AIKVSXER S-10000W Solar Street Light Instruction Manual

Introduction

This manual provides detailed instructions for the installation, operation, and maintenance of your AIKVSXER S-10000W Solar Street Light. Please read this manual thoroughly before use to ensure proper function and longevity of the product.

Safety Information

• Ensure all mounting hardware is securely fastened to prevent the light from falling.
• Do not look directly into the LED lights when illuminated, as this may cause eye strain or damage.
• Keep the solar panel clean and free from obstructions to ensure optimal charging efficiency.
• Do not attempt to disassemble or modify the product, as this will void the warranty and may cause damage or injury.
• Install the light in a location that receives direct sunlight for at least 4-6 hours daily for best performance.

Package Contents

Verify that all items listed below are included in your package:

• Solar Street Light (1 unit)
• Remote Control (1 unit)
• Screws (for mounting)
• Allen Wrench (1 unit)
• Instruction Manual (this document)

Figure 1: Package Contents. The image displays the solar street light unit, a remote control, various screws, and an Allen wrench, all neatly arranged.

Product Features

• High Lumen LED Beads & Optical Lens Design: Features high-brightness LED beads and transparent optical lenses for enhanced light distribution. Provides 6500K daylight with up to 800,000lm brightness. Stepless dimming (10%-100%) is available via remote control.
• 3 Lighting Modes:
  1. Motion Sensor: 100% brightness when motion is detected, returning to 30% brightness after 30 seconds of no motion.
  2. Dusk to Dawn: Automatically turns on at dusk and off at dawn.
  3. Three Timing Modes: 2H/3H/4H constant lighting, then automatically switches to motion sensor mode.
• Solar Powered: Operates on solar energy with a large capacity battery, eliminating electricity costs. Provides up to 24 hours of continuous lighting after 4-6 hours of full charge.
• IP67 Waterproof and Durable Material: Constructed with a special waterproof structure and high-quality ABS material, making it resistant to water, rain, snow, and oxidation. Operates in temperatures between -22℉ and 140℉.
• Easy Installation: Offers two installation methods: Pole Mount and Wall Mount. No complex wiring or additional accessories required.

Figure 2: Key Features of the AIKVSXER Solar Street Light. This image visually summarizes the main benefits and functionalities of the product.

Figure 3: High Lumen LED Beads and Optical Lens Design. The image highlights the individual LED modules with their specialized optical lenses designed for maximum brightness and light distribution.

Figure 4: Upgraded Large Capacity Battery. This diagram illustrates the 36000mAh battery and its integrated protection features, including overcharge, overdischarge, short circuit, and leakage protection.

Installation

The AIKVSXER S-10000W Solar Street Light offers flexible installation options for various outdoor environments.

Mounting Options:

• Pole Mount: Ideal for street lighting, parking lots, and open areas.
• Wall Mount: Suitable for garages, courtyards, and building exteriors.

Installation Steps:

1. Choose Location: Select a location that receives maximum direct sunlight throughout the day to ensure optimal charging of the solar panel. Avoid areas shaded by trees, buildings, or other obstructions.
2. Assemble Pole/Bracket: Attach the provided mounting arm to the solar street light unit using the included Allen wrench and screws.
3. Secure Mount:
   • For Pole Mount: Secure the mounting bracket to a pole (recommended diameter: 2.56-3.15 inches) using the provided expansion bolts.
   • For Wall Mount: Secure the mounting bracket to a sturdy wall using the provided screws.
4. Attach Light Unit: Slide the assembled light unit onto the secured mounting arm and fasten it with the appropriate screws. Ensure the solar panel faces upwards towards the sun.
5. Test Functionality: After installation, use the remote control to test the light's functions.

Figure 5: Wall Mount and Pole Mount Options. This image demonstrates the two primary installation methods, providing visual guidance for placement.

Figure 6: Correct Installation Position. This diagram highlights optimal placement for the solar panel to receive maximum sunlight, avoiding shaded areas.

Operation

Your AIKVSXER S-10000W Solar Street Light is designed for automatic operation but can be controlled via the included remote.

Remote Control Functions:

Figure 7: Remote Control Layout and Functions. This image provides a visual guide to the remote control buttons and their corresponding actions.

• ON/OFF: Press to manually turn the light on or off.
• Brightness Adjustment: Use the Brightness +/- buttons for stepless dimming from 10% to 100%. Dedicated buttons for 50% and 100% brightness are also available.
• Motion Sensor Mode: Activates motion detection. The light will illuminate at 100% brightness upon detecting motion and dim to 30% after 30 seconds of inactivity.
• Dusk to Dawn Mode: The light automatically turns on when it gets dark and turns off when it detects daylight.
• Timing Modes (2H/3H/4H): Sets the light to stay on at a constant brightness for 2, 3, or 4 hours, after which it will automatically switch to motion sensor mode.
• AUTO: Activates the intelligent light sensor for automatic dusk-to-dawn operation.
• Sleep Mode: Reduces brightness to a minimal level for extended operation.

Figure 8: Automatic Dusk to Dawn Operation. The image shows the light's ability to automatically activate at night and deactivate during the day, conserving energy.

Figure 9: Motion Sensing Mode. This graphic explains how the light adjusts its brightness based on detected movement, enhancing security and energy efficiency.

Figure 10: Brightness Adjustment Levels. This series of images visually represents the various brightness settings available, from 10% to 100%.

Figure 11: Timing Modes. This image illustrates the timed lighting options, where the light operates at a set brightness for a specified duration before transitioning to motion sensor mode.

Maintenance

To ensure optimal performance and extend the lifespan of your solar street light, follow these maintenance guidelines:

• Clean Solar Panel: Regularly wipe the solar panel with a soft, damp cloth to remove dust, dirt, leaves, or snow. A clean panel ensures maximum sunlight absorption and charging efficiency.
• Check Connections: Periodically inspect all mounting screws and connections to ensure they remain tight and secure.
• Battery Indicator: Monitor the battery indicator lights on the unit to understand the current charge level.

Troubleshooting

If you encounter issues with your AIKVSXER S-10000W Solar Street Light, refer to the following common troubleshooting steps:

Specifications

Warranty and Support

AIKVSXER offers a 3-Year Product Warranty for the S-10000W Solar Street Light. For any questions, concerns, or support needs regarding your product, please contact our customer service team. We are committed to providing a satisfactory solution.

For further assistance, please visit the AIKVSXER Store on Amazon.
