1. Introduction
This manual provides essential information for the safe and efficient use of your De'Longhi PRO 66 MXL PZ Gas Cooker. Please read these instructions carefully before installation, operation, and maintenance. Keep this manual for future reference.
The De'Longhi PRO 66 MXL PZ is a 60 cm free-standing gas cooker featuring a gas hob with 4 burners, including a powerful double crown burner, and a multifunction electric oven equipped with specialized functions such as Master Pizza and Easy Steam, alongside an Idroclean cleaning system. It is designed for domestic use and offers an Energy Class A rating for efficient operation.
2. Safety Instructions
General Safety:
- Ensure the appliance is installed by a qualified technician in accordance with local regulations.
- Do not store flammable materials near the appliance.
- Keep children away from the appliance during operation.
- Always use oven gloves when handling hot dishes or oven racks.
- Do not use abrasive cleaners or sharp objects for cleaning.
- In case of a gas leak, immediately close the main gas valve, open windows, and do not operate electrical switches. Contact a qualified technician.
Electrical Safety:
- Ensure the electrical supply matches the voltage specified on the appliance rating plate.
- Do not use extension cords or multiple adapters.
- If the power cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified persons to avoid a hazard.
Gas Safety:
- Verify that the gas supply type (natural gas G20 or LPG G30/G31) matches the appliance's configuration. Conversion kits (nozzles) are provided for LPG.
- Ensure adequate ventilation in the kitchen.
- Never leave gas burners unattended during operation.
3. Setup and Installation
The De'Longhi PRO 66 MXL PZ is a free-standing appliance. Proper installation is crucial for safety and performance.
3.1 Unpacking
Carefully remove all packaging materials. Check the appliance for any damage. Report any damage to your retailer immediately.
3.2 Positioning
Place the cooker on a flat, stable surface. Ensure sufficient clearance from adjacent furniture or walls as specified in the installation guide (refer to separate installation instructions for detailed measurements).
Image 1: Front view of the De'Longhi PRO 66 MXL PZ Gas Cooker, showing the hob with four burners, control knobs, digital display, and electric oven with a transparent door.
3.3 Gas Connection
The gas connection must be performed by a qualified and authorized technician. The appliance is factory-set for G20 (natural gas). Replacement nozzles for G30/G31 (LPG) are included for conversion if required. Ensure all connections are leak-tested.
3.4 Electrical Connection
Connect the appliance to a properly earthed electrical outlet. The electrical connection must comply with local safety standards. Do not use adapters or extension cords. The cooker's height can be adjusted between 857 mm and 908 mm using the adjustable feet.
4. Operating the Gas Hob
The hob features 4 gas burners, including one double crown burner for high-power cooking.
4.1 Burner Layout
- Front Left: Standard burner
- Rear Left: Standard burner
- Front Right: Standard burner
- Rear Right: Double Crown burner (4 kW)
4.2 Ignition
- Place a suitable pan on the desired burner.
- Push and turn the corresponding control knob counter-clockwise to the maximum flame setting.
- Hold the knob in for a few seconds to allow the thermocouple to heat up.
- Release the knob. If the flame extinguishes, repeat the process.
- Adjust the flame size by turning the knob between the maximum and minimum settings.
Important: Do not hold the knob for too long after the flame has ignited, as this can damage the ignition system.
5. Operating the Electric Oven
The multifunction electric oven offers various cooking modes, including specialized functions.
Image 2: Interior view of the De'Longhi PRO 66 MXL PZ oven with the door open, showing multiple rack positions and a baking tray inside.
5.1 Oven Functions
- Conventional Bake: For traditional baking and roasting.
- Fan-Assisted Bake: For even heat distribution, ideal for cooking on multiple levels.
- Grill: For grilling and browning.
- Master Pizza 300°C: A dedicated function designed to reach high temperatures (up to 300°C) quickly, ideal for baking pizzas with a crispy crust. Use with the provided pizza stone (if applicable).
- Easy Steam: This function introduces steam into the oven cavity, suitable for baking bread, pastries, or reheating dishes to retain moisture. Follow specific instructions for water filling.
