Wipro Deco 20W ML1 LED Mirror Light Instruction Manual

1. Introduction

This manual provides essential information for the safe installation, operation, and maintenance of your Wipro Deco 20W ML1 LED Mirror Light. Please read this manual thoroughly before installation and retain it for future reference.

The Wipro Deco ML1 LED Mirror Light is designed to provide efficient and glare-free illumination for various indoor spaces, including bathrooms, dressing tables, and wall picture displays. It features a cool day white (6500K) light output and a stylish design.

2. Safety Information

WARNING: To reduce the risk of electric shock, fire, or injury to persons, read and follow all warnings and instructions carefully.

• Always disconnect power at the main circuit breaker before installation or servicing.
• Installation should be performed by a qualified electrician in accordance with all applicable electrical codes.
• Do not install this fixture in wet locations. It is designed for indoor use only and is not water resistant.
• Ensure the supply voltage is compatible with the fixture's requirements (220-240V AC, 50/60Hz).
• Do not attempt to modify the fixture. Any modifications may void the warranty and create safety hazards.
• Keep flammable materials away from the light fixture.
• Avoid direct eye exposure to the light source when illuminated.

3. Package Contents

Verify that all components are present before beginning installation:

• Wipro Deco 20W ML1 LED Mirror Light (2 units)
• Instruction Manual
• Mounting Hardware (screws, wall anchors) - (Assumed, typically included with wall-mount fixtures)

Image 3.1: Wipro Deco ML1 LED Mirror Lights in their retail packaging.

4. Product Features

• Eye Comfort: Glare-free soothing texture with high-quality diffused optics for visual comfort and even light distribution.
• Driver Protection: Equipped with 440V high voltage and 4kV surge protection to safeguard against adverse voltage conditions.
• Long Life: Utilizes high-quality LM 80 Tested LEDs for extended operational lifespan.
• Energy Saving: LED technology offers higher efficiency compared to conventional lighting, reducing electricity consumption.
• High Brightness: 20W LED light provides up to 2000 lumens of illumination.
• Stylish Design: Modern aesthetic suitable for various home interiors.

Image 4.1: Key features of the Wipro Deco ML1 LED Mirror Light.

5. Setup and Installation

This fixture is designed for wall-mount installation. Professional installation is recommended.

5.1 Tools Required (Not Included)

• Screwdriver (Phillips head)
• Drill with appropriate drill bit for wall anchors
• Pencil
• Measuring tape
• Wire strippers
• Electrical tape

5.2 Installation Steps

1. Turn Off Power: Locate the circuit breaker controlling the power to the installation area and turn it OFF. Verify power is off using a voltage tester.
2. Mark Mounting Position: Hold the fixture against the wall at the desired installation height and location. Use a pencil to mark the positions for the mounting screws. Ensure the fixture is level.
3. Drill Holes: Drill pilot holes at the marked positions. Insert wall anchors if necessary, depending on the wall material.
4. Connect Wiring: Carefully connect the electrical wires from the wall to the fixture's wires. Typically, connect live (L) to live, neutral (N) to neutral, and ground (G) to ground. Use wire nuts and electrical tape to secure connections. Ensure no bare wires are exposed.
5. Mount Fixture: Align the fixture with the drilled holes and secure it to the wall using the provided mounting screws. Do not overtighten.
6. Restore Power: Once the fixture is securely mounted and all connections are checked, restore power at the main circuit breaker.

Image 5.1: Example installation above a bathroom vanity.

Image 5.2: Example installation above a medicine cabinet.

6. Operating Instructions

The Wipro Deco ML1 LED Mirror Light is operated via a standard wall switch (toggle or push button, depending on your home's wiring). There are no integrated controls on the fixture itself.

1. To Turn On: Flip the connected wall switch to the "ON" position.
2. To Turn Off: Flip the connected wall switch to the "OFF" position.

The light provides a consistent Cool Day White (6500K) illumination once activated.

Image 6.1: Illustration of different color temperatures. This model provides 6500K Cool White light.

7. Maintenance

Regular maintenance ensures optimal performance and longevity of your LED mirror light.

• Cleaning: Ensure the power is OFF before cleaning. Use a soft, dry, or slightly damp cloth to wipe the exterior of the fixture. Do not use abrasive cleaners, solvents, or cleaners containing alcohol, as these can damage the finish or electrical components.
• Bulb Replacement: This fixture uses integrated LED components and does not require bulb replacement. If the light stops functioning, refer to the troubleshooting section or contact customer support.
• Inspection: Periodically check for any loose wiring or damage to the fixture. If any damage is observed, disconnect power immediately and contact a qualified electrician or customer support.

8. Troubleshooting

If you encounter issues with your Wipro Deco ML1 LED Mirror Light, refer to the following common problems and solutions:

If the problem persists after trying these solutions, please contact Wipro customer support.

9. Specifications

10. Warranty and Support

For warranty information and customer support, please refer to the warranty card included with your product or contact Wipro customer service directly.

Manufacturer: Wipro Enterprises (p) Ltd

Contact Number: 1-800-425-1969

Please have your product model number (D542065) and purchase details ready when contacting support.
