 2.75 HP motor, emphasizing its 150 kg capacity.

Figure 3.8: Illustration of the simple, no-assembly setup process, ready in 10 seconds.

Figure 3.9: Detailed view of the running surface dimensions (116 cm x 50 cm) and its 150 kg weight capacity.

Product Demonstration Video

4. Setup

The VANNECT X390AS Walking Pad Treadmill comes 100% pre-assembled, requiring no complex setup.

1. Unpack: Carefully remove the treadmill from its packaging.
2. Placement: Place the treadmill on a firm, level surface. Ensure there is sufficient space around the unit for safe operation.
3. Power Connection: Plug the power cord into a grounded electrical outlet.
4. Initial Check: Before stepping on, ensure the belt is centered and there are no obstructions.

Figure 4.1: The treadmill is designed for easy movement and storage, arriving fully assembled.

5. Operating Instructions

5.1 Power On/Off

• To power on, plug in the treadmill and press the power button (if available, otherwise it powers on automatically).
• To power off, press the power button on the unit or remote, then unplug from the wall.

5.2 Using the Remote Control

The wireless remote control allows you to manage your workout without bending down.

• Start/Stop: Press the Start/Stop button to begin or end your workout.
• Speed Adjustment: Use the '+' and '-' buttons to increase or decrease the speed (1-10 km/h).
• Pause: The pause button temporarily stops the belt and retains your workout data.
• Remote Storage: The remote control has a magnetic back for convenient storage on the treadmill's side to prevent loss.

Figure 5.1: The remote control can be conveniently stored on the side of the treadmill.

5.3 Adjusting the Incline

The treadmill features a manual 9% incline adjustment.

1. To engage the incline, lift the rear of the treadmill and secure the incline support mechanism.
2. To return to a flat position, disengage the incline support and lower the treadmill.

Figure 5.2: Illustrates the manual incline adjustment and its impact on workout intensity and calorie expenditure.

5.4 LED Display

The integrated LED display shows your real-time workout data:

• Time: Duration of your workout.
• Speed: Current speed in km/h.
• Distance: Total distance covered.
• Calories: Estimated calories burned.

Figure 5.3: The clear LED display provides essential workout metrics at a glance.

6. Maintenance

6.1 Cleaning

• Wipe down the treadmill with a damp cloth after each use to remove sweat and dust.
• Do not use abrasive cleaners or solvents.

6.2 Belt Lubrication

Regular lubrication of the running belt is crucial for optimal performance and longevity.

Figure 6.1: Lubrication plan for the running belt.

To lubricate, lift the edge of the running belt and apply a small amount of silicone lubricant (not included) to the center of the deck. Run the treadmill at a low speed for a few minutes to distribute the lubricant.

6.3 Belt Adjustment

If the running belt becomes misaligned or too loose/tight, it may need adjustment using the provided tool.

Figure 6.2: Adjusting the running belt with the provided tool.

• Refer to the specific instructions in the included tool kit for detailed belt adjustment procedures.
• A slight mark on the running belt is the belt joint and is considered normal, not a defect.

7. Troubleshooting

If you encounter any issues with your VANNECT Walking Pad Treadmill, please refer to the following common troubleshooting steps:

If the problem persists after attempting these solutions, please contact VANNECT Customer Support for assistance.

8. Specifications

9. Warranty and Support

VANNECT is committed to providing high-quality products and excellent customer service.

• Warranty: The VANNECT X390AS Walking Pad Treadmill comes with a 5-year free warranty.
• Customer Support: For any questions, technical assistance, or warranty claims, please contact VANNECT customer service. Our engineers can provide video assistance if needed.
• Please have your model number (X390AS) and proof of purchase ready when contacting support.