- Defrost: Uses the fan to circulate air at room temperature for gentle defrosting.
5.2 Setting the Oven
- Turn the function selector knob to the desired cooking mode.
- Turn the temperature selector knob to the desired temperature.
- The oven will begin to preheat. An indicator light will turn off when the set temperature is reached.
- Place food inside the oven using appropriate bakeware.
- Monitor cooking progress through the oven door.
Refer to the specific recipe or food packaging for recommended cooking times and temperatures.
6. Maintenance and Cleaning
Regular cleaning and maintenance ensure the longevity and optimal performance of your cooker.
6.1 Idroclean System
The Idroclean system uses steam to soften food residues, making them easier to remove. Follow these steps:
- Pour approximately 200 ml of water into the bottom of the oven cavity.
- Select the Idroclean function (refer to your oven's control panel for the specific symbol).
- Run the cycle for the recommended duration (usually 20-30 minutes) at a low temperature.
- Once the cycle is complete and the oven has cooled, wipe away softened residues with a damp cloth or sponge.
6.2 Hob Cleaning
- Allow burners and pan supports to cool completely before cleaning.
- Remove pan supports and burner caps/crowns. Wash them with warm soapy water.
- Wipe the stainless steel hob surface with a soft cloth and a mild detergent. Avoid abrasive cleaners that can scratch the surface.
- Ensure all parts are thoroughly dry before reassembling.
6.3 Oven Interior and Exterior
- For the oven interior, after using Idroclean, wipe with a damp cloth. For stubborn stains, use a specialized oven cleaner, following the product instructions carefully.
- Clean the oven exterior with a soft cloth and mild detergent.
- Do not use steam cleaners.
7. Troubleshooting
Before contacting customer service, refer to the following common issues and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Gas burner does not ignite. | No gas supply; ignition electrode dirty; thermocouple not heated sufficiently. | Check gas supply; clean electrode; hold knob longer after ignition. |
| Oven not heating. | No power supply; oven function/temperature not set correctly; door not closed properly. | Check power connection; verify settings; ensure door is fully closed. |
| Uneven cooking in oven. | Incorrect rack position; overloaded oven; door opened too frequently. | Use recommended rack positions; avoid overcrowding; minimize door opening. |
| Oven light not working. | Bulb needs replacement. | Replace bulb (ensure oven is cool and disconnected from power). |
If the problem persists after attempting these solutions, contact De'Longhi customer support or a qualified service technician.
8. Specifications
Detailed technical specifications for the De'Longhi PRO 66 MXL PZ Gas Cooker:
- Model Name: PRO 66 MXL PZ
- Brand: De'Longhi
- Type: Free-standing Gas Cooker with Electric Oven
- Dimensions (W x D x H): 600 mm x 600 mm x 857-908 mm (adjustable height)
- Hob Type: Gas, 4 burners (including 1 double crown burner)
- Oven Type: Electric, Multifunction
- Oven Functions: Master Pizza 300°C, Easy Steam, Conventional, Fan-Assisted, Grill, Defrost
- Cleaning System: Idroclean (steam-assisted)
- Material: Stainless Steel
- Energy Efficiency Class: A
- Gas Regulation: G20 (Methane) - supplied; G30/G31 (LPG) - conversion nozzles included
Image 3: Energy efficiency label. Note: The provided image is for a refrigerator (Samsung BRB30600FWW) and does not correspond to the De'Longhi PRO 66 MXL PZ cooker. The cooker's energy class is A, as stated in the product features.
9. Warranty and Support
Your De'Longhi PRO 66 MXL PZ Gas Cooker is covered by a manufacturer's warranty. Please refer to the warranty card included with your appliance for specific terms and conditions, including the warranty period and coverage details.
For technical assistance, spare parts, or to schedule a service appointment, please contact De'Longhi customer support. Contact information can typically be found on the official De'Longhi website or in the warranty documentation.
When contacting support, please have your appliance model number (PRO 66 MXL PZ) and serial number ready. The serial number is usually located on a data plate on the back or side of the appliance, or inside the oven door frame.
