MXV 78-Inch Electric Fireplace TV Stand User Manual

1. Introduction

Thank you for choosing the MXV 78-Inch Electric Fireplace TV Stand. This manual provides essential information for the safe assembly, operation, and maintenance of your new entertainment center. Please read all instructions carefully before use and retain this manual for future reference.

2. Safety Information

Important Safety Warnings:

• Do not place heavy objects on top of the TV stand exceeding the specified weight capacity.
• Ensure the stand is properly assembled and stable before placing any items or using the fireplace.
• Be cautious of the fireplace component as it may get hot during operation.
• Keep children and pets away from the stand when the electric fireplace is in use.
• Do not block the air vents of the electric fireplace.
• Only use the provided power cord and avoid overloading the power outlet.

3. Product Features

• Electric Fireplace: Features a 36-inch electric fireplace with remote or touch button control. Includes a 0-8 hour timer, 62°F–82°F thermostat, 750W/1500W heating modes, 12 flame colors, and 5-level brightness. Built-in overheat protection ensures safe operation.
• Multi-function TV Cabinet: Equipped with three 125V outlets and two USB ports (5V/2.1A) for convenient device charging. Both sides include open compartments with 12-color LED light strips, remotely adjustable to match your room’s ambiance.
• Ample Storage Space: Measuring 78" W × 13.8" D × 25.2" H, this TV stand provides flexible organization with three open shelves and two lockable cabinets, suitable for media equipment and accessories.
• Sturdy & Durable Design: Constructed with certified particleboard and MDF for lasting stability. The reinforced structure offers reliable support for your TV and electronics, with a weight capacity of 132 lbs.

4. Package Contents

The MXV 78-Inch Electric Fireplace TV Stand is shipped in two separate boxes. Please ensure you have received both packages before beginning assembly. All necessary components for assembly are included.

5. Assembly Instructions

Assembly is required for this product. Please follow the detailed instructions provided in the included assembly manual. A general overview of the steps is as follows:

1. Attach legs with screws. Tighten using the provided tool.
2. Insert dowels into pre-drilled holes.
3. Align panels and secure with bolts.
4. Connect electrical components as per the diagram.
5. Install the fireplace component last.

For detailed diagrams and step-by-step guidance, refer to the separate assembly guide included in your package.

6. Operating Instructions

6.1 Electric Fireplace Operation

The electric fireplace can be controlled via the included remote control or the touch buttons on the unit.

• Power On/Off: Press the power button on the remote or unit.
• Heating Modes: Select between 750W or 1500W heating modes.
• Thermostat: Adjust temperature from 62°F to 82°F.
• Timer: Set an automatic shut-off timer from 0 to 8 hours.
• Flame Colors: Choose from 12 different flame colors to suit your preference.
• Flame Brightness: Adjust the flame brightness to 5 different levels (L1-L5) by holding the flame button for 3 seconds.

6.2 LED Light Strips Operation

The LED light strips in the open compartments can be adjusted remotely.

• Use the dedicated remote control for the LED lights to change colors and brightness.
• Select from 12 available colors to create different ambiances.

6.3 Power Outlet and USB Ports

The built-in power strip provides convenient access to power for your devices.

• Plug in up to three 125V AC devices into the outlets.
• Use the two 5V/2.1A USB ports to charge compatible electronic devices.

7. Maintenance

• Cleaning: Wipe surfaces with a soft, damp cloth. Avoid harsh chemicals or abrasive cleaners.
• Dusting: Regularly dust the unit to prevent buildup, especially around the fireplace vents.
• Electrical Components: Periodically check the power cord and plugs for any damage. Do not use if damaged.
• Fireplace: The electric fireplace requires minimal maintenance. Ensure vents are clear.

8. Troubleshooting

If you encounter any issues with your MXV Electric Fireplace TV Stand, please refer to the following common solutions:

• Fireplace not turning on: Check if the unit is properly plugged into a working outlet. Ensure the power switch on the fireplace unit is in the 'ON' position.
• No heat output: Verify that the heating mode is activated and the thermostat is set to a temperature higher than the ambient room temperature.
• LED lights not working: Check the connection of the LED strips to the power source. Ensure the remote control batteries are functional.
• Power outlets/USB ports not working: Confirm the main power cord for the TV stand is securely plugged in. Test with another device to rule out device issues.
• Overheat protection activated: If the fireplace shuts off unexpectedly, it may be due to overheat protection. Unplug the unit, allow it to cool for 15-20 minutes, and ensure no vents are blocked before restarting.

If problems persist, please contact MXV customer support.

9. Specifications

10. Warranty and Support

For warranty information, product support, or to purchase replacement parts, please contact MXV customer service. Refer to your purchase documentation for specific warranty terms and contact details.
