Introduction
This manual provides comprehensive instructions for the installation, operation, and maintenance of your ANRAN 5MP 4G LTE Solar Security Camera. Please read this manual thoroughly before using the product to ensure proper functionality and safety. Keep this manual for future reference.
Product Overview
Key Features:
- 5MP HD Video & 360° Pan/Tilt: Captures clear 5MP (2560x1920) video with 355° horizontal and 140° vertical rotation. Features 4X digital zoom.
- Day and Night Vision: Equipped with infrared (IR) night vision and 2.5K color night vision via four spotlights for comprehensive coverage.
- Solar Powered & Wire-Free: Integrated 9600mAh battery and high-efficiency solar panel provide continuous power, eliminating the need for external wiring.
- 4G LTE Cellular Connectivity: Operates independently without Wi-Fi, ideal for remote locations. Includes a pre-installed ANRAN SIM card with 100MB data.
- PIR Motion Detection: Advanced sensor detects persons, pets, vehicles, and parcels, reducing false alarms. Customizable alarm plans and sensitivity levels.
- Two-Way Audio: Built-in speaker and microphone enable real-time communication through the companion application.
Package Contents:
- ANRAN 5MP 4G LTE Solar Security Camera
- Solar Panel
- Mounting Bracket and Screws
- USB Charging Cable
- User Manual
- Pre-installed ANRAN SIM Card (with 100MB data)
- 32GB Micro SD Card (pre-installed)
Image: The ANRAN 5MP 4G LTE Solar Security Camera, shown with its accompanying solar panel and mounting hardware.
Setup Guide
1. Initial Charging
Before first use, fully charge the camera's internal battery using the provided USB cable. Connect the cable to the camera's charging port and a standard 5V/2A USB power adapter (not included). The charging indicator light will show the charging status.
2. SIM Card Installation
The camera comes with a pre-installed ANRAN SIM card. Ensure it is properly seated in the SIM card slot. Note: Only the provided ANRAN SIM card is compatible. Self-replacement of SIM cards is not supported.
Image: A detailed view of the camera's SIM card slot, indicating where the pre-installed ANRAN SIM card should be located.
3. App Download and Account Registration
- Scan the QR code in the manual or search for "ANRAN" in your mobile app store (iOS App Store or Google Play Store).
- Download and install the ANRAN application.
- Open the app and register a new account using your email address or phone number.
4. Adding the Camera to the App
- Power on the camera.
- In the ANRAN app, tap the "+" icon to add a new device.
- Select "4G Camera" or the appropriate device type.
- Follow the on-screen instructions to scan the QR code on the camera or manually enter its device ID.
- Once connected, you can name your camera and begin live viewing.
5. Mounting the Camera and Solar Panel
Choose a location that provides optimal sunlight exposure for the solar panel and a clear view for the camera. Ensure the camera is within range of a strong 4G LTE signal.
- Mark Drilling Positions: Use the mounting bracket as a template to mark the screw holes on the desired surface.
- Drill Holes: Drill pilot holes at the marked positions.
- Secure Bracket: Attach the mounting bracket to the surface using the provided screws and anchors.
- Attach Camera: Secure the camera to the mounting bracket. Adjust the angle for optimal coverage.
- Position Solar Panel: Mount the solar panel in a location that receives direct sunlight for most of the day. Connect the solar panel cable to the camera's charging port.
Image: The ANRAN camera and solar panel mounted on an exterior wall, demonstrating a flexible wireless setup.
Operating Instructions
1. Live View and PTZ Control
Open the ANRAN app and select your camera to access the live view. Use the on-screen controls to pan (355° horizontally) and tilt (140° vertically) the camera. You can also use the digital zoom feature to get a closer look.
Image: The ANRAN camera demonstrating its 355° pan and 90° tilt capabilities, controlled via the mobile application interface.
2. Motion Detection and Alerts
- Enable PIR Motion Detection: In the app settings, navigate to "Motion Detection" and enable the PIR sensor.
