IMALENT GR35 EDC Flat Flashlight User Manual

Introduction

The IMALENT GR35 is an ultra high-performance EDC (Everyday Carry) flat flashlight designed for versatility and portability. It offers a powerful output of 2800 lumens and a maximum beam throw of 426 meters. This innovative device integrates four distinct functionalities: a bright white light, UV light, red-blue flashing emergency light, and a green beam/laser, making it suitable for a wide range of applications from checking and working to outdoor activities.

Key features include:

• Four-in-One Functionality: Combines white light, UV, red-blue light flashing, and green beam in a single, compact flashlight.
• High Performance: Delivers up to 2800 lumens and a 426-meter beam throw.
• Type-C Rechargeable: Fully charges in approximately 1 hour and 30 minutes, offering up to 33 hours and 43 minutes runtime on low mode.
• Versatile Output Modes: Features 6 brightness levels and a strobe function, easily accessible via a long press of the button.
• Higher UV Intensity: Provides up to 630mW at a 365nm wavelength, with a runtime of 6 hours and 15 minutes.
• Battery Level Indicator: Integrated indicator for convenient monitoring of battery status.

What's in the Box

Upon opening your IMALENT GR35 package, you should find the following items:

• IMALENT GR35 Flashlight (Battery Included) x 1
• PD Type-C Charging Cable x 1
• Lanyard x 1
• User Manual x 1

Setup

Charging the Device

The IMALENT GR35 is equipped with a Type-C charging port for convenient and fast recharging. Ensure the device is fully charged before its first use to maximize battery life and performance.

1. Locate the Type-C charging port on the flashlight.
2. Connect the provided Type-C charging cable to the flashlight and a compatible USB power source (e.g., wall adapter, computer USB port).
3. The battery level indicator will show the charging status. It typically glows red while charging and turns green when fully charged.
4. A full charge takes approximately 1 hour and 30 minutes.

Image: The IMALENT GR35 flashlight being charged via its Type-C port, with the charging indicator visible.

Initial Power On/Off

To power on or off the flashlight, locate the main control button. A quick press will typically activate the last used mode, while a long press or specific sequence may be required for power cycling or mode changes.

Operating Instructions

The IMALENT GR35 offers multiple light modes and brightness levels for various situations. Familiarize yourself with the control dial and buttons for optimal use.

Switching Modes and Brightness

The flashlight features a rotary switch for easy selection between different light functions (Laser, UV, Spotlight, Floodlight, Emergency Flasher). Once a mode is selected, a long press on the main button allows cycling through brightness levels.

Image: Close-up of the IMALENT GR35 control dial, illustrating the different light mode selections.

Available Light Functions:

• Green Beam/Laser: Ideal for pointing, presentations, or signaling.
• UV Light (365nm): Useful for detecting stains, verifying currency, or inspecting certain materials.
• White Light (Spotlight/Floodlight): Provides powerful illumination with 6 adjustable brightness levels, including a Turbo mode (2800 lumens) and a low Moonlight mode (20 lumens). Double-tap for instant full brightness or strobe.
• Red-Blue Flashing Light: An emergency signaling mode for increased visibility in critical situations.

Using the Multi-function Clip

The GR35 features a multi-function clip, perfect for securing the flashlight to pockets, belts, or even the brim of a hat for hands-free operation.

Image: The IMALENT GR35 flashlight clipped to the brim of a cap, providing illumination for reading.

Maintenance

Proper maintenance ensures the longevity and optimal performance of your IMALENT GR35 flashlight.

• Cleaning: Regularly wipe the flashlight body with a soft, damp cloth. Avoid using harsh chemicals or abrasive materials.
• Lens Care: Keep the lens clean and free from dust or debris. Use a lens cleaning cloth if necessary.
• Storage: Store the flashlight in a cool, dry place away from direct sunlight and extreme temperatures. If storing for extended periods, ensure the battery is partially charged (around 50%) and recharge every few months.
• Water Resistance: The GR35 is rated Waterproof (IPX7). Ensure the Type-C port cover is securely closed to maintain water resistance. Avoid submerging the flashlight beyond its rated depth or duration.

Troubleshooting

If you encounter issues with your IMALENT GR35, refer to the following common troubleshooting steps:

• Flashlight Not Turning On:
  • Check battery level. Recharge if necessary.
  • Ensure the device is not in lockout mode. Refer to the power on/off instructions.
• Light is Dim or Flickering:
  • Battery may be low. Recharge the flashlight.
  • Ensure the lens is clean.
• Charging Issues:
  • Verify the Type-C cable is securely connected to both the flashlight and the power source.
  • Try a different Type-C cable or power adapter.
  • Check the charging port for any obstructions.

If problems persist, please contact IMALENT customer support.

Specifications

Detailed technical specifications for the IMALENT GR35 flashlight:

Image: A graphic displaying the IMALENT GR35 Premium Edition specifications, including brightness levels, runtimes, and water resistance.

Warranty and Support

The IMALENT GR35 EDC Flat Flashlight comes with a Limited Warranty.

For warranty claims, technical support, or any inquiries regarding your product, please contact IMALENT customer service through their official website or the retailer where the product was purchased. Please have your proof of purchase and product model number (GR35) ready when contacting support.
