1. Introduction
Thank you for choosing the ELECCTV W1-B-2PC 2K Dual-Band WiFi Security Camera. This manual provides essential information for the proper installation, operation, and maintenance of your security camera system. The W1-B-2PC camera features advanced 2.4GHz and 5GHz dual-band wireless connectivity, 2K QHD video resolution, color night vision, AI motion detection with spotlight and siren, two-way audio communication, and an IP65 weather-resistant design for reliable outdoor use. Please read this manual thoroughly before use to ensure optimal performance and safety.
2. Safety Information
- Ensure the camera is installed in a location where it is protected from direct impact or vandalism.
- Use only the provided charging cable and adapter to charge the camera's battery.
- Do not expose the camera to extreme temperatures outside its operating range (-4°F to 113°F / -20°C to 45°C).
- Keep the camera and its accessories out of reach of children.
- Avoid pointing the camera directly at strong light sources, as this may affect image quality.
- Regularly check the mounting to ensure the camera remains securely attached.
3. Package Contents
Verify that all items are present in your package:
- ELECCTV W1-B-2PC Security Camera (2 units)
- Mounting Bracket (2 units)
- USB Charging Cable (2 units)
- Mounting Screw Kit (2 sets)
- User Manual
4. Product Overview
Familiarize yourself with the components of your ELECCTV W1-B-2PC camera:
Image: Front view of two ELECCTV W1-B-2PC cameras.
- Lens: Captures 2K QHD video footage.
- Spotlight: Provides illumination for color night vision and acts as a deterrent.
- PIR Motion Sensor: Detects heat signatures for accurate motion detection.
- Microphone: Captures audio for two-way talk and recording.
- Speaker: Enables two-way audio communication and siren activation.
- Mounting Base: Allows for secure wall or ceiling installation.
- USB Charging Port: For recharging the internal battery.
- Reset Button: Used to reset the camera to factory settings.
- Micro SD Card Slot: Supports local storage up to 256GB (card not included).
5. Setup Guide
5.1. Charging the Camera
Before initial use, fully charge the camera's built-in rechargeable battery. Connect the provided USB charging cable to the camera's charging port and a standard 5V/2A USB power adapter (not included). The charging indicator light will show the charging status. A full charge can last 1-3 months depending on usage and power-saving settings.
5.2. App Installation
Download and install the O-KAM Pro app on your smartphone. The app is available for both iOS and Android devices. Search for "O-KAM Pro" in your device's app store or scan the QR code provided in the quick start guide (if applicable).
Image: O-KAM Pro app interface for easy setup and WiFi connection.
5.3. Device Pairing
Follow these steps to connect your camera to your Wi-Fi network:
- Open the O-KAM Pro app and create an account or log in.
- Tap the "+" icon to add a new device.
- Select your camera model from the list.
- Power on the camera. If the indicator light is not flashing, press and hold the reset button for 5 seconds until it flashes.
- Follow the in-app instructions to connect the camera to your 2.4GHz or 5GHz Wi-Fi network. The camera supports dual-band connectivity for a stable connection.
- Scan the QR code displayed on your phone with the camera lens.
- Once connected, name your camera and complete the setup.
Image: Dual-band WiFi 6 connectivity and key features.
5.4. Camera Mounting
The ELECCTV W1-B-2PC camera is 100% wire-free and IP65 waterproof, allowing for flexible installation both indoors and outdoors. Choose a location with a strong Wi-Fi signal and a clear view of the area you wish to monitor.
- Mark the desired drilling spots using the mounting bracket as a template.
- Drill holes and insert wall anchors if mounting on a masonry surface.
- Secure the mounting bracket to the wall or ceiling using the provided screws.
- Attach the camera to the mounting bracket and adjust the angle for optimal coverage.
Image: Camera demonstrating IP65 waterproof rating in rain.
Image: Flexible mounting options for the camera.
6. Operating Instructions
6.1. Live View and Playback
Access the O-KAM Pro app to view live 2K QHD video from your camera. You can also review recorded events by date and time. The app supports simultaneous live streaming from up to four cameras for comprehensive coverage.
Image: Reviewing recorded events in the app.
Image: Quad-view live streaming in the app.
6.2. Two-Way Audio
The camera features a built-in microphone and speaker. In the live view interface of the O-KAM Pro app, tap the microphone icon to speak through the camera and the speaker icon to listen to audio from the camera's location.