- Adjust Sensitivity: Set the detection sensitivity level to minimize false alarms. Higher sensitivity detects smaller movements.
- Set Alarm Plan: Configure schedules for when motion detection should be active.
- Receive Alerts: When motion is detected, the camera will send instant push notifications to your phone and can trigger a smart siren alarm.
Image: An illustration of the ANRAN camera detecting a person, triggering a push notification and siren alarm on a mobile device.
3. Two-Way Audio
From the live view, tap the microphone icon to speak through the camera's speaker. Tap the speaker icon to listen to audio from the camera's surroundings. This feature allows for real-time communication.
Image: People interacting with the ANRAN camera's two-way audio feature, communicating with individuals near the camera through the mobile app.
4. Night Vision Modes
The camera supports both infrared (IR) black and white night vision and 2.5K color night vision. In low-light conditions, the camera automatically switches to night vision. You can configure the night vision mode in the app settings.
Image: A split view demonstrating the ANRAN camera's 5MP HD clarity in both daytime (color) and nighttime (infrared black and white) conditions.
5. Video Recording and Playback
Recorded videos are stored on the inserted SD card or in cloud storage (subscription may be required). Access recorded footage through the "Playback" or "History" section in the ANRAN app. You can filter by date and time to review specific events.
Maintenance
- Solar Panel Cleaning: Regularly clean the surface of the solar panel to ensure maximum sunlight absorption. Use a soft, damp cloth to remove dust, dirt, or debris.
- Camera Lens Cleaning: Gently wipe the camera lens with a microfiber cloth to maintain clear image quality. Avoid abrasive cleaners.
- Battery Health: While the solar panel provides continuous charging, ensure the camera receives adequate sunlight. If the camera is in a shaded area for extended periods, occasional manual charging via USB may be necessary.
- Firmware Updates: Check the ANRAN app periodically for firmware updates. Keeping the camera's firmware updated ensures optimal performance and security.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Camera not connecting to 4G network. | Weak 4G signal; SIM card not properly inserted or activated; incorrect APN settings. | Relocate the camera to an area with better 4G coverage. Ensure the ANRAN SIM card is correctly inserted. Contact ANRAN support if issues persist. |
| Battery not charging via solar panel. | Insufficient sunlight; dirty solar panel; faulty connection. | Ensure the solar panel is in direct sunlight and free from obstructions. Clean the solar panel surface. Check the connection cable between the panel and camera. |
| Frequent false motion alerts. | High PIR sensitivity; environmental factors (e.g., moving branches, insects). | Adjust the PIR motion detection sensitivity in the app settings. Ensure the camera's field of view is clear of common false alarm triggers. |
| No two-way audio. | Microphone/speaker disabled in app; app permissions not granted; network issues. | Check app settings to ensure microphone and speaker are enabled. Verify app permissions on your mobile device. Ensure a stable 4G connection. |
| Camera offline. | No 4G signal; battery depleted; camera powered off. | Check 4G signal strength. Recharge the camera battery. Power cycle the camera (turn off and on). |
Specifications
- Resolution: 5MP (2560x1920)
- Pan/Tilt Range: Horizontal 355°, Vertical 140°
- Zoom: 4X Digital Zoom
- Night Vision: IR Night Vision, 2.5K Color Night Vision (via spotlights)
- Connectivity: 4G LTE Cellular (does not support Wi-Fi)
- Battery: 9600mAh Rechargeable Battery
- Power Source: Solar Panel, USB Charging
- Motion Detection: PIR Humanoid Detection
- Audio: Two-Way Audio (Built-in Microphone & Speaker)
- Storage: Supports Micro SD Card (32GB included) and Cloud Storage
- SIM Card: ANRAN SIM card included (100MB data)
Warranty and Support
ANRAN products typically come with a limited warranty. Please refer to the warranty card included with your product or visit the official ANRAN website for detailed warranty information and terms. For technical support, product inquiries, or assistance with troubleshooting, please contact ANRAN customer service through their official website or the contact information provided in the product packaging.
