OOTD T10 Electric Scooter User Manual

Introduction

Thank you for choosing the OOTD T10 Electric Scooter. This manual provides essential information for the safe operation, maintenance, and troubleshooting of your new scooter. Please read it thoroughly before your first ride to ensure optimal performance and safety.

The OOTD T10 is designed for adults, featuring a powerful motor, robust construction, and advanced safety features for a comfortable and secure riding experience across various terrains.

What's in the Box

Upon unboxing your OOTD T10 Electric Scooter, please verify that all components listed below are present and in good condition:

• Product Instructions x 1
• Installation Tools x 1
• Wrench for mounting rod x 1
• Chargers x 1
• OOTD T10 Electric Scooter (Main Unit)

If any items are missing or damaged, please contact customer support immediately.

Safety Guidelines

Your safety is paramount. Adhere to the following guidelines to prevent accidents and ensure a safe riding experience:

• Always wear a helmet and appropriate protective gear (knee pads, elbow pads, gloves) when riding.
• Familiarize yourself with local laws and regulations regarding electric scooter usage.
• Do not ride under the influence of alcohol or drugs.
• Avoid riding in heavy rain, snow, or icy conditions.
• Maintain a safe distance from other vehicles, pedestrians, and obstacles.
• Check tire pressure, brakes, and lights before each ride.
• Do not exceed the maximum weight limit of 150 kg (330 lbs).
• Children under 16 years old should not operate this scooter.
• Always use both front and rear brakes for effective stopping.

Setup and Assembly

The OOTD T10 Electric Scooter comes partially assembled. Follow these steps to complete the setup:

1. Unfolding the Scooter:

   Carefully remove the scooter from its packaging. Locate the folding mechanism near the base of the handlebar stem. Release the latch and lift the handlebar stem until it locks securely into place. Ensure it is fully locked before proceeding.



   Image: The OOTD T10 Electric Scooter in its fully unfolded state, ready for use.

2. Handlebar Installation:

   Attach the handlebars to the stem, ensuring all cables are properly routed and not pinched. Secure them using the provided screws and the installation tools. Tighten firmly but do not overtighten.

3. Checking Tire Pressure:

   The 11-inch off-road tires are designed for various terrains. Before your first ride, check the tire pressure and inflate to the recommended PSI (usually indicated on the tire sidewall or in a separate quick-start guide).



   Image: A detailed view of the 11-inch anti-skid and wear-resistant tire, highlighting its robust tread pattern.

4. Initial Charge:

   Before the first use, fully charge the scooter's battery. Connect the charger to the charging port and plug it into a standard power outlet. The charging indicator will show the charging status. A full charge typically takes 4-5 hours.



   Image: An illustrative diagram showcasing the internal structure and capacity of the 48V 13.5Ah large capacity lithium battery.

Operating Instructions

Getting Started

1. Power On/Off:

   Press and hold the power button on the display panel to turn the scooter on or off.



   Image: The large LED display of the OOTD T10, providing real-time information such as speed, battery level, selected gear, and total mileage.

2. Speed Modes:

   The scooter features multiple speed modes (typically 3). Press the mode button to cycle through them. Start with the lowest speed mode until you are comfortable with the scooter's handling.

3. Acceleration:

   Gently press the throttle lever to accelerate. The scooter is equipped with a 500W (900W peak) brushless motor, providing strong acceleration and uphill climbing capability up to 35 degrees.



   Image: An exploded view illustrating the powerful 500W high-efficiency motor and its capability to ascend inclines of up to 35 degrees.

4. Braking:

   The OOTD T10 is equipped with front and rear disc brakes for reliable stopping power. Gently squeeze both brake levers simultaneously to slow down and stop. Avoid sudden, hard braking, especially at high speeds.

5. Lighting System:

   Activate the ultra-bright LED headlights (high and low beam) and the "eagle eye" taillight for optimal visibility during day and night. Use turn signals when changing direction.



   Image: The scooter's dual LED headlights illuminating the path ahead, along with the rear turn signals for enhanced visibility and safety.

Folding and Storage

The OOTD T10 features a convenient one-touch folding mechanism for easy transport and storage:

1. Folding:

   Ensure the scooter is powered off. Locate the folding latch and release it. Carefully fold the handlebar stem downwards until it clicks into its locked position. This reduces the scooter's dimensions to 126.5 x 30.5 x 57.5 cm.



   Image: A person easily folding the OOTD T10 scooter and placing it into the trunk of a car, demonstrating its portability.

2. Storage:

   Store the folded scooter in a dry, cool place away from direct sunlight and extreme temperatures. Keep it away from flammable materials.

Maintenance

Regular maintenance ensures the longevity and safe operation of your OOTD T10 Electric Scooter:

• Cleaning:

  Wipe the scooter with a damp cloth after each use. Do not use high-pressure water jets or corrosive cleaning agents. Ensure the charging port cover is securely closed to prevent water ingress.

• Battery Care:

  Charge the battery regularly, even if the scooter is not in use for extended periods (at least once every 30 days). Avoid completely draining the battery. Use only the original charger provided.

• Tires:

  Regularly inspect tires for wear, punctures, or damage. Maintain recommended tire pressure for optimal performance and range.

• Brakes:

  Check brake pads and discs for wear. Adjust brake tension if necessary to ensure responsive braking. If you notice reduced braking performance, have them inspected by a qualified technician.

• Fasteners:

  Periodically check all screws and bolts to ensure they are tight. Loose fasteners can affect stability and safety.

Troubleshooting

This section addresses common issues you might encounter with your OOTD T10 Electric Scooter. For problems not listed here, please contact customer support.

Specifications

Image: A diagram illustrating the unfolded and folded dimensions of the OOTD T10, along with suitable rider height, maximum load, and net weight.

Warranty and Support

OOTD offers a 12-month warranty on key components of your T10 Electric Scooter, ensuring peace of mind. This warranty covers manufacturing defects under normal use conditions.

For any inquiries, technical assistance, or warranty claims, please contact our premium after-sales service. You can reach us through the seller's contact information on the platform where you purchased the product, or visit the official OOTD brand store for support options.

Seller: SZABO STORE S.R.L

Your satisfaction is our priority, and we are committed to providing excellent support throughout your ownership experience.
