Teamgee S8 Dual 14-inch FHD Portable Monitor User Manual

1. Introduction

Thank you for choosing the Teamgee S8 Dual 14-inch FHD Portable Monitor. This device is designed to enhance your productivity by providing an extended display solution for various operating systems and devices. Its ultra-thin and lightweight design makes it ideal for mobile professionals, travelers, and anyone requiring an efficient multi-display setup on the go. This manual provides essential information for setup, operation, and maintenance to ensure optimal performance.

2. Package Contents

Please verify that all items are present in your package:

• Teamgee S8 Dual 14-inch Portable Monitor
• USB-C to USB-C Cables (2x)
• USB-C to HDMI Cable (1x)
• USB-A to USB-C Cable (1x)
• Portable Protective Sleeve
• User Manual (this document)

3. Key Features

• Dual 14-inch FHD Displays: Two 14-inch Full HD (1920x1080) screens provide expansive workspace.
• Ultra-Thin & Lightweight: Designed for portability, weighing approximately 1.45 pounds.
• Durable Construction: Crafted from aerospace-grade aluminum alloy for enhanced durability.
• High-Quality Visuals: Features 1000:1 contrast ratio, 300 Nits brightness, 72% NTSC color gamut, and an eye comfort display.
• Universal Compatibility: Plug-and-play support for Mac, Windows, Chromebook, Android, and Dex devices.
• Versatile Connectivity: Equipped with dual USB-C and HDMI ports for flexible device connections.
• Integrated Kickstand: A precision bearing pivot kickstand provides stable support.

Image: The Teamgee S8 monitor is designed to be significantly lighter than a standard laptop, emphasizing its portability.

Image: The monitor's display quality is highlighted, showing crisp details and vibrant colors suitable for various tasks.

Image: The built-in kickstand provides stable and adjustable support for the portable monitor.

4. Setup Instructions

The Teamgee S8 monitor offers flexible connection methods depending on your laptop's ports. All necessary cables are included.

Image: Visual guide for connecting the Teamgee S8 monitor to a laptop using either a single USB-C cable or a dual cable setup.

Method 1: Single Cable Connection (Full-function USB-C)

This method is applicable for laptops equipped with a full-function USB-C port that supports both video output (DisplayPort Alternate Mode) and power delivery.

1. Connect one end of the USB-C to USB-C cable to your laptop's full-function USB-C port.
2. Connect the other end of the USB-C to USB-C cable to either Port 1 or Port 2 on the Teamgee S8 monitor.
3. The monitor should automatically detect the signal and power on.

Method 2: Dual Cable Connection (HDMI + USB)

This method is used when your laptop does not have a full-function USB-C port, or if you prefer to use separate video and power connections.

1. Connect one end of the USB-C to HDMI cable to your laptop's HDMI port.
2. Connect the USB-C end of the USB-C to HDMI cable to Port 3 on the Teamgee S8 monitor (for video signal).
3. Connect one end of the USB-A to USB-C cable to your laptop's USB-A port (or a power adapter).
4. Connect the USB-C end of the USB-A to USB-C cable to either Port 1 or Port 2 on the Teamgee S8 monitor (for power).
5. The monitor should power on and display the video signal.

Note: Ensure your laptop's graphics settings are configured to detect and extend to the new display. This typically involves adjusting display settings in your operating system (e.g., Windows Display Settings, macOS System Preferences > Displays).

5. Operating Instructions

Display Modes

Once connected, you can configure how your laptop interacts with the portable monitor:

• Extend Mode: This mode expands your desktop across both screens, allowing you to have different applications open on each display. This is ideal for multitasking and increased productivity.
• Mirror Mode (Duplicate): This mode duplicates your laptop's screen onto the portable monitor, showing the same content on both displays. Useful for presentations or sharing content.

To switch between display modes, access your operating system's display settings:

• Windows: Right-click on the desktop, select 'Display settings', then choose 'Extend these displays' or 'Duplicate these displays' from the 'Multiple displays' dropdown.
• macOS: Go to 'System Settings' (or 'System Preferences') > 'Displays'. You can arrange displays or select 'Mirror displays'.

Adjusting Monitor Settings

The Teamgee S8 monitor includes on-screen display (OSD) controls, typically accessible via buttons on the monitor itself. These controls allow you to adjust settings such as:

• Brightness and Contrast
• Color Temperature
• Input Source Selection
• Aspect Ratio
• Volume (if speakers are present)

Refer to the specific button layout on your monitor for navigation within the OSD menu.

6. Maintenance

Proper care ensures the longevity and performance of your Teamgee S8 monitor:

• Cleaning the Screen: Use a soft, lint-free cloth slightly dampened with water or a non-abrasive screen cleaner. Avoid harsh chemicals or alcohol-based cleaners.
• Cleaning the Casing: Wipe the aluminum casing with a soft, dry cloth.
• Storage: When not in use, store the monitor in its protective sleeve to prevent scratches and dust accumulation.
• Handling: Avoid dropping the monitor or subjecting it to strong impacts. Do not place heavy objects on top of it.
• Temperature: Operate and store the monitor within recommended temperature ranges to prevent damage.

7. Troubleshooting

If you encounter issues with your Teamgee S8 monitor, refer to the following common problems and solutions:

8. Specifications

9. Warranty and Support

Teamgee products are designed for reliability and performance. For warranty information, please refer to the warranty card included in your product packaging or visit the official Teamgee website. If you require technical assistance or have questions regarding your Teamgee S8 Portable Monitor, please contact Teamgee customer support through their official channels.