6.3. Motion Detection and Alerts
The camera utilizes AI motion detection to identify human movement. When motion is detected, the camera can activate its spotlight, trigger a 120dB siren, and send instant notifications to your smartphone. You can customize detection zones and sensitivity settings within the app to reduce false alerts.
Image: Night guard security with spotlight and siren activation.
Image: AI precision detection for persons and birds.
6.4. Night Vision Modes
The camera offers both infrared and full-color night vision. With its 2K QHD resolution and integrated spotlights, you can achieve clear, detailed color images even in low-light conditions. The 130° wide-angle lens provides extensive coverage.
Image: 2K QHD Color Night Vision in action.
Image: Day and night security with color night vision and digital zoom capabilities.
6.5. Storage Options
Your camera supports two storage methods:
- Micro SD Card: Insert a Micro SD card (up to 256GB, not included) into the designated slot for local storage of recordings.
- Cloud Storage: The camera offers free 1-day rolling cloud storage for life, with no subscription required for this basic service. Extended cloud storage plans may be available through the app.
Image: SD Card and Cloud storage options.
6.6. Smart Home Integration (Alexa)
The ELECCTV W1-B-2PC camera is compatible with Amazon Alexa. Follow the instructions in the O-KAM Pro app or your Alexa app to link your camera and enable voice commands for live viewing on compatible Alexa-enabled devices.
6.7. Sharing Access
You can share access to your camera's live feed and recordings with family members through the O-KAM Pro app. This allows multiple users to monitor the property simultaneously.
Image: Sharing camera access with family for enhanced security.
6.8. Bird Identification Feature
The camera includes an advanced bird identification feature that can distinguish different bird species. Note that this feature requires a separate subscription within the O-KAM Pro app.
Image: Bird identification and night security features.
Image: New bird identification feature in the app.
7. Maintenance
- Battery Charging: Recharge the camera battery as needed. The app will notify you when the battery level is low.
- Cleaning: Periodically clean the camera lens and body with a soft, dry cloth to ensure clear image quality and proper sensor function. Do not use harsh chemicals.
- Firmware Updates: Keep the camera's firmware updated through the O-KAM Pro app to ensure optimal performance, security, and access to new features.
8. Troubleshooting
| Issue | Possible Solution |
|---|---|
| Camera not connecting to Wi-Fi | Ensure your Wi-Fi network is 2.4GHz or 5GHz. Check Wi-Fi signal strength at the camera's location. Reset the camera and try pairing again. Verify correct Wi-Fi password entry. |
| Poor image quality | Clean the camera lens. Ensure there are no obstructions in the camera's field of view. Check Wi-Fi signal strength for stable streaming. |
| Motion detection not working or too sensitive | Adjust motion detection sensitivity and customize detection zones in the O-KAM Pro app. Ensure the PIR sensor is not blocked. |
| Battery drains quickly | Reduce motion detection frequency or sensitivity. Adjust power-saving modes in the app. Ensure the camera is not in an area with constant motion. |
| Two-way audio not functioning | Check microphone and speaker permissions for the O-KAM Pro app on your smartphone. Ensure camera's microphone and speaker are not obstructed. |
9. Specifications
| Feature | Specification |
|---|---|
| Model Name | W1 |
| Video Capture Resolution | 2K QHD (1920p) |
| Connectivity Technology | Wi-Fi (2.4GHz & 5GHz Dual-Band) |
| Power Source | Battery Powered (Rechargeable) |
| Indoor/Outdoor Usage | Outdoor |
| Water Resistance Level | IP65 |
| Special Features | Wireless, AI Motion Detection, Spotlight, Siren, Color Night Vision, 2-Way Talk |
| Compatible Devices | Smartphone (via O-KAM Pro App), Amazon Alexa |
| Storage Options | Micro SD Card (up to 256GB), Cloud Storage |
| Lens Aperture | f/2.0 |
| Digital Zoom | 5X |
| Field of View | 130° Wide-angle |
| Product Dimensions | 8 x 2 x 2.7 inches |
| Item Weight | 1.39 pounds (0.63 Kilograms) |
| UPC | 765150757364 |
10. Warranty and Support
ELECCTV products are designed for reliability and performance. For specific warranty details, please refer to the warranty card included with your product or visit the official ELECCTV website. If you encounter any issues or require technical assistance, please contact ELECCTV customer support through the O-KAM Pro app or the contact information provided on the ELECCTV website.
